1. SPECIFICATION
ITEM
POWER SUPPLY
PRODUCT WEIGHT
ELECTRICITY
DRAIN MOTOR
CONSUMPTION
STEAM HEATER
WASH HEATER
REVOLUTION
SPEED
OPERATION WATER PRESSURE
CONTROL TYPE
WASH CAPACITY
DIMENSION
WASH PROGRAM
RINSE
DOOR SWITCH TYPE
WATER LEVEL
RESERVATION
SENSING LAUNDRY AMOUNT
FUZZY LOGIC
DISPLAY REMAINING TIME
ERROR DIAGNOSIS
POWER AUTO OFF
CHILD LOCK
AUTO RESTART
TIME SAVE
WARNING
To reduce the risk of personal injury, adhere to all industry recommended safety procedures including
the use of long sleeved gloves and safety glasses.
Failure to follow all of the safety warnings in this manual could result in property damage, personal
injury or death.
F14A8TDSA(1~9) / F12A8TDSA(1~9) / F14A8QDSA(1~9) / F12A8QDSA(1~9)
WASHING
SPIN
WASH
F14A8*DSA(1~9) : No Spin / 400 / 800 / 1000 / 1400
SPIN
F12A8*DSA(1~9) : No Spin / 400 / 800 / 1000 / 1200
Cotton, Cotton Eco, Mix, Easy Care, Duvet, Allergy Care, Refresh,
220 V - 240 V ~, 50 Hz
66 kg
190 W
380 W
30 W
1200 W
2120 W
46 rpm
100 ~ 1000 kPa (1.0 kgf / cm
Electronic
Refer to the Rating Label
600 mm (W) x 590 mm (D) x 850 mm (H)
Sports Wear, Dark Wash, Delicate, Wool,
Intensive 60, Quick 30, Silent Wash
Normal, Rinse + , Rinse ++ , Rinse + +Hold, Normal+Hold
PTC+Solenoid
by Pressure Sensor S/W
From 3 hours to 19 hours
Adapted
Adapted
Adapted
10 items
Adapted
Adapted
Adapted
Adapted
3
2
2
~ 10.0 kgf / cm )
