INSTALL INSTRUCTIONS C-VS-1000-TAH
2007 CHEVY/GMC SUBURBAN/TAHOE/YUKON XL/YUKON
TOOLS REQUIRED:
Ratcheting wrench
Metric/Standard Socket Set
Standard Wrench Set
HARDWARE:
QTY DESCRIPTION
1
OEM switch bracket
4
¼-20 Serrated nut
2
¼-20 x ¾" Hex bolt
2
#10 x ¾" Sheet metal screw
1
Torx screw hardware kit
Switch cutout filler plate
CM001800-4
OEM switch bracket
CM001800-3
VEHICLE SPECIFIC CONSOLE
Power drill w/ 1/8" drill bit (optional)
Screwdriver set
T-20 torx bit
PART #
CM001800-3
GSM30023
GSM33001
GSM33195
C-HK-1
C-VS-1000-TAH
Supplied lighter plugs
