Mounting instruction
Names of lead wires and destinations (refer to Page 68)
Caution
Never connect the power supply to the speaker leads,
otherwise it cause damage to the main unit.
Note
To prevent unconnected leads from shorting out, insulate them
by wrapping their tips with electrical tape. Similarly, insulate the
ends of connected leads.
If an external amplifier is to be connected to the receiver, be
sure to ground its outside housing to the vehicle body (a metal
part).
No.
Name
1
ACC
2
B+
3
Ground
4
Antenna power supply Blue
5
Illumination power supply Orange/White
6
Control power supply Blue/White
7 & 8
Line-out terminals
9
Speaker terminals
10
Cellular phone mute
Wire color
Destination
Red
Connect where the power comes on
when the ignition is in the ACC
position.
Yellow
Connect where the power is
constantly available, regardless of the
ignition switch's position.
Black
Connect
grounding is available.
Connect to the automatic-antenna
control terminal of the vehicle.
Connect to where power comes on
when the headlights are turned on.
Connect to the control terminal for
the external amplifier turn on.
Connect to the RCA input connectors
of an external amplifier.
Connect them to their respective
speaker leads.
Pink
Connect to the ground output
terminal on a mobile phone.
66
where
good
body
