Owner's Manual — Phoenix 4800 E
Industrial Desiccant Dehumidifier
Congratulations on your purchase of the Phoenix 4800E
dehumidifier. This dehumidifier offers the finest in air-drying
equipment. However, this machine can only provide maximum
service and performance if properly installed, operated and
maintained.
This owner's manual is provided to acquaint you with the
dehumidifier so that the installation, operation and maintenance
can proceed successfully. Ultimate satisfaction depends on the
quality of the installation and thorough understanding of the
operation of this equipment. The dehumidifier is built around
tested engineering principles and has passed a thorough
inspection for quality of workmanship and function.
• 3032 pints/day AHAM
• 4800 CFM process airflow
• Dries in temperatures to 140ºF
• Reaches dew points as low as -40ºF
Specifications subject to change without notice.
Toll-Free 1-800-533-7533
4201 Lien Rd. • Madison, WI 53704
Installation, Operation & Service Instructions
Read and Save These Instructions
Phoenix 4800E
(without Frame)
PN 4029191
The Phoenix 4800 E
• 48"W x 120"L x 74"H
• 1600 lbs. (Standard
machine weight only)
• 480 volt 3-phase
• 106 full load amps
1
www.UsePhoenix.com • sales@UsePhoenix.com
Phoenix 4800E
(with Frame)
PN 4028003
TS-451d 06/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4800 E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phoenix 4800 E

Summary of Contents for Phoenix 4800 E

  • Page 1: Introduction

    Industrial Desiccant Dehumidifier Installation, Operation & Service Instructions Read and Save These Instructions Congratulations on your purchase of the Phoenix 4800E dehumidifier. This dehumidifier offers the finest in air-drying equipment. However, this machine can only provide maximum service and performance if properly installed, operated and maintained.

  • Page 2: Table Of Contents

    Read the operation and maintenance instructions carefully a sealed air stream (process). After the desiccant has before using this unit. Proper adherence to these instructions is essential to obtain maximum benefit from your Phoenix 4800E. Toll-Free 1-800-533-7533 www.UsePhoenix.com • sales@UsePhoenix.com...

  • Page 3: How The Phoenix 4800E Works

    (drying chamber) and returns dried, processed air to the affected area via the Process Air Outlet. The Phoenix 4800E has two separate air streams that run through it – Process and Reactivation (Fig. 1). The Reactivation Air Inlet and Outlet are both ducted to the outdoors (or left open if the unit is set up outside).

  • Page 4: Ducting

    3.5 Avoiding Secondary Damage 3) Verify Selector Switch is set to STANDBY. The Phoenix 4800E is a powerful tool capable of removing 4) Engage Power Source and turn Main Disconnect to ON. a great deal of water from most environments. Care must...

  • Page 5: Cool Down

    Cool Down 5.5 Alarm (Light and Horn) 1) Set Selector Switch to STANDBY. The alarm indicator lamp illuminates (and horn sounds) to indicate that a fault condition exists. The fault conditions 2) COOL DOWN light will come on for 5 minutes. could be: 3) When COOL DOWN light is off, Main Disconnect can be •...

  • Page 6: Blower And Motor

    DO NOT operate the unit without the filters or with less Servicing the Phoenix 4800E with its high voltage effective filters as the desiccant wheel inside the unit will circuitry presents a health hazard which could result in become clogged and require disassembly to clean.

  • Page 7: Wiring Diagram

    7 Panel Layout/Wiring Diagram Toll-Free 1-800-533-7533 www.UsePhoenix.com • sales@UsePhoenix.com...
  • Page 8 7 Panel Layout/Wiring Diagram 480V 3Ø 60HZ INCOMING POWER LL1 LL2 LL3 POWER DISTRIBUTION NON-FUSED DISCONNECT 200 AMP BRANCH PROTECTION SUPPLIED **(BY OTHERS)** 105 FLA LARGEST MOTOR 7.5HP LARGEST HEATER 24KW FIELD DETERMINE #8 AWG PER PHASE #8 AWG PER PHASE TYPE MTW TYPE MTW 90 DEG C COPPER...
  • Page 9 7 Panel Layout/Wiring Diagram Toll-Free 1-800-533-7533 www.UsePhoenix.com • sales@UsePhoenix.com...

  • Page 10: Troubleshooting

    9 Troubleshooting 8 Trouble Shooting Trouble Probable Fault Probable Cause Corrective Action Unit Stopped Power/Control 1. Main power off Check main power and cable (fan off, no Failure 2. Main disconnect open Close or replace disconnect heater) 3. Selector switch open Close or replace switch 4.

  • Page 11: Detailed Sequence Of Events

    9 Detailed Sequence of Events a) ALARM lamp illuminates. b) Alarm horn sounds. – Control Operation c) Terminals 3080 and X2 energize. These terminals can be utilized for an external alarm (1 amp maximum). 1) Turning on Main Disconnect at dehumidifier provides d) Time relay TR1 starts the 5 minute heater cool 480 VAC, 3 phase power to the control panel.

  • Page 12: Service Parts List

    10 Service Parts Item Part No. Qty. Description 4027228 Blower, Reactivation, 460V, 5HP 4027229 Blower, Process, 460V, 7.5HP 4028630 Probe, Thermocouple, Type J, 12” 4028633 Heating Element, 24KW 4020175 Dehumidistat 4028771 Temperature Controller with Control Output Board, Relay SPST 4032306 Control Box 4030198 Fusa 2A...

  • Page 13: Warranty

    Phoenix 4800 Limited Warranty Warrantor: Therma-Stor LLC 4201 Lien Rd Madison, WI 53704 Telephone: 1-800-533-7533 Who Is Covered: This warranty extends only to the original end-user of the 4800 and may not be assigned or transferred. First Year Warranty: Therma-Stor Products warrants that, for one (1) year the 4800 will operate free from any defects in materials and workmanship, or Therma-Stor Products will, at its option, repair or replace the defective part(s), free of any charge.
