Installation INSTRUCTIONS KK-K9-F14-K

TOOLS REQUIRED:

Power Drill
Drill Bit Set
Standard & Metric Socket Sets
Phillips Screw Driver
Open End Wrench Set

HARDWARE:

QTY: DESCRIPTION:
28
¼" x ½" Stainless carriage bolts
8
¼" x ¾" Stainless carriage bolts
64
¼" flanged serrated nuts
6
¼" x ¾" Hex head cap screw
6
¼" x 1 ½" Hex head lag screw
36
#12 x ¾" Stainless sheet metal screws
24
#10 x ¾" Stainless sheet metal screws
12
#10 x ½" Stainless sheet metal screws
10
#10 x ¾" Stainless machine screws
6
#10 x ¾" Sheet metal screws
1
Tube silver caulk
1
46" x 45 ½" Rubber Floor mat
10
#10 x ½" Flat head sheet metal screws
Read all instructions before installing any Havis-Shields Equipment Corp products.
Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
Use hardware provided with install kit
For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email
524-9900.
K9 TRANSPORTATION SYSTEM
2003-2009 EXPEDITION
Always
Wire Cutters / Crimping tool
Ratcheting Wrench Extension
Torx Bit Set
4 ½" Hole Saw (Exhaust Fan Option)
Caulk Gun
PART #:
GSM32022
GSM32024
GSM30023
GSM33001
GSM33062
GSM34177
GSM34170
GSM34169
GSM34098
GSM33195
PRM97343
KNM01029-SUV
GSM33150
!
technicalsupport@havis.com
or call 1-800-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSM32022 and is the answer not in the manual?

Questions and answers

Summary of Contents for Havis-Shields GSM32022

  • Page 1 46” x 45 ½” Rubber Floor mat #10 x ½” Flat head sheet metal screws Read all instructions before installing any Havis-Shields Equipment Corp products. Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes! Use hardware provided with install kit For product support, visit the Install Instructions Section of our website at http://havis.com/Installation/Installation.html, email...
  • Page 2 Assembled K9 Transportation System for 2003-2009 Ford Expedition Rear of Unit Driver Side Tunnel Rear Support Plate (not shown) Dome Light Location for 11” Fan (PRM97466) Passenger Side Tunnel Mounting Legs & Hold Down Plates Front of Unit KK-K9-F14-K_INST_11-08...
  • Page 3 SUBASSEMBLY: Note: If doors have electric door switches, they must be reattached to original plug assembly. Switch assembly must then be wired-tied down so it does not interfere with window or door latch operations. Remove plastic trim piece. Metal Remove window/lock switch View of Expedition door panel clips hold on trim assembly from door...
  • Page 4 Cut on this line Back seat configuration for Ford Expedition Remove bolt 1. Remove the specified bolt and cut o the line shown lef 2. The upper portion of the c will remain off. 3. Save for vehicle re-sale. Remove trim pieces co vering seat bolts View of current installation...
  • Page 5 Remove plastic storage compartment INSTALLATION: Note: The K9 unit will not slide into rear hatch opening without removing ream d trim panels. Side tunnels must also be removed. 1 Attach floor mounting plates to heig nuts. (Photos 1 and 2) 2.
  • Page 6 . Attach rear support plate to bottom of rear floor lip using ¼” x ¾” hex head bolts. (Photo 3) . Attach top of K9 mounting legs to floor using ¼” floo will line up with ho 6. Loosely attach side tu nnels to main housing using ¼”...
  • Page 7 8. Final Installation Steps: • Mount dome light switch box. A switch box is pr housing in various locations. (At topside of • Wire to 12-volt power source on as preferred. • Sheet metal seams and gaps need to be SI compartment will eliminate water from •...
  • Page 8 KK-K9-F14-K_INST_11-08...
