Owner's Manual — Phoenix R125 LGR Dehumidifier
The Phoenix R125 is the first 65 pint LGR Dehumidifier. The
R125 offers high quality restoration drying performance in the
WTRDHM category at entry-level pricing. The Phoenix R125
utilizes new patent-pending LGR technology that produces
maximum grain depression and removes water long after
conventional dehumidifiers stop. As a result, structures,
contents and materials dry quicker, allowing you to get to your
next job faster. At only 79 lbs. and with a compact 20"W x
17"D footprint, the R125 fits virtually anywhere you need to
dry.
The Phoenix R125 LGR Dehumidifier
LGR Performance in a 79 lb, 20" x 17" footprint
Removes 65 pints at AHAM drawing only 5.0 amps
Focused Airflow Outlet directs air downward across the
wet surface
Accommodates 10" layflat ducting
Rugged Roto-mold Plastic Housing resists dents and
scratches
Solid State Control Panel
Protected Recessed Condensate Hose that cannot catch
or be damaged on obstructions
Heavy-duty rotating handle for ease of transport and
storage
Recessed 12" Wheels
Pleated Media MERV-7 Filter; Optional MERV-11
Convenient Front Pocket for cord and hose storage
Specifications subject to change without notice.
Toll-Free 1-800-533-7533
4201 Lien Rd. • Madison, WI 53704
Installation, Operation & Service Instructions
Read and Save These Instructions
Product Support Questions: Contact Phoenix at 800-533-7533
Sales Inquiries: Contact Sylvane at (800) 934-9194 or visit sylvane.com
The Phoenix R125 combines Phoenix innovation, technical
expertise, and proven durability into a small, portable, and
durable roto-mold housing. In addition to the R125's compact
size and superior performance, the unit features high energy
efficiency, front cord and hose storage, a ductable outlet, a
pleated media filter, and a rotating handle for easy transport
and storage.
Phoenix R125
Part No. 4032350
Patent 7,246,503
7,281,389
7,540,166
1
www.UsePhoenix.com • sales@UsePhoenix.com
TS-716
02/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phoenix R125

Summary of Contents for Phoenix R125

  • Page 1: Introduction

    Owner’s Manual — Phoenix R125 LGR Dehumidifier Installation, Operation & Service Instructions Read and Save These Instructions The Phoenix R125 is the first 65 pint LGR Dehumidifier. The The Phoenix R125 combines Phoenix innovation, technical R125 offers high quality restoration drying performance in the expertise, and proven durability into a small, portable, and WTRDHM category at entry-level pricing.

  • Page 2: Table Of Contents

    The units should be properly secured for transport. The Phoenix R125 must always be upright when transported by • DO NOT use the Phoenix R125 as a bench or table. vehicle. It may be tipped onto its handle and back for loading •...

  • Page 3: Electrical Requirements

    3.2 Electrical Requirements 3.6 POWER Button The Phoenix R125 plugs into a common grounded outlet on a 15 amp circuit. It draws 5.0 amps at 80°F, 60% RH. If used in a wet area, a ground fault interrupter (GFI) is required. If...

  • Page 4: Maintenance

    4.1 Air Filter air conditioner’s to remove heat and moisture from incoming The Phoenix R125 is equipped with a pleated media air filter air and to add heat to the air that is discharged. that must be checked regularly. The standard filter is a MERV- Hot, high pressure refrigerant gas is routed from the 7 high efficiency filter.

  • Page 5: Troubleshooting

    Unit runs but does not pump water. 5.2 Troubleshooting 1. Hose kinked or plugged No dehumidification, neither hour meter display nor compressor run and POWER button does not turn ON. 2. Pump motor defective 1. Unit unplugged or no power to outlet 3.

  • Page 6: Air Mover

    5.3 Air Mover 5.5 Condensate Pump The motorized impeller has a PSC motor and internal thermal The internal condensate pump removes water that overload protection. If defective, the complete assembly must collects in the reservoir. be replaced. To replace the condensate pump: 1.

  • Page 7: Wiring Diagram

    7 Wiring Diagram Wiring diagram Toll-Free 1-800-533-7533 www.UsePhoenix.com • sales@UsePhoenix.com...

  • Page 8: Service Parts

    8 Service Parts Items listed are not shown Description Part No. Item Description Part No. Hose (1/4” ID x 33’ long) 4024916 Top Cover 4031258 Coupling Body, 1/4” Tube 4024910 Filter, 12” x 12” x 1” 4026315 Coupling Insert, 1/4” Tube 4027277 Impeller, Air Mover 4031384...

  • Page 9: Warranty

    (but all warranty periods will be extended by the period of time, if any, that the Phoenix R125 Dehumidifier is out of service while awaiting covered warranty service).
