2.3.6.6 Set up constant power output (the range is from 0 to 108 W)
When you select the MAX POWER function, the LCD will display as:
MAX POWER=56 W
NEW=

2.3.6.7 Set up SAVE OPTION

This function is for saving the last set up of the voltage output. It will save much time of
users when the users will need the same voltage value. It will display the same voltage value
when the power supply is powered on for every time.
When you select the SAVE OPTION function, the LCD will display as:
SAVE VOLTAGE
DON T SAVE VOLT

2.3.6.8 EXIT function

When the EXIT function is selected, you will exit the Menu operation.
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
3645A-TYPE USER'S MANUAL
Users can change the power value by using number
kayboard or rotating the ROTARY button, and confirm
the value by pressing "Enter" button. The range of the
power value is from 0 to 108W.
Users can change the selection by using UP and DOWN
keys or rotating the ROTARY button, and confirm the
selection by pressing "Enter" button. To select SAVE
VOLTAGE means to save the last set up voltage, to select
DON T SAVE VOLT means not to save the last set up
voltage value.
14
