INSTALL INSTRUCTIONS KK-K9-F14-K-PT
K9/PRISONER TRANSPORTATION SYSTEM
HARDWARE:
QTY: DESCRIPTION:
28
¼-20 x ½" Stainless carriage bolt
8
¼-20 x ¾" Stainless carriage bolt
64
¼-20 flanged serrated nut
6
¼-20 x ¾" Hex head cap screw
6
¼" x 1 ½" Hex head lag screw
36
#12 x ¾" Stainless sheet metal screw
24
#10 x ¾" Stainless sheet metal screw
12
#10 x ½" Stainless sheet metal screw
10
10-32 x ¾" Stainless machine screw
6
#10 x ¾" Sheet metal screw
1
Tube silver caulk
1
46" x 45 ½" Rubber Floor mat
10
#10 x ½" Flat head sheet metal screw
1
¼" Lexan shield/PT front partition
Read all instructions before installing any Havis-Shields Equipment Corp products.
Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
Use hardware provided with install kit
For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email
1-800-524-9900.
2003-2009 FORD EXPEDITION
Always
PART #:
GSM32022
GSM32024
GSM30023
GSM33001
GSM33062
GSM34177
GSM34170
GSM34169
GSM34098
GSM33195
PRM97343
KNM01029-SUV
GSM33150
KNM001220
!
technicalsupport@havis.com
or call
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Havis-Shields K9/Prisoner Transportation System KK-K9-F14-K-PT
Summary of Contents for Havis-Shields K9/Prisoner Transportation System KK-K9-F14-K-PT
- Page 1 #10 x ½” Flat head sheet metal screw ¼” Lexan shield/PT front partition Read all instructions before installing any Havis-Shields Equipment Corp products. Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes! Use hardware provided with install kit For product support, visit the Install Instructions Section of our website at http://havis.com/Installation/Installation.html, email...
- Page 2 FORD EXPEDITION K9/PT COMBO KIT Upper passenger side filler panel ¼” Lexan shield Driver-side tunnel Rear floor mount bracket Rear passenger Lower passenger side filler panel Floor mounting side filler panel plates and legs Front passenger Upper “B”-pillar side filler panel mounting bracket Lower passenger-side mounting foot...
- Page 3 Remove plastic trim piece. Metal Remove window/lock switch View of Expedition door panel clips hold on trim assembly from door Remove hex head screws holding Remove trim piece covering torx Remove plastic door panel lower section of door panel screws under door panel armrest and remove screws Remove window switch and Recommended location for switch...
- Page 4 2006-2008 FORD EXPEDITION DOOR Cut on this line Back seat configuration for Ford Expedition Leave passenger-side rear seat Remove bolt 1. Remove the specified bolt and cut on the line shown left. 2. The upper portion of the cut piece will remain off.
- Page 5 Note: Mounting plate straddles a ridge in the floor. When bolts are tightened the plate will form to the floor. 7 ¾” Sub-assemble mounting leg to Attach assembly to vehicle Attach assembly to K9 floor mounting plate using ¼” x ¾” using OEM seat hardware and using ¼”...
- Page 6 Place front partition filler panel View of assembly at this time into vehicle as shown above Position front partition as Remove “B” pillar upper trim Position ¼” lexan shield shown and attach to K9 panel. Remove seat belt bolt Using holes in partition mark and housing assembly drill shield Attach using ¼”...
- Page 7 Attach “B” pillar mounting Grab handle removed Install “B” pillar mounting bracket to front partition using bracket using bolts that hold ¼” x ¾” carriage bolts and nuts grab handle. (Re-installing the grab handle is optional) Attach ceiling filler panel to View of ceiling filler Install ceiling filler panel to front partition using ¼”...
- Page 8 Location where ceiling filler bolts to rear partition Attach front partition to vehicle using 6” L-mounting bracket. Bolt bracket to partition using ¼” x ¾” carriage bolts and nuts. Bolt “L” mounting bracket to vehicle using ¼” x 1” Lag bolts.
- Page 9 Hinge up window guard and reattach to bracket with 10-32 x ½” Stainless machine screws and #10 Flat washers. NOTE: Door panel fillers are provided for the Expedition EL. This is not used for the standard length Expedition. K9 / PT unit installation complete. Shown with emergency sliding door open between K9 and Prisoner compartment.
