3. 1 System Installation

3.1.1 Put the disk into the CDROM drive. Then the system will run automatically and the initial diagram as
in Fig. 3-1 will be displayed.
3.1.2 Then it will enter the interface as in Fig. 3-2. Press "NEXT" to continue.
3.1.3 In Fig. 1-3, there is some explanation to some products' introduction. Read it and press "YES" to
continue, otherwise there will be no way to install.
3.4 In Fig. 3-4, click "BROWSE" to select installation directory path. The default directory path is "C:
\Program Files\Array\PowerMS"
3645A Programmable Power Supply
ARRAY ELECTRONIC CO.,LTD 2002.3

Chapter 3 System Installation

Fig.3-1 The Installation Initial Interface
Fig. 3-2 The Installation Interface 2
Fig. 3-3 The Installation Interface 3
