Norton TC-405 Owner's Manual

Thank you for buying wet tile/concrete hand held saw.
To ensure your safety and satisfaction. Carefully read through this owner's manual before
using the product.
SPECIFICATIONS
Wheel diameter
Wheel arbor diameter
Max. Cutting capacities
With 4-1/2"(110 mm) blade
With 5"(125 mm) blade
Input
No load speed
Overall dimensions
Net weight
SAFETY PRECAUTIONS
• Never use the machine improperly or work in an unsafe manner.
• Always wear safety goggles, dust mask, and ear protection while operating the saw (to comply with ANSI-Z87.1).
• Always remain alert when the saw is in use. Failure to pay attention on the operator's part may lead to serious injury.
• Before you start working, familiarize yourself with the work site and its surroundings. Take notice of circumstances which may
impede working or traffic, observe soil conditions (good bearing or not), and take measures to ensure safety (i.e. the shielding of
roadworks from public traffic).
• Take measures to ensure that the machine is in a safe and trouble-free condition prior to usage. Use the machine only when all
protective devices (i.e. guards, noise absorbers, emergency-off devices) are operating in the intended locations.
• A visual check of the machine must be made at least once a shift to ensure that visible damages or faults are recognized. Any
changes (including changes in the performance or behavior of the machine) must be reported to the supervisor. If necessary, stop
the machine at once and secure it.
• In the case of a malfunction stop the machine immediately and secure it. Fix the problem as soon as possible.
• For starting and stopping the machine follow the operating instruction steps and observe any indicator lights.
• Before switching the machine on make sure that the activated machine will be of no danger to anyone.
INSTRUCTIONS FOR SAFE HANDLING
1. Make sure that the tool is only connected to the voltage marked on the name
plate.
2. Never use the tool if its cover or any bolts are missing. If the cover or bolts have
been removed, replace them prior to use. Maintain all parts in good working
order.
3. Always secure tools when working in elevated positions.
4. Never touch the blade or other moving parts during use.
5. Never start a tool when its rotating component is in contact with the work piece.
6. Never lay a tool down before its moving parts have come to a complete stop.
7. ACCESSORIES: The use of accessories or attachments other than those
recommended in this manual might present a hazard.
8. REPLACEMENT PARTS: When servicing use only identical replacement parts.
TC-405 Hand Held Saw
Owner's Manual
110 mm (4-5/16") - 125 mm (5")
20 mm (25/32")
at 45º at 90º
13/16"(21 mm) 1-3/8"(34 mm)
1"(26 mm) 1-5/8"(41.5 mm)
1,000 W
-1
12,000 min
204 X 220 X 157 mm
(8-1/16" X 8-1/2" X 6-3/16")
2.9 kg (6.4 lbs)
English Espanol
SawMaster Diamond Tools, Inc.
UNPACKING
Open the container, carefully lift the hand held
saw by the handles and place it on a flat, level
working area. Be certain that you have the
following items before you discard the
container.
• Saw
• Universal Wrench
• Water Tube Assembly
• Ø4-1/2" Saw Blade
• Owners Manual
Switch
Figure 1
• The saw is activated by pressing
trigger (1), to deactivate the saw release the
trigger.
• To keep the saw on, press the lock button
(2) while pressing the trigger. Press the
trigger again to deactivate the lock.
English
the
