HP Z230 SFF Workstation Quickspecs page 36

QuickSpecs
Technical Specifications - Graphics
NVIDIA NVS 315 1GB
Graphics (for HP
Workstations)
Shading Architecture
Supported Graphics APIs DX11, OpenGL 4.1
Available Graphics
Drivers
Power Consumption
Note
Form Factor
Graphics Controller
Bus Type
Memory
Connectors
Maximum Resolution
Image Quality Features
DA - 14630 Worldwide — Version 14 — April 1, 2014
VGA display output:
Drives two analog display at resolutions up to 1920 × 1200 at 60 Hz
using DisplayPort to VGA cable adaptors
Shader Model 5.0
Genuine Windows 7 Professional (64-bit and 32-bit)
Microsoft Windows XP Professional (64-bit and 32-bit)
Red Hat Enterprise Linux(RHEL)
SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)
HP qualified drivers may be preloaded or the latest HP qualified drivers are
available from the HP support Web site:
http://welcome.hp.com/country/us/en/support.html
SUSE Linux Enterprise drivers may also be obtained from:
ftp://download.nvidia.com/novell
19.5 Watts
The thermal solution used on this card is an active fan heatsink.
Low Profile:
2.713 inches in height × 5.7 inches in length
NVIDIA NVS 315 (using GF119-825 GPU)
Number of Cores: 48 CUDA cores
Max. Power: 19.3W
Cooling Solution: Active fan heatsink
PCI Express x16, 2.0 compliant
Size: 1GB DDR3
Clock: 875Mhz
Memory Bandwidth: 14GB/s
DMS-59 output
Cables included:
- For CTO: DMS-59 to DVI cable
- For AMO: DMS-59 to DVI cable and DMS-59 to VGA cable
Maximum number of displays supported: 2
Maximum Resolution Support:
- DMS-59 to VGA: 2048 x 1536 @ 85Hz
- DMS-59 to DVI: 1980 x 1200 @ 60Hz
- DMS-59 to DP: 2560 x 1600 @ 60Hz
See Display Output section.
The following video formats are supported:
- MPEG2
- MPEG4 Part 2 Advanced Simple Profile
HP Z230 SFF Workstation
or http://www.nvidia.com
Page 36
