Removal and replacement procedures

Modem module cable

✎
The modem module cable is included in the Cable Kit, using the following spare part numbers:
■
583282-001—for use only with HP Compaq 6545b computer models
■
593853-001—for use only with HP Compaq 6540b computer models
■
583957-001—for use only with HP Compaq 6445b computer models
■
593854-001—for use only with HP Compaq 6440b computer models
Before removing the modem module cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Bluetooth module (see
b. Mass storage device (see
c. Optical drive (see
d. Keyboard (see
e. Switch cover (see
f. Fan (see
g. Heat sink (see
h. Palm rest (see
i. TouchPad (see
j. Display assembly (see
k. Top cover (see
l. ExpressCard assembly (see
m. Speaker assembly (see
n. Card reader/USB board (see
o. System board (see
4–80
"Battery" on page
"Bluetooth module" on page
"Mass storage device" on page
"Optical drive" on page
"Keyboard" on page
"Switch cover" on page
"Fan" on page 4-39)
"Heat sink" on page
"Palm rest" on page
"TouchPad" on page
"Display assembly" on page
"Top cover" on page
"ExpressCard assembly" on page
"Speaker assembly" on page
"Card reader/USB board" on page
"System board" on page
4-7).
4-9)
4-11)
4-23)
4-25)
4-33)
4-40)
4-36)
4-38)
4-45)
4-59)
4-68)
4-74)
4-63)
4-72)
