OWNERS MANUAL
INSTALLATION, OPERATION & MAINTENANCE
RANGES & GRIDDLE/BROILER
WARNING:
Improper installation, adjustment,
alteration, service or maintenance can
cause damage, injury or death. Read the
installation, operating & maintenance
instructions thoroughly before installing or
servicing the equipment.
FOR YOUR SAFETY:
Do not store or use gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
Instruction to be followed in the event the user smells gas shall be posted
in a pominent location. This informantion shall be obtained by consulting
the local gas supplier.
Form Number: S-2551
11/04
Printed in U.S.A.
MODELS: m MF-R4
m MF-R6
m MF-R8
m MF-R10
RAISED GRIDDLES:
m MF-RG12-2
m MF-RG12-4
m MF-RG12-6
m MF-RG12-8
m MF-RG24
m MF-RG24-2
m MF-RG24-4
m MF-RG24-6
m MF-RG36-4
CAUTION:
Tel: (617) 387-4100
E-Mail: custserv@mfii.com
COVERING:
- INSTALLATION
- OPERATION
- MAINTENANCE
- PARTS & SERVICE
l
35 Garvey Street
Everett
l
Fax: (617) 387-4456
Outside Fax: 1-800-227-2659
l
Website: www.mfii.com
l
l
MA
02149
Advertisement
Table of Contents
Related Manuals for Market Forge Industries MF-R4
Summary of Contents for Market Forge Industries MF-R4
-
Page 1: Owners Manual
OWNERS MANUAL INSTALLATION, OPERATION & MAINTENANCE RANGES & GRIDDLE/BROILER MODELS: m MF-R4 WARNING: COVERING: m MF-R6 - INSTALLATION Improper installation, adjustment, m MF-R8 - OPERATION m MF-R10 alteration, service or maintenance can - MAINTENANCE - PARTS & SERVICE cause damage, injury or death. Read the installation, operating &... -
Page 2: Table Of Contents
TABLE OF CONTENTS INSTALLATION INSTRUCTIONS ........BEFORE FIRST USE - GRIDDLES ........ RATING PLATE ............... BEFORE FIRST USE - OVENS ........CLEARANCES ..............MAINTENANCE INSTRUCTIONS ........HIGH SHELF ASSEMBLY ..........CLEANING & MAINTENANCE ........OPERATING INSTRUCTIONS ........OPEN BURNERS - DAILY MAINTENANCE ....LEVELING (RANGES EQUIPED WITH OVENS) ... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS m A manual gas shut - off valve must be installed in the gas supply line ahead of the appliance and gas pressure regulator for safety and ease in servicing. m The gas pressure regulator supplied must be installed on the appliance prior to connecting the equipment to the gas line. -
Page 4: Gas Connection
OPERATING INSTRUCTIONS tained around the appliance for easy servicing. Provision should be made for any commercial, heavy duty cooking appliance to exhaust combustion waste products to the outside of the building. Usual practice is to place the appliance under an exhaust hood, which should be constructed in accordance to the local codes. -
Page 5: Flexible Couplings Connector & Casters
OPERATING INSTRUCTIONS (CONT.) FLEXIBLE COUPLINGS. CONNECTOR AND CASTERS: For an appliance equipped with casters, the installation shall be made with a connector that complies with the Standard for Connectors for Movable Gas Appliances, ANSI Z21.69 or Connectors for Moveable Gas Appliances, CAN/CGA-6.16,and a quick disconnect device that complies with the Standard for Quick Disconnect Devices for Use With Gas Fuel, ANSI Z21.41, or Quick Disconnect Devices for Use With Gas Fuel, CANI-6.9. -
Page 6: Before First Use - Griddles
OPERATING INSTRUCTIONS (CONT.) m Make sure accumulated gas if any has dispersed. Since propane gas is heavier than air, check near the floor area for the odor of propane gas before attempting to light any pilot burner. m Depress the red button on the safety valve and hold it in, throughout the lighting procedure. m Press the red button ofthe pilot ignitor and you should hear a snap and see a spark at the pilot burner. -
Page 7: Maintenance Instructions
MAINTENANCE INSTRUCTIONS To perform maintenance and repairs on the unit, please contact the factory, ther factory representatives or the nearest authorized service company. CLEANING AND MAINTENANCE: Any equipment works better and lasts longer when maintained properly. Cooking equipment is no exception. Your Market Forge Range and Oven must be kept clean on a daily basis. CAUTION: NEVER USE AMMONIA IN AN OVEN THAT IS WARMER THAN ROOM TEMPERATURE AND AL WAYS HAVE DIRECT VENTILATION! -
Page 8: Illustrated Parts List
ILLUSTRATED PARTS LIST BURNER/GRIDDLE OPTIONS MF-R4 MF-R10 Model Total Ship Model Total Ship Configuration Number Base Weight Configuration Number Base Weight MF-R4 (4) Burners 20" MF-R10 (10) Burners (1) 30" (Standard) Oven Bases 170,000 480 lbs (Standard) & 420,000 995 lbs (1) 20"... -
Page 9: Parts List
ILLUSTRATED PARTS LIST (CONT.) ITEM NO. PART NO. DESCRIPTIONS 93-0100 TOP GRATE - 12" X 12" 93-0097 BURNER HEAD (ANTI-CLOG) 93-0099 VENTURI - REAR 93-0098 VENTURI - FRONT 93-0082 AIR SHUTTER 93-0152 BURNER HANGER 93-0118 24" CRUMB TRAY 93-0119 36" CRUMB TRAY 93-0120 48"... - Page 10 ILLUSTRATED PARTS LIST (CONT.) ITEM NO. PART NO. DESCRIPTIONS 93-0046 LEG - 6" CONE 93-0151 12" LANDING LEGDE 93-0146 24" LANDING LEGDE 93-0147 36" LANDING LEGDE 93-0148 48" LANDING LEGDE 93-0149 60" LANDING LEGDE 93-0150 72" LANDING LEGDE 93-0004 REGULATOR (NATURAL) - USED ON 24" & 36" 93-0005 REGULATOR (L.P.) - USED ON 24"...
-
Page 11: Range/Oven (Exploded View)
ILLUSTRATED PARTS LIST (CONT.) RANGE/OVEN... -
Page 12: Range/Griddle/Broiler (Exploded View)
ILLUSTRATED PARTS LIST (CONT.) RANGE/GRIDDLE/BROILER...
