CONNECTION
Standard signal
generator
DC POWER CABLE CONNECTION
CLONE
GND
1/8" (3.5 mm)
3-conductor plug
When entering the adjustment mode,
input the square wave as below from
the audio generator
1.5 V 3 V
10 Hz
5 - 2
Audio generator
Power supply
4.5 V / 1 A
