Owner's Manual — 200 HT LGR Dehumidifier
The Phoenix 200 HT features LGR (low grain refrigerant) technology. This technology enables the 200 HT to remove more
water and create more grain depression than standard refrigerant dehumidifiers.
Combined with this performance, the multiple ducting and the superior high temperature performance makes the Phoenix
200 HT the most effective and versatile drying device made.
The Phoenix 200 HT
LGR Dehumidifier
In-Board Wheels - Reduces outer dimensions for
tighter storage setups and does not catch on
obstructions for easier movement around the jobsite.
Recessed Condensate Hose - Does not catch on
obstructions and allows for dense storage setups by
reducing overall width of the unit.
Patented Bypass Technology
Increased Capacity - The Phoenix 200 HT removes 5%
more water than the 200 MAX.
Improved High-Ambient Performance - Patent pending
technology allows superior efficiency in high-ambient
conditions.
Focused Airflow - Patent pending focused outlet directs
air toward the most wet surface.
335 CFM - More processed air speeds drying and
provides superior static pressure for ducting.
More Grain Depression - The driest air from an LGR
gets your jobs drier quicker.
Air Filter - A MERV- is standard.
Multiple Ducting Options - 2" intake, 0" exhaust.
Energy Efficiency - Draws 7.5 amps.
Skid Plate - Protects the 200 HT from damage while
transporting, loading and unloading.
Specifications subject to change without notice.
Toll-Free 1-800-533-7533
PO Box 8680 • Madison, WI 53708
Installation, Operation and Service Instructions
Read and Save These Instructions
Phoenix 200 HT
PN 4025900
Patent 7,246,503

www.usephoenix.com • sales@thermastor.com
Patented
BYPASS
TS-302
Revised 10/07
