[FM-TV UNIT] [OTH-2] only
REF ORDER
NO. NO.
C1 4030013850 S.CERAMIC
C2 4030013850 S.CERAMIC
C3 4030013850 S.CERAMIC
C4 4030014200 S.CERAMIC
C5 4030013850 S.CERAMIC
C10 4030013970 S.CERAMIC
C11 4030013970 S.CERAMIC
C12 4030013970 S.CERAMIC
C13 4030013970 S.CERAMIC
C16 4030014020 S.CERAMIC
C17 4030014160 S.CERAMIC
C18 4030013970 S.CERAMIC
C19 4030013850 S.CERAMIC
C20 4030013850 S.CERAMIC
C21 4030008680 S.CERAMIC
C22 4030014320 S.CERAMIC
C24 4550006120 S.TANTALUM
C25 4550006120 S.TANTALUM
C26 4550006110 S.TANTALUM
C27 4030013970 S.CERAMIC
C28 4030013970 S.CERAMIC
C29 4550006320 S.TANTALUM
C30 4550006320 S.TANTALUM
C31 4030013850 S.CERAMIC
C32 4030013970 S.CERAMIC
C41 4030013850 S.CERAMIC
C42 4030014200 S.CERAMIC
C43 4030009820 S.CERAMIC
C44 4030009820 S.CERAMIC
C45 4030009820 S.CERAMIC
C50 4030013970 S.CERAMIC
C51 4030014150 S.CERAMIC
C52 4030013970 S.CERAMIC
C53 4030014330 S.CERAMIC
C54 4030014330 S.CERAMIC
C55 4030014190 S.CERAMIC
C57 4030009820 S.CERAMIC
C61 4030013970 S.CERAMIC
C71 4030013970 S.CERAMIC
C72 4030013970 S.CERAMIC
C73 4030008680 S.CERAMIC
C74 4550006320 S.TANTALUM
C75 4550006120 S.TANTALUM
C76 4030014180 S.CERAMIC
C77 4030009820 S.CERAMIC
C90 4030016960 S.CERAMIC
J1 6510022370 S.CONNECTOR IMSA-9178S-04Y901
EP1 0910053044 PCB
DESCRIPTION
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H101JCQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
ECUE1H020BCQ
ECUE1H270JCQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1E102KBQ
C2012 JF 1C 105Z-T-A
ECUE1H181JCQ
TEMSVA 0G 226M-8L
TEMSVA 0G 226M-8L
TEMSVB2 0J 336M8L
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
ECST0JY475R
ECST0JY475R
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1H101JCQ
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 0J 104K-T-N
ECUE1H220JCQ
C1005 JB 0J 104K-T-N
ECUE1H221JCQ
ECUE1H221JCQ
ECUE1H680JCQ
C1005 JB 1C 103K-T-A
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C2012 JF 1C 105Z-T-A
ECST0JY475R
TEMSVA 0G 226M-8L
ECUE1H470JCQ
C1005 JB 1C 103K-T-A
ECJ0EB1C183K
B 5415D
S.=Surface mount
