Package Includes; Environmental And Physical; Device Interface; Wifi And Wireless Wan - NetComm NF5 Specifications

SPECIFICATIONS

PACKAGE INCLUDES:

• N300 WiFi Gigabit Router with Voice
• Power Adapter
• Ethernet Cable (RJ-45)
• Phone Cable (RJ-11)
• Wireless Security Card • Warranty Card

ENVIRONMENTAL AND PHYSICAL

• Operating temperature: 0-40°C,
Humidity: 10%-90% non-condensing
• Storage temperature: -10-70°C, Humidity: 0%-95%
non-condensing
• DC Input Voltage 12V/1.5A

DEVICE INTERFACE

• 1 x RJ45 port (Blue) 10/100/1000 Mbps
• 4 x RJ45 port (Yellow) 10/100/1000 Mbps,
• 1 x RJ11 port (Grey), FXS for regular phone set
• 1 x WPS/Reset Button
• 1 x USB 2.0 (black) for external HSPA modem and
file sharing
• Power button • Power Jack
• LED (Power/USB/WAN/LAN1-LAN4/WiFi/Phone)
WIRELESS WAN
• 1 x USB 2.0 Port for external 3G/4G modem
• PPP (for WCDMA / HSPA)
• Automatic 3G Failover function
WIFI
• Unique Wireless SSID and encryption key
• IEEE 802.11n. Compatible with IEEE 802.11b/g/a
• SSID broadcast or in stealth mode
• Auto/Manual Channel selection
• WEP/WPA/WPA-PSK/WPA2/WPA2-PSK
• WPS button (WiFi Protected Setup)
ETHERNET WAN
• 1 x Gigabit WAN port (10/100/1000 Mbps)
• PPPoE, DHCP client, Static IP, PPTP, L2TP
FUNCTIONALITY
IPV6 SUPPORT
o Static IPv6 o PPPOE
o DHCPv6 o Dual Stack IPv6
VOIP
PROTOCOL
o SIP 2.0 o T.38 FAX Relay
VOICE COMPRESSION
o G.711-Alaw voice compression
o G.711-Mulaw voice compression
o G.726-32 voice compression
o G.729AB voice compression
o G.168 116 ms tail line echo cancellation
CALL FUNCTION
o Call forward o Caller ID
o Call waiting o 3-way conference call
SECURITY
• IP/Service Filter • URL blocking
• MAC control
• DoS (Denial of Service) Protected
ROUTING
• Static Route
• Dynamic Route (RIP v1/v2)
• DMZ • DDNS
• IPTV IGMPv1/v2/v3 snooping and filtering,
• VLAN tagged/ Untagged frames
• Jumbo Frame
• VPN Passthrough (PPTP/L2TP/IPSec)
ADMINISTRATION
• SNMP • UPnP
• IGD • Syslog
• Web-based UI • Remote Login
• TR-069/TR-064 Auto provisioning
• Backup/Restore Settings
• QoS: Support QoS mechanism for prioritizing
the various type of traffics, TOS/DSCP to 802.1p
mapping (DiffServ)
STORAGE
• Storage/File Sharing: FAT16/FAT32, EXT2, NTFS
• Samba server, FTP server
• Supports DLNA
NetCommWireless
NETCOMM WIRELESS LIMITED
Head Office - 18-20 Orion Road, Lane Cove,
NSW 2066, Sydney, Australia ABN 85 002 490 486
E: sales@netcommwireless.com
Trademarks and registered trademarks are the property of NetComm Wireless Limited or their respective owners. Specifications are subject to change without notice. Images shown may vary slightly from the actual product.
N300 WiFi Gigabit
Router with Voice
ADSL/Cable
(ADSL/Cable
modem required)
USB File Share
(Music, movies, photos
and documents)
The NetComm Wireless NF5 is a future ready WiFi router that connects the home
or office to super-fast broadband. Simply connect your fixed line modem to the
Gigabit WAN port for instant Internet access - perfect for NBN/Fibre connections
The advanced network sharing function gives multiple users the freedom to watch
movies, download music, play online games and enjoy other bandwidth intensive
activities such as IPTV streaming on a single broadband account.
Enjoy extended WiFi coverage with high-speed WiFi N, or connect up to four
wired devices via the Gigabit Ethernet ports. The device also features a USB
2.0 port for external hard drive storage or an alternate Internet source with a
compatible 3G/4G USB modem. The VoIP phone port allows users to make
phone calls over the Internet, making a phone line completely redundant and
cutting phone costs.
The NF5 is also kind to the environment with innovative green features for power
conservation. With support for IPV6, users are ensured that their router will be
able to continue to access websites when new web addressing starts becoming
a commonplace.
* Maximum wireless signal rate and coverage values are derived from IEEE Standard 802.11g and 802.11n specifications. Actual
wireless speed and coverage are dependent on network and environmental conditions included but not limited to volume of
network traffic, building materials and construction/layout.
www.netcommwireless.com
NetCommWirel
or or
FIBRE
NBN 3G/4G
USB Modem
PRODUCT DATASHEET
VoIP
Make phone calls over the Internet
4 x Wired
Gigabit Connections
(Computers, game consoles,
media centres etc)
