INSTALL INSTRUCTIONS KK-100-05 & KK-120-05 KWIK-KIT PRISONER TRANSPORT INSERT FORD and CHEVY VAN PRISONER TRANSPORT TOOLS REQUIRED: ¼” & 3/8” Ratcheting Wrenches ¼” & 3/8”Air Ratchets (recommended) 3/8” Impact Guns (recommended) ¼” & 3/8” Standard Socket Sets Powered Drill Powered Screwdriver (recommended) Drill Bit Set Tape Measure Screwdriver Set...
Page 2
#10 x ½” Phillips flat head machine screw #10 Thin nylock nut Read all instructions before installing any Havis-Shields Equipment Corp products. Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes! Use hardware provided with install kit For product support, visit the Install Instructions Section of our website at http://havis.com/Installation/Installation.html, email...
Page 3
Rear OEM Trim modifications 1997-2007 Chevrolet G-Series Van Installation of Kwik Kit is very similar in Ford and Chevy Vans. All kits start with a measurement at the rear floor. The rear plastic floor trim on Chevy vans must be cut straight across as shown in photo.
Ford Van Driver-Side rear 8”inches to rear body flange. Note: The OEM rear Black plastic trim will remain. Photos show without Trim. Note: Photos above show a Chevrolet Van. Photos are intended to show rubber floor mat option only. PASSENGER WINDOW VAN PREPARATIONS: 1.
Page 5
Remove clear shrink- wrap covering the prisoner transport assembly. 2. This is the rear 40/60/or 80 section of the kit. Remove all black hardware, wood panels and brackets holding wood panels. Remove bolts holding the kit to the wood pallet. 5.
Page 6
Remove all black hardware from assembled unit. This will give you the subassemblies as they are shown on the following pages. KK-XXX-05_INST_8-07...
Page 7
The following photos are the main subassemblies as they are shipped from the factory. Remove drawing on final page and reference the item #’s as you install this kit. Item #1 Driver Side Bench/Wall/ Front bulkhead wing section Item #4 & 13 (2) - Diamond plate floor Item #8 Passenger-side rear ceiling...
Page 8
Item #12 Item #6 Item #11 Rear bulkhead/door assembly Compartment Compartment ceiling Bulkhead/door assembly KWIK KIT LAYOUT Diamond plate floor and ceiling sections are not shown for detail purposes. KK-XXX-05_INST_8-07...
Page 9
Be sure that all Auxiliary lighting, video systems, Kwik kit options, and wiring are complete. Access is severely limited after kit is installed. If optional rear load light(s) (KK-RLL) was ordered, install at this time. See KK-RLL install instructions Be sure to tape harnesses to roof in approximate locations that accessories are being installed in Kwik kit.
Page 10
Item #1 Item #2 Place Driver-side Bench/Wall Place Passenger-side assembly into van so bench rests Bench/Wall assembly into van so on wheel well bench rests on wheel well Item #3 Item #3 Remove steel support bracket for Remove Emergency Exit Hatch Emergency Exit Hatch pin.
Page 11
Be careful that exposed wires are not touching metal and optional KK- x-VAK hoses are not completely crushed Note: Vent hose will be tight in spots. If hose are crushed to an oval shape the airflow will still be good. Avoid completely crushing hoses. Item #3 Item #4 The floor(s) will square the benches...
Page 12
Item #8 Place Passenger-side Ceiling section into vehicle Do not attach any hardware at this time Item #7 & #8 Slide the ceiling sections out of the way in order to access A/C hoses, wires, etc. Note: These components will be hard to access once ceiling is mounted. Remove all slack from hoses to maximize airflow.
Page 13
Item #10 Place 3 compartment bench Photo shows optional storage door Note: Be careful not to scratch bulkheads. Items #9, #8, & #12 all bolt together VERY IMPORTANT!!! Position 3 compartment ceiling and loosely attach a few ¼” x ¾” hex head bolts and washers where 3 compartment divider and ceiling meet with rear passenger- side ceiling.
Page 14
Item #6 to #5 Item #6 Item #6 Place Rear Bulkhead Position between Driver and Loosely attach Doorframe to Center Doorframe into vehicle Passenger-side Bench/Wall divider using #10 x 3/8” flat head assemblies machine screws and nylock nuts Item #6 to #2 Item #11 Note: It is recommended to put Loosely bolt Rear Bulkhead...
Page 15
Item #6 Item #7, #8, #12 to #3, & #6 Continue around the entire kit bolting An awe or scribe will help Tighten screws holding Rear all Ceiling pieces to Bulkheads and align the holes Doorframe to Center Divider Doorframes using ¼...
Page 16
Top Passenger-Side rear Top Driver-Side rear Item #6 Item #6 3” to 3 1/2” 3” Item #6 Item #6 Item #7 to #1 With unit positioned according to measurements on previous page, pre- Position Driver-side Ceiling section to drill and attach a #10 x 1” sheet metal screw to hold the rear Bulkhead in mate with Bench/Wall assembly.
Page 17
Be careful when pre- drilling not to hit hoses, wires, etc… Note: Ceiling is behind wall Pre-drill ceiling with 5/32” drill bit and attach #10 x 1” Phillips pan head sheet metal screws to hold Ceiling to Bench/Wall assembly. Repeat these steps on the Passenger-side Ceiling section Item #5 through #8 into #7 Pre-drill through Ceiling sections, (using...
Page 18
On the Rear doorframe, remove the sheet metal screws installed earlier. Drill 3/8” holes through the doorframe, floor, and vehicle. Attach using 3/8” x 2” hex head bolts, washers, fender washers, lock washers, and hex nuts. Item #6 to van floor Item #11 to van floor 3/8”...
Page 19
Socket Item #14 to doors and frames Attach Ball & Socket Style Doorstop. Attach “Ball” portion of assembly. Attach to threaded hole on the door using a ¼” x 1” Hex head bolt. 2 Attach the “Socket” and bracket portion. Attach to doorframe using #8 x ¾” Phillips machine screws and keps nuts.
