Mounting instruction
Notes
To prevent unconnected leads from shorting out, insulate
them by wrapping their tips with electrical tape. Similarly,
insulate the ends of connected leads.
If an external amplifier is to be connected to the receiver,
be sure to ground its outside housing to the vehicle body
(a metal part).

Names of lead wires and destinations

No. Name
1 ACC
2 B+
3 Ground
4 Antenna power supply Blue
5 Lamp power supply
6 Control power supply
7 E-LAN terminal
8 & 9 Line-out terminals
10 Line-out terminals (Nonfader)
11 Cellular phone mute
12 Eclipse Commander terminal
13 Digital out terminals
14 Line in terminal (for MP3)
100
(refer to Page 102)
Wire color Destination
Red Connect where the power comes on
when the ignition is in the ACC
position.
Yellow Connect where power is constantly
available, regardless of the ignition
switch's position.
Black Connect where good body grounding
is available.
Connect to the automatic-antenna
control terminal of the vehicle.
Orange/White Connect to where power comes on
when the headlights are turned on.
Blue/White Connect to the control terminal for the
external amplifier, etc.
Connect to the E-LAN terminal of the
CD changer, DSP, etc.
Connect to the RCA input connectors
of an external amplifier.
Connect to the RCA input connectors
of a DSP or EQ, or the RCA input
connectors of a woofer amplifier.
Pink Connect to the ground output terminal
on a mobile phone.
Connect to the Eclipse Commander
module.
Connect to digital terminals of the
Eclipse Commander module.
Connect to the mini plug
output connector of MP3 unit.
(φ3.5)
