Specifications - NetComm NF2 Product Data Sheet

SPECIFICATIONS

PACKAGE INCLUDES
• 1 x NF2
• Power Adapter
• Printed Quick Start Guide
• Ethernet Cable (RJ-45)
• Wireless Security Card
• Warranty Card
• Dual Band WiFi antenna
ENVIRONMENTAL AND PHYSICAL
• Operating temperature: 0-40 C, Humidity: 10%-90%
o
non-condensing
• Storage temperature: -10-70 o C, Humidity: 0%-95%
non-condensing
• Dimensions: 130mm (L) x 33mm(W) x 190mm(H)
• DC Input Voltage 12V/2A
DEVICE INTERFACE
• 1 x 10/100/1000Mbps WAN port
• 3 x 10/100/1000Mbps LAN ports
• 2 x USB 2.0 ports – for 3G/4G USB Modem and
USB storage devices
• 1 x power button
• 1 x WPS button
• 1 x reset button
• 2x3 internal WiFi antennas (1 x external antenna)
• LED - 3G/4G signal / Internet connection / Link / WAN /
LAN 1-3 / WiFi / Power
• Power Jack
WIRELESS WAN
• 1 x USB 2.0 port for external 3G/4G modem
• GPRS/EDGE/WCDMA/HSDPA/HSUPA/ C DMA2000/
EVDO/LTE
ETHNERNET WAN
• 1 x WAN port (10/100/1000 Mbps)
• PPPoE, DHCP client, Static IP, PPTP, L2TP
• Auto-reconnect, dial-on demand, manual connect
WIRELESS
• IEEE 802.11n. Backwards compatible with IEEE
802.11b/g/a
• 2.4GHz & 5GHz Concurrent WiFi
• SSID broadcast or in stealth mode
• Auto/Manual Channel selection
• WEP/WPA/WPA-PSK/WPA2/WPA2-PSK
• WPS button (WiFi Protected Setup)
NAS
• File sharing
• DLNA
SECURITY
• IP/Service Filter
• URL blocking
• MAC control
• DoS (Denial of Service) Protected
ROUTING
• Static Route
• Dynamic Route (RIP v1/v2)
• DMZ
ADMINISTRATION
• UPnP • IGD • Syslog
• Web-based UI • QoS • Remote Login
• Backup/Restore Settings • SNMP
• TR-069 auto provisioning
• VPN IPSec, L2TP client/server, PPTP client/server
COMPLIANCE
• C-Tick
NetCommWireless
NETCOMM WIRELESS LIMITED
Head Office - 18-20 Orion Road, Lane Cove,
NSW 2066, Sydney, Australia ABN 85 002 490 486
E: sales@netcommwireless.com
Trademarks and registered trademarks are the property of NetComm Wireless Limited or their respective owners. Specifications are subject to change without notice. Images shown may vary slightly from the actual product.
Dual Band WiFi Gigabit Hub
3 WAYS TO CONNECT
3G/4G USB Modem
USB File Share
(Music, movies, photos and documents)
Concurrent Dual Band Local WiFi
Using the latest wireless technology, the NetComm NF2 gives you
maximum range and maximum speed.
The NF2 features concurrent dual band WiFi giving you two powerful WiFi networks with a
combined speed of up to 900Mbps. With two networks running on two unique frequencies you
can prioritise different devices between the two networks. Enjoy maximum speed and range for
streaming video, music and transferring other bandwidth intensive files around your home or office.
Choose how you connect:
ADSL: Give your ADSL modem a boost and connect the NF2 to create your own powerful and
secure WiFi network
Fibre: Future proof your Internet. The NF2 is designed for NBN's Fibre broadband. When you
get NBN's Fibre service to your premises, switch the NF2 straight to your Fibre service.
3G/4G: The NF2 works with your 3G or 4G USB modem, which means you can create your
own WiFi hotspot wherever you have mobile coverage.
Wired devices are also supported with three high-speed Ethernet ports that can be used t o
connect NAS boxes, media servers or any Ethernet device; you can also connect a U SB Hard
drive and turn it into a network storage drive, accessible from all devices on y our network.
1 M aximum wireless signal rate and coverage values are derived from IEEE Standard 802.11g and 802.11n Draft 2.0
specifications. Actual wireless speed and coverage are dependent on network and environmental conditions included but
not limited to volume of network traffic, building materials and construction/layout.
www.netcommwireless.com
NetCommWirel NetCommWirel
or or
ADSL/Cable
(ADSL/Cable modem required)
3 x Gigabit Wired Connections
(Computers, game consoles, media centres etc)
(Laptops, tablets, portable gaming etc)
PRODUCT DATASHEET
FIBRE
Fibre
