SECTION 6 PARTS LIST

[RF UNIT]
REF ORDER
NO. NO.
IC1 1110004020 S.IC
IC2 1110003200 S.IC
IC5 1130009670 S.IC
IC10 1110004020 S.IC
IC13 1110004480 S.IC
IC14 1110005120 S.IC
IC15 1130009370 S.IC
IC901 1110005040 S.IC
Q1 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q3 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q4 1590002430 S.TRANSISTOR DTA144EE TL
Q5 1510001030 S.TRANSISTOR DTA123JE TL
Q6 1590002010 S.TRANSISTOR XP1114 (TX)
Q7 1590002650 S.TRANSISTOR UPA805T-T1
Q8 1530003560 S.TRANSISTOR 2SC5195-T1
Q9 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q26 1530003610 S.TRANSISTOR FH102-TL
Q27 1590002010 S.TRANSISTOR XP1114 (TX)
Q41 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q42 1590002430 S.TRANSISTOR DTA144EE TL
Q43 1590001660 S.TRANSISTOR XP4312 (TX)
Q44 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q45 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q46 1590001660 S.TRANSISTOR XP4312 (TX)
Q52 1590002010 S.TRANSISTOR XP1114 (TX)
Q53 1510001030 S.TRANSISTOR DTA123JE TL
Q54 1590002010 S.TRANSISTOR XP1114 (TX)
Q121 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q201 1590001470 S.TRANSISTOR UN9213 (TX)
Q202 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q203 1590001770 S.TRANSISTOR XP1213 (TX)
Q204 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q801 1580000730 S.FET
Q851 1580000730 S.FET
Q852 1590002430 S.TRANSISTOR DTA144EE TL
Q854 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q855 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q856 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q857 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q859 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q860 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q865 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q866 1590002010 S.TRANSISTOR XP1114 (TX)
Q867 1510001030 S.TRANSISTOR DTA123JE TL
Q868 1590002010 S.TRANSISTOR XP1114 (TX)
Q869 1590002430 S.TRANSISTOR DTA144EE TL
Q872 1560000540 S.FET
Q874 1530003560 S.TRANSISTOR 2SC5195-T1
Q875 1590001440 S.TRANSISTOR UN9214 (TX)
D1 1750000350 S.VARICAP
D2 1790001620 S.DIODE
D3 1790001620 S.DIODE
D4 1790001260 S.DIODE
D5 1790001260 S.DIODE
D6 1790001260 S.DIODE
D7 1790001260 S.DIODE
D8 1790001260 S.DIODE
D9 1790001260 S.DIODE
D10 1790001620 S.DIODE
D11 1790001620 S.DIODE
D12 1790001620 S.DIODE
D13 1790001620 S.DIODE
D21 1790001620 S.DIODE
D22 1720000650 S.VARICAP
D23 1720000650 S.VARICAP
D24 1790001260 S.DIODE
D33 1790001620 S.DIODE
D34 1790000850 S.DIODE
D35 1790001620 S.DIODE
D36 1790001620 S.DIODE
D37 1790001620 S.DIODE
D51 1790001590 S.DIODE
DESCRIPTION
µPC2757T-E3
TA31136FN (EL)
BU2092FV-E2
µPC2757T-E3
µPC2758T-E3
µPC2749TB-E3
TB31242FN (EL)
M52342FP 600C
3SK293 (TE85L)
3SK293 (TE85L)
2SK880-Y (TE85R)
1SV252 (TE85L)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV286 (TPH3)
1SV286 (TPH3)
MA2S077-(TX)
1SV308 (TPL3)
MA132WK (TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
MA6S718 (TX)
[RF UNIT]
REF ORDER
NO. NO.
D52 1790001590 S.DIODE
D63 1790001260 S.DIODE
D64 1790001260 S.DIODE
D65 1790001260 S.DIODE
D66 1790001260 S.DIODE
D67 1790001260 S.DIODE
D68 1790001260 S.DIODE
D71 1790001260 S.DIODE
D72 1790001260 S.DIODE
D73 1790001260 S.DIODE
D74 1790001260 S.DIODE
D75 1790000850 S.DIODE
D76 1790000850 S.DIODE
D77 1790000660 S.DIODE
D121 1790001260 S.DIODE
D122 1790001260 S.DIODE
D201 1790001250 S.DIODE
D801 1720000650 S.VARICAP
D802 1720000650 S.VARICAP
D803 1790001260 S.DIODE
D804 1790001620 S.DIODE
D805 1790001620 S.DIODE
D851 1720000650 S.VARICAP
D852 1720000650 S.VARICAP
D853 1790001260 S.DIODE
D854 1790001620 S.DIODE
D861 1790001250 S.DIODE
D862 1790001250 S.DIODE
D871 1790001250 S.DIODE
D901 1790001260 S.DIODE
D902 1790001260 S.DIODE
D906 1790001260 S.DIODE
D907 1790001260 S.DIODE
D909 1790001620 S.DIODE
D911 1790001620 S.DIODE
D912 1790001260 S.DIODE
D913 1790000860 S.DIODE
D914 1790000850 S.DIODE
FI2 2020001270 CERAMIC
FI3 2010002490 S.XTAL
FI4 2020001760 S.CERAMIC
FI901 2040001570 SAW
FI902 2020001700 S.CERAMIC
FI904 2040001590 S.LC
FI905 2020001710 S.CERAMIC
L1 6200005600 S.COIL
L2 6200005730 S.COIL
L3 6200005670 S.COIL
L4 6200005690 S.COIL
L5 6200005690 S.COIL
L6 6200009270 S.COIL
L7 6200009270 S.COIL
L8 6200005690 S.COIL
L9 6200005700 S.COIL
L10 6200005740 S.COIL
L11 6200005680 S.COIL
L12 6200005660 S.COIL
L13 6200005610 S.COIL
L14 6200005610 S.COIL
L15 6200005630 S.COIL
L21 6150004840 S.COIL
L39 6200005690 S.COIL
L41 6200005720 S.COIL
L46 6200005640 S.COIL
L47 6200005670 S.COIL
L48 6200005680 S.COIL
L49 6200005740 S.COIL
L50 6200005680 S.COIL
L51 6200005650 S.COIL
L52 6200005680 S.COIL
L53 6200005670 S.COIL
L54 6200005660 S.COIL
6 - 1
DESCRIPTION
MA6S718 (TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA132WK (TX)
MA132WK (TX)
MA728 (TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S111-(TX)
1SV286 (TPH3)
1SV286 (TPH3)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
1SV286 (TPH3)
1SV286 (TPH3)
MA2S077-(TX)
1SV308 (TPL3)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV308 (TPL3)
1SV308 (TPL3)
MA2S077-(TX)
MA133 (TX)
MA132WK (TX)
CFWM450E
FL-319
SFECV13.25MAS
WFSTSB6221D
SFSCC4.5MC2-TC10
LFSC25N11B0240B
TPSCC4.5MB-TC10
ELJRE 3N3Z-F
ELJRE 39NG-F
ELJRE 12NG-F
ELJRE 18NG-F
ELJRE 18NG-F
MLF2012K 560K-T
MLF2012K 560K-T
ELJRE 18NG-F
ELJRE 22NG-F
ELJRE 47NG-F
ELJRE 15NG-F
ELJRE 10NG-F
ELJRE 3N9Z-F
ELJRE 3N9Z-F
ELJRE 5N6Z-F
LS-510
ELJRE 18NG-F
ELJRE 33NG-F
ELJRE 6N8Z-F
ELJRE 12NG-F
ELJRE 15NG-F
ELJRE 47NG-F
ELJRE 15NG-F
ELJRE 8N2Z-F
ELJRE 15NG-F
ELJRE 12NG-F
ELJRE 10NG-F
S.=Surface mount
