Installation & Operation Manual
Gas Boilerless Convection Steamer
SIRIUS II-(4, 6, 8, 10 & 12)
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
M
R
ANUAL 14-0268
EV 9 (07/22)
$21.00
SIRIUS II
Sirius II - 6
servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
Sirius II - 10
WARNING
A Middleby Company
www.crownsteamgroup.com
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
SIRIUS II - GAS BOILERLESS
CONVECTION STEAMER
M
S
ANUAL
ECTION
CO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Market Forge Industries SIRIUS II Series
Summary of Contents for Market Forge Industries SIRIUS II Series
- Page 1 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment: Model #: ___________________________ Serial #: ___________________________ Date Purchased: _____________________ Installation & Operation Manual SIRIUS II Gas Boilerless Convection Steamer SIRIUS II-(4, 6, 8, 10 & 12) Sirius II - 6 Sirius II - 10 WARNING...
-
Page 2: Important Notes For Installation And Operation
Safety Precautions SIRIUS II - Gas Boilerless Convection Steamer SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment. -
Page 3: Table Of Contents
SIRIUS II - Gas Boilerless Convection Steamer Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Introduction ........................... 6 Installation ..........................8 Operation ..........................12 Maintenance ......................... -
Page 4: Service Connections
Service Connections SIRIUS II - Gas Boilerless Convection Steamer ERVICE ONNECTIONS DIMENSIONS ARE IN INCHES [MM] 30.75 [781] 24.00 [610] Flue 6.50 6.25 Steam 1.50 [165] [159] 19.00 [483] Vent [38] 17.75 [451] 2.00 28.75 [730] 3.88 [51] [98] Pull out service drawer 2.00 Sirius II-4... - Page 5 SIRIUS II - Gas Boilerless Convection Steamer Service Connections DIMENSIONS ARE IN INCHES [MM] DIMENSIONS ARE IN INCHES [MM] 32.50 [826] 24.00 [610] 19.00 [483] Flue 17.75 [451] 28.75 [730] Steam Vents Pull out service 3.88 [98] drawer [127] Sirius II-8 Sirius II-10 Gas in Sirius II-12...
-
Page 6: Introduction
Introduction SIRIUS II - Gas Boilerless Convection Steamer NTRODUCTION Product Description Congratulations on purchasing the Market Forge Sirius II. The Sirius II is a single compartment countertop or two compartment floor model steamer featuring pressureless steam cooking, a circulating fan inside the cooking chamber to speed cooking and an automatic preheated waterfill mechanism. - Page 7 SIRIUS II - Gas Boilerless Convection Steamer Introduction Time Delay Relay: The steamer has two timers built into the electrical system to shut down should the water level system fail. When the steamer is first turned on and the reservoir is empty two countdown timers will begin to count. If it takes longer than 60 seconds for the level of the water to come into contact with the lower water sensor probe, the burner and the heating light will turn off.
-
Page 8: Installation
Installation SIRIUS II - Gas Boilerless Convection Steamer Nstallation Delivery and Inspection Damage Inspection: Reporting shipping damage is the responsibility of the purchaser. Do not discard packaging if filing a freight damage claim. Upon receipt of steamer immediately inspect the exterior of packaging for damage. - Page 9 SIRIUS II - Gas Boilerless Convection Steamer Installation Venting The Sirius II must be installed in an adequately ventilated area under a properly designed exhaust hood. Failure to do so could result in component failure and the introduction of unwanted flue gasses into the work area. A properly designed hood system is one that exhausts 100% of grease-laden vapor and flue products and replenishes at least 80% of the air it exhausts.
- Page 10 Installation SIRIUS II - Gas Boilerless Convection Steamer Recommended Water Quality: Refer to Service Connections in this Manual for the recommended water quality criteria. NOTICE Water level probes will not sense water level if steamer is connected to a de-ionized water or reverse osmosis system. Rear Drain: Make sure the 1”...
- Page 11 SIRIUS II - Gas Boilerless Convection Steamer Installation Startup Procedure 1. Make sure water line is flushed prior to connecting steamer. 2. Make sure water is connected and supplied to the steamer. 3. Make sure appropriate gas is connected and supplied to the steamer. 4.
-
Page 12: Operation
Operation SIRIUS II - Gas Boilerless Convection Steamer PERATION Operating Information Electrical Connection: Make sure unit is plugged into a proper receptacle or wired properly and the breaker for the circuit is on. Water Connection: Make sure the steamer is properly connected to a water source. Do not connect the unit to de-ionized water;... - Page 13 SIRIUS II - Gas Boilerless Convection Steamer Operation NOTICE If the door is open, nothing will happen. Close the door and the steamer will turn on and begin warming up. Door Operation: The door must be closed at all times while cooking. If the door is opened during cooking, the burner will shut down and the amber HEAT light will go off until the door is closed.
- Page 14 Operation SIRIUS II - Gas Boilerless Convection Steamer Blanching Many foods can be blanched in atmospheric steam before being finished in ovens, fryers, or on grills and griddles. This reduces total cooking time, helps ensure complete cooking and a moist product. Potatoes, poultry and seafood are excellent examples.
- Page 15 SIRIUS II - Gas Boilerless Convection Steamer Operation Warnings & Cautions Warnings • Failure to keep the overflow outlets clear and unobstructed may result in hot water flowing out the door of the steamer. A blocked overflow and drain could allow water to flow to the countertop or floor, which can cause slippery conditions. Modifying the steamer to operate without the overflow standpipe could cause dangerous situations and will void the warranty.
-
Page 16: Maintenance
Maintenance SIRIUS II - Gas Boilerless Convection Steamer Maintenance Cleaning Guidelines Daily Cleaning Once the power is off and the reservoir has been drained, a simple cleaning process should be followed: WARNING The cooking chamber is designed to retain heat. It may still be hot to the touch when cleaning. Wear protective gloves, or wait for the surface to cool before cleaning. - Page 17 SIRIUS II - Gas Boilerless Convection Steamer Maintenance Weekly Cleaning In addition to the daily cleaning it is necessary to clean the air intakes on a weekly basis. Air intakes provide necessary cooling air to the internal components. They are generally located on the rear and sides of the equipment. Monthly Cleaning Market Forge recommends using Optipure DSP descaling powder to clean your steamer on a monthly basis or whenever necessary.
- Page 18 SIRIUS II - Gas Boilerless Convection Steamer Notes PAGE OF 20 INSTALLATION & OPERATION MANUAL 14-0268 REV 9 (07/22)
- Page 19 SIRIUS II - Gas Boilerless Convection Steamer Notes INSTALLATION & OPERATION MANUAL 14-0268 REV 9 (07/22) PAGE OF 20...
- Page 20 SIRIUS II - Gas Boilerless Convection Steamer SIRIUS II-(4, 6, 8, 10 & 12) SIRIUS II Gas Boilerless Convection Steamer A product with the Market Forge name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
