Icom IC-R3 Service Manual page 29

[RF-B UNIT]
REF ORDER
NO. NO.
R709 7030007290 S.RESISTOR
R710 7030007290 S.RESISTOR
R711 7030007250 S.RESISTOR
C401 4030009820 S.CERAMIC
C402 4030009820 S.CERAMIC
C403 4030009820 S.CERAMIC
C404 4030009820 S.CERAMIC
C405 4030009820 S.CERAMIC
C406 4030009820 S.CERAMIC
C407 4030009820 S.CERAMIC
C408 4030009820 S.CERAMIC
C409 4030009820 S.CERAMIC
C410 4030009820 S.CERAMIC
C411 4030009820 S.CERAMIC
C501 4030013850 S.CERAMIC
C502 4030013850 S.CERAMIC
C503 4030013850 S.CERAMIC
C504 4030013850 S.CERAMIC
C505 4030013850 S.CERAMIC
C506 4030013850 S.CERAMIC
C507 4030013850 S.CERAMIC
C508 4030013850 S.CERAMIC
C509 4030013850 S.CERAMIC
C510 4030013850 S.CERAMIC
C511 4030013850 S.CERAMIC
C601 4030013850 S.CERAMIC
C602 4030013850 S.CERAMIC
C603 4030014120 S.CERAMIC
C604 4030013850 S.CERAMIC
C605 4030013850 S.CERAMIC
C606 4030013850 S.CERAMIC
C607 4030013850 S.CERAMIC
C608 4030014050 S.CERAMIC
C609 4030013850 S.CERAMIC
C610 4030013850 S.CERAMIC
C611 4030013850 S.CERAMIC
C701 4030013850 S.CERAMIC
C702 4030013850 S.CERAMIC
C703 4030013850 S.CERAMIC
C704 4030013850 S.CERAMIC
C705 4030013850 S.CERAMIC
C706 4030013850 S.CERAMIC
C707 4030013850 S.CERAMIC
C708 4030013850 S.CERAMIC
C709 4030013850 S.CERAMIC
C710 4030013850 S.CERAMIC
C711 4030013850 S.CERAMIC
J3 6510022330 CONNECTOR
J4 6510022340 CONNECTOR
EP1 0910053034 PCB
[LOGIC UNIT]
REF ORDER
NO. NO.
IC2 1140008440 S.IC
IC3 1180001820 S.IC
IC5 1110005070 S.IC
IC9 1110003800 S.IC
IC10 1110004790 S.IC
IC11 1140008990 S.IC
IC14 1110004520 S.IC
IC15 1190000710 S.IC
IC801 1190001250 S.IC
IC901 1190001110 S.IC
IC902 1190001130 S.IC
IC903 1130006540 S.IC
Q1 1590001180 S.TRANSISTOR XP1210 (TX)
Q2 1590001440 S.TRANSISTOR UN9214 (TX)
Q4 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
DESCRIPTION
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 220 X (22 Ω)
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H100CCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H030BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
IMSA-9230B-1-04Z113-T
IMSA-9230B-1-06Z113-T
B 5372D
DESCRIPTION
AK93C10AF-E2
XC62FP3002MR
S-80925ALMP-DAN-T2
NJM2904V-TE1
XC6371A351PR
M38267M8L-256GP RX-2304
M5222FP 600C
TA31056F (TP1)
MB3776APFV-G-BND-ER
LV4127W
M35017-001FP
TC7S02FU (TE85R)
[LOGIC UNIT]
REF ORDER
NO. NO.
Q5 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q6 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q7 1590001440 S.TRANSISTOR UN9214 (TX)
Q8 1590002430 S.TRANSISTOR DTA144EE TL
Q11 1590001440 S.TRANSISTOR UN9214 (TX)
Q17 1590001390 S.FET
Q18 1590002430 S.TRANSISTOR DTA144EE TL
Q19 1590001940 S.TRANSISTOR DTC144EE TL
Q23 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q26 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q30 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q31 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q36 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q37 1590001390 S.FET
Q38 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q39 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q40 1590002430 S.TRANSISTOR DTA144EE TL
Q41 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q42 1590001650 S.TRANSISTOR XP4601 (TX)
Q43 1560000840 S.FET
Q44 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q50 1590001440 S.TRANSISTOR UN9214 (TX)
Q51 1590002430 S.TRANSISTOR DTA144EE TL
Q201 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q202 1590001440 S.TRANSISTOR UN9214 (TX)
Q203 1590002950 S.FET
Q303 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q304 1530003190 S.TRANSISTOR 2SC4617 TLQ
Q801 1560001110 S.FET
Q802 1590002820 S.TRANSISTOR UMY1N TR
Q804 1560001110 S.FET
Q806 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q820 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q821 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q902 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q903 1510000620 S.TRANSISTOR 2SA1576 T107 S
Q904 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q908 1590001440 S.TRANSISTOR UN9214 (TX)
D1 1790001250 S.DIODE
D2 1790001250 S.DIODE
D3 1790001560 S.DIODE
D4 1790000970 S.DIODE
D5 1790001560 S.DIODE
D7 1790001250 S.DIODE
D8 1790001250 S.DIODE
D9 1790001250 S.DIODE
D14 1790001250 S.DIODE
D15 1790001560 S.DIODE
D16 1790000850 S.DIODE
D17 1790001250 S.DIODE
D18 1790001590 S.DIODE
D19 1790001560 S.DIODE
D20 1790001560 S.DIODE
D201 1750000540 S.DIODE
D202 1790001240 S.DIODE
D203 1790000860 S.DIODE
D204 1790000670 S.DIODE
D301 1790001250 S.DIODE
D800 1750000690 S.DIODE
D801 1750000690 S.DIODE
D802 1750000690 S.DIODE
D804 1750000540 S.DIODE
D805 1750000540 S.DIODE
D810 1790001260 S.DIODE
D820 1790001250 S.DIODE
D901 1720000660 S.VARICAP
D903 1790001250 S.DIODE
X1 6050010310 S.XTAL
X901 6050011010 S.XTAL
L1 6200008630 S.COIL
L900 6200002040 S.COIL
L901 6200005010 S.COIL
L902 6200005010 S.COIL
L903 6200005010 S.COIL
L904 6200005010 S.COIL
L905 6200005010 S.COIL
6 - 6
DESCRIPTION
2SJ144-Y (TE85R)
2SJ144-Y (TE85R)
2SK1829 (TE85R)
HAT1023R-EL
2SK2493 (TE16L)
2SK2493 (TE16L)
MA2S111-(TX)
MA2S111-(TX)
1SS372 (TE85R)
MA729 (TX)
1SS372 (TE85R)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
1SS372 (TE85R)
MA132WK (TX)
MA2S111-(TX)
MA6S718 (TX)
1SS372 (TE85R)
1SS372 (TE85R)
RB060L-40 TE-25
MA2S728-(TX)
MA133 (TX)
SB07-03C-TB
MA2S111-(TX)
MA727-(TX)
MA727-(TX)
MA727-(TX)
RB060L-40 TE-25
RB060L-40 TE-25
MA2S077-(TX)
MA2S111-(TX)
1SV288 (TPH2)
MA2S111-(TX)
CR-613 (4.935 MHz)
CR-679 (3.579545 MHz)
CD54-101KC
NL 252018T-101J
NL 252018T-100J
NL 252018T-100J
NL 252018T-100J
NL 252018T-100J
NL 252018T-100J
S.=Surface mount
