Summary of Contents for Tascam CD-200i
- Page 1 D01086320B CD-200i CD Player/iPod Dock OWNER'S MANUAL...
-
Page 2: Important Safety Precautions
CAUTION Changes or modifications to this equipment not expressly approved by TEAC CORPORATION for compliance could void the user's authority to operate this equipment. TASCAM CD-200i... -
Page 3: Important Safety Instructions
Wohnbereich Funkstörungen versursachen; in apparatus has been exposed to rain or moisture, diesem Fall kann vom Betrieber verlang werden, does not operate normally, or has been dropped. angemessene Maßnahmen durchzuführen und dafür aufzukommen. TASCAM CD-200i... -
Page 4: Safety Information
If the battery fluid leaks, wipe away any fluid on the battery compartment before inserting new batteries. • Do not disassemble a battery. The acid inside the battery could harm skin or clothing. TASCAM CD-200i... - Page 5 (e) The return and collection systems are available to the end users. For more detailed information about disposal of waste batteries and/or accumulators, please contact your city office, waste disposal service or the shop where you purchased them. TASCAM CD-200i...
-
Page 6: Table Of Contents
Selecting by track number ...... 23 Search forward and backward ....24 Folder playback (with data CDs only) ..24 Selecting the folder ......... 24 Playback modes ..........25 Select the playback mode ....... 25 Programmed playback ......... 25 TASCAM CD-200i... -
Page 7: Introduction
1 − Introduction 1 − Introduction Thank you for your purchase of the TASCAM CD-200i CD Included items Player/iPod Dock. The included items are listed below. Before connecting and using the unit, please take time to read this manual thoroughly to ensure you understand... -
Page 8: Trademarks
About discs In addition to audio CDs (CD-DA), the CD-200i can play CD-R and CD-RW discs on which audio CD, MP3, or WAV TASCAM CD-200i... -
Page 9: Names And Functions Of Parts
Use this standard stereo phones jack to connect stereo When operating the remote control unit (RC-CD200i), headphones. Use a plug adapter when connecting point it towards here. headphones with mini-plugs. PHONES Use the knob to adjust the headphone output level. TASCAM CD-200i... -
Page 10: Ipod Dock
• iPod and AUX IN cannot be selected if devices are not connected to this unit. REPEAT (PITCH ON/OFF) key (CD and iPod) Press this key to cycle through the repeat playback modes in the following order (see “Repeat playback” on page 28.): TASCAM CD-200i... -
Page 11: Rear Panel
• In North America, use only on 120V supply. • When pitch control is ON, digital output signal from CD-200i cannot be received in some equipment. DIGITAL OUTPUT (OPTICAL) jack (CD) This jack outputs the CD playback signal in S/PDIF digital format. -
Page 12: Display
When a fourth-generation iPod or iPod mini is connected, and the output source is set to iPod, the SHUFFLE and REPEAT indicators are not shown on this unit’s display. Check the iPod itself to confirm the iPod’s current playback and repeat mode. TASCAM CD-200i... -
Page 13: Remote Control Unit (Rc-Cd200I)
Press this key to cycle through the sound output sources in the following order (see “Changing the output sound source” on page 20.): PITCH ON/OFF key (CD) Press this key to turn the pitch control function ON and OFF. (See “Pitch control” on page 29.) TASCAM CD-200i... - Page 14 When the output source is set to CD, press this key to stop playback. When the output source is set to iPod, press this key to pause playback. PLAY/READY key (CD and iPod) Press during playback to pause. When playback is stopped or paused, press to start playback. TASCAM CD-200i...
-
Page 15: Preparation For Use
TV Screen (or Widescreen) setting to suit the connected device. The iPod playback sound signal and signals input through the AUX IN jacks can only be output as analog signals. They cannot be output as digital signals. TASCAM CD-200i... -
Page 16: Connecting An Ipod
When the unit’s power is OFF, it does not charge connected iPods. During charging, a battery icon appears on the iPod screen that shows the charging status. Please see the operation manual for the iPod that you are using for details. TASCAM CD-200i... -
Page 17: Opening The Ipod Dock
CAUTION • Do not move the iPod dock left, right, up or down when it is pulled out. • Do not place anything other than an iPod on the iPod dock when it is pulled out. TASCAM CD-200i... -
Page 18: Removing The Ipod
• Before connecting or disconnecting something to the AUX IN jack, set the output source to CD or iPod (not AUX), or turn the CD-200i’s power OFF. TASCAM CD-200i... -
Page 19: Preparing The Remote Control
Operation distance or otherwise be damaged. Please read and abide by the precautions on them when using batteries. Also see Directly in front: Within 7 meters "Cautions about batteries" on page 4. 15° left or right: Within 7 meters TASCAM CD-200i... -
Page 20: Changing The Output Sound Source
PLAY MODE/INTRO CHECK (SOURCE SEL) key SOURCE SEL key By the above operation, the sound output sources will cycle through in the following order: [When the output source is iPod] [When the output source is AUX IN] TASCAM CD-200i... -
Page 21: Playing Back Cds
WAV data format even if they have the ".wav" 00002.mp3 (Track 002) file extension. An Example of Data CD Structure • Discs with 1,000 or more files or 513 or more folders might not play correctly. TASCAM CD-200i... -
Page 22: Loading A Cd
(See If you open the disc tray while this unit is in use, the “Playback modes” on page 25.) following settings are lost. – Program – Current folder (for data CDs) TASCAM CD-200i... -
Page 23: Selecting A Track
The numeric keys cannot be used to select a track when in program or shuffle mode. TASCAM CD-200i... -
Page 24: Search Forward And Backward
• During folder playback, REPEAT ALL plays back all tracks inside the current folder repeatedly. • During folder playback, SHUFFLE plays back all tracks inside the current folder randomly. • During folder playback, only tracks in the current folder can be included in a program. TASCAM CD-200i... -
Page 25: Playback Modes
(SOURCE SEL) key In programmed playback mode, when playback is stopped the total number of tracks in the program and the total program time are shown (total program time is not shown when using a data CD). TASCAM CD-200i... -
Page 26: Setting The Program
PROGRAM EDIT press the key when the empty program step where it is possible to add a track appears. The unit exits program setting mode. • The same track can be added to the program [Data CD] multiple times. TASCAM CD-200i... -
Page 27: Checking The Program
In addition to the above procedure, opening the disc 3 Use the numeric keys or skip (Ô/Â, ¯/) tray also clears the program. keys to select the desired track and press the PROGRAM EDIT key. TASCAM CD-200i... -
Page 28: Repeat Playback
Then, playback continues from the beginning of the disc or current folder. If repeat playback is turned ON when stopped, repeat playback begins when the PLAY/READY key is pushed. TASCAM CD-200i... -
Page 29: Pitch Control
±14.0%. • To turn pitch control playback OFF: REPEAT PITCH ON/OFF Press the ) key while press- DISPLAY SHIFT) ing and holding the key on the PITCH main unit or press the key on the remote con- trol. TASCAM CD-200i... -
Page 30: Intro Check
When pitch control is ON, therefore, some equipment might not be able to receive the digital output signal from the CD-200i. • The pitch control function cannot be used with iPods. PLAY MODE/INTRO CHECK... -
Page 31: Ipod Playback
SOURCE SEL key Controlling an iPod The following keys on the CD-200i front panel and remote Doing this makes it possible to control the iPod from the control (RC-CD200i) can be used to control the iPod. CD-200i front panel and remote control (RC-CD200), as well as to output the iPod’s sound and video signals. -
Page 32: Message Lists
Clean or change the disc. DISC ERR or focus adjustment was not possible. The CD drive hardware is broken. Contact a TEAC repair center. DRV ERR The track cannot be accessed. Clean or change the disc. READ ERR TASCAM CD-200i... -
Page 33: Troubleshooting
Unlock the HOLD switch on the iPod. e Remove the iPod from the iPod dock once and then wait a moment before reconnecting the iPod. e Updating the iPod software frequently resolves problems. Please visit Apple’s website and check for the latest information. TASCAM CD-200i... -
Page 34: Specifications
CD Maximum Output Level: +6 dBV Output Impedance: 200Ω PHONES Jack ª Connector: Standard Stereo Jack Maximum Output Level: 20 mW + 20 mW Load Impedance: 32Ω DIGITAL OUTPUT (OPTICAL) Terminal ª Connector: Optical Jack Compatible Signal Format: IEC-60958 Type II (S/PDIF) TASCAM CD-200i... -
Page 35: General
481 x 94.5 x 298 (mm) / 18.94 x 3.72 x 11.73 (in) Dimensions Illustrations and other depictions may differ in part • from the actual product. Specifications and external appearance may be changed • without notification to improve the product. TASCAM CD-200i... - Page 36 CD-200i TEAC CORPORATION http://tascam.jp/ Phone: +81-42-356-9143 1-47 Ochiai, Tama-shi, Tokyo 206-8530, Japan TEAC AMERICA, INC. http://tascam.com/ Phone: +1-323-726-0303 7733 Telegraph Road, Montebello, California 90640 USA TEAC MEXICO, S.A. de C.V. http://teacmexico.net/ Phone: +52-55-5010-6000 Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacán, CP 04100, México DF, México TEAC UK LIMITED http://tascam.eu/...
