HP Z230 SFF Workstation Quickspecs page 39

QuickSpecs
Technical Specifications - Graphics
Graphics Cable Adapters
AMD FirePro V3900 1GB
Graphics
Drivers
Power Consumption
Note
Notes
Form Factor
Graphics Controller
Bus Type
Memory
Maximum Resolution
Display Output
Shading Architecture
Supported Graphics APIs OpenCL™ 1.1, DirectX® 11 and OpenGL 4.2
Available Graphics
Drivers
Power Consumption
Note
DA - 14630 Worldwide — Version 14 — April 1, 2014
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
HP qualified drivers may be preloaded or available from the HP support Web
site:
http://welcome.hp.com/country/us/en/support.html
33.4 Watts
Heatsink cooler design is active.
Graphics Cable Adapter option choice is available starting Feb 1 2013 for the
following graphics cards:
NVS 310, Quadro 410, Quadro K5000, FirePro V3900, FirePro W7000
New Graphics Cards introduced after Feb 1 2013 will be eligible for choosing
Graphics Cable Adapters, unless otherwise specified.
No cable choice for NVS 300, NVS 510.
Maximum number of cables allowed is 8.
Full height, half length (full-height bracket included)
AMD FirePro™ V3900 professional graphics
PCI Express® x16, Generation 2.1
1GB DDR3 memory
2560x1600 per display (5120x1600 max. horizontal resolution)
1 DisplayPort® 1.2
1 Dual-link DVI
Shader Model 5.0
Genuine Windows® 7 Professional (64-bit and 32-bit)
Genuine Windows Vista® Business (64-bit and 32-bit)
Microsoft® Windows XP® Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
HP qualified drivers may be preloaded or available from the HP support Web
site: http://welcome.hp.com/country/us/en/support.html
<50W
AMD Eyefinity technology can support multiple displays using a single enabled
AMD FirePro™ professional graphics card; the number of supported displays
varies by card model. Microsoft® Windows® 7, Windows Vista®, or Linux® is
required in order to support more than 2 displays. Depending on the card
model, native DisplayPort™ connectors and/or certified DisplayPort™ active or
passive adapters to convert your monitor's native input to your card's
DisplayPort™ or Mini-DisplayPort™ connector(s) may be required. See
HP Z230 SFF Workstation
Page 39
