2.3.1 V-set (set up a constant voltage from 0 to 36V)
Set up a constant DC voltage output is the first main function of programmable DC power
supply, 3645A power supply provides two methods to set up the constant DC voltage output by
using the number keyboard and the rotary button. Please see the following operation procedure.
Procedure
Step 1
Step 2
Step 3
Step 4
Step 5
It will exit the setting up voltage operation at any procedure by press ESC button
For example, how to set up the output voltage at 24.3V
1. To set up by using number keyboard
Step1. Press "V-set" button,
Step2. Enter the password by using the number keyboard (if the keyboard is unlocked,
please do step4),
Step3. Press Enter button (if the password is wrong, please do step2 for reentering),
Step4. Press "2", "4", "." and "3" button to enter the voltage value,
Step5. Press "V/A" button to confirm the voltage value.
2. To set up by using Rotary SW
(1) If the key board is unlocked by password, directly rotate the "Rotary SW" button, and the
voltage will be continually changed from the previews value according the rotation. At the
beginning, the cursor will be shown on the last number of the value which is indicated on the
LCD, you can move the cursor to the first number, second number etc by using "
buttons, and then rotate to change each number, and let it stay at 24.3 V, then confirm the value
by pressing "V/A" button.
(2) If the keyboard is locked by password
Step1. Press "V-set" button,
Step2. Enter the password by using the number keyboard,
Step3. Press Enter button (if the password is wrong, please do step2 for reentering),
Step4. Rotate the Rotary SW button to change the value, the operation is as the same as item(1)
Step5. Press "V/A" button to confirm the voltage value.
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3
Operation details
Press "V-set"
Enter the password ( Or jump to step 4 if the keyboard
is unlocked)
Press "Enter" button ( it will return to step 2 if your
password is wrong for reentering)
Press "V-set" .Set the voltage voltage to 24.00V by using
the number key or the rotary code switch.Then pyess
"V/A" to confirm the set
Press "mV/mA" button to change the voltage unit into mV,
it will return to step 4 for reentering if the current voltage
exceed the high limited voltage value
3645A-TYPE USER'S MANUAL
LCD display
24.00V 0.00A
0.00W ON
ENTER PASSWORD
ENTER PASSWORD
****
SET VOLT= 24.00V
NEW=
SET VOLT= 24.00V
NEW= 18
"and " "
