Removal and replacement procedures

Bluetooth module cable

✎
The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth module cable is
included in the Cable Kit, using the following spare part numbers:
■
583282-001—for use only with HP Compaq 6545b computer models
■
593853-001—for use only with HP Compaq 6540b computer models
■
583957-001—for use only with HP Compaq 6445b computer models
■
593854-001—for use only with HP Compaq 6440b computer models
Before removing the Bluetooth module cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Bluetooth module (see
b. Mass storage device (see
c. Optical drive (see
d. Keyboard (see
e. Switch cover (see
f. Palm rest (see
g. TouchPad (see
h. Display assembly (see
i. Top cover (see
4–70
"Battery" on page
"Bluetooth module" on page
"Mass storage device" on page
"Optical drive" on page
"Keyboard" on page 4-25)
"Switch cover" on page
"Palm rest" on page 4-36)
"TouchPad" on page 4-38)
"Display assembly" on page
"Top cover" on page 4-59)
4-7).
4-9)
4-11)
4-23)
4-33)
4-45)
Maintenance and Service Guide
