SY-7VBA133U Quick Start Guide

Quick BIOS Setup

This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead,

CPU settings are software configurable with the BIOS [SOYO COMBO FEATURE]. The

[SOYO COMBO FEATURE] combines the main parameters that you need to configure, all

in one menu, for a quick setup in BIOS.

After the hardware installation is complete, turn the power switch on, then press the <DEL> key

during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS

SETUP UTILITY will be shown on the screen. Then, follow these steps to configure the CPU

settings.

Select [STANDARD CMOS SETUP]

Step 1.

Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to "Auto".

Select [LOAD OPTIMIZED DEFAULTS]

Step 2.

Select the "LOAD OPTIMIZED DEFAULTS" menu and type "Y" at the prompt to load the

BIOS optimal setup.

Select [SOYO COMBO FEATURE]

Step 3.

Set the [CPU Frequency Select] field to "Manual", to be able to change the CPU frequency

1 MHz stepping.

Select [SAVE & EXIT SETUP]

Step 4.

Press <Enter> to save the new configuration to the CMOS memory, and continue the boot

sequence.
