Pulsar W671 User Manual

Digital quartz
Hide thumbs
Table of Contents

Advertisement

Quick Links

CAL. W626, W671
DIGITAL QUARTZ
Time/calendar
Stopwatch
Countdown timer
with preset and adjustable timer functions
Daily alarm
Auto illumination function (Cal. W671)
Illuminating light

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W671 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar W671

Summary of Contents for Pulsar W671

  • Page 1 CAL. W626, W671 DIGITAL QUARTZ Time/calendar Stopwatch Countdown timer with preset and adjustable timer functions Daily alarm Auto illumination function (Cal. W671) Illuminating light...

  • Page 2: Mode Change

    Cal. W626 MODE CHANGE TIME/ STOPWATCH CALENDAR mode mode With each press, the mode changes in order. ALARM TIMER mode mode...
  • Page 3 Cal. W626 TIME/CALENDAR MODE Date Month TIME display CALENDAR display SHOWING THE CALENDAR DISPLAY Press to show CALENDAR display. * Month, date and day are displayed for 5 seconds, and then, the watch automatically returns to the TIME display.

  • Page 4: Time/Calendar Setting

    Cal. W626 TIME/CALENDAR SETTING Press for 2 to 3 seconds. Select the digits to be adjusted. Set the flashing digits. Return to TIME/CALENDAR mode. Selection of the digits Seconds Minutes Hour Date 12-/24-hour indication Year Month...

  • Page 5: Stopwatch Mode

    Cal. W626 STOPWATCH MODE The stopwatch measures up to 100 hours in 1/100 second increments for the first 1 hour and in 1 second increments thereafter. Start / Stop / Restart Reset / Split / Split release Split time measurement * Measurement and release of split time can be repeated by...
  • Page 6 Cal. W626 Measurement of two competitors FINISH TIME FINISH TIME START RESET OF 1ST COMPETITOR OF 2ND COMPETITOR FINISHES COMPETITOR...

  • Page 7: Timer Mode

    Cal. W626 TIMER MODE Two types of timer are available: preset timer and adjustable timer. The adjustable timer can be set up to 60 minutes in minute increments. PRESET TIMER SETTING Select the preset time. Selection of the preset time 3 min.
  • Page 8 Cal. W626 Return to TIMER mode. TIMER OPERATION Start / Stop / Restart Reset * When the set time is up, a warning sound beeps for 5 seconds. To stop it manually, depress any one of the buttons.

  • Page 9: Alarm Mode

    Cal. W626 ALARM MODE ALARM SETTING Press for 2 to 3 seconds. Select the digits to be adjusted (hour/minutes). Set the flashing digits. Return to ALARM mode. * The alarm is automatically engaged.
  • Page 10 Cal. W626 Alarm engagement/disengagement Alarm engaged With each press, the alarm is Alarm mark engaged and disengaged alternately. “on” mark Turning on/off of hourly time signal and button operation confirmation sound Hourly time signal mark With each press in TIME/ CALENDAR mode, the hourly time signal and button operation confirmation sound are turned...
  • Page 11 Cal. W671 MODE CHANGE TIME/ STOPWATCH CALENDAR mode Mode mode mark With each press, the mode changes in order. ALARM TIMER mode mode...

  • Page 12: Time/Calendar Mode

    Cal. W671 TIME/CALENDAR MODE Month Date TIME/CALENDAR SETTING Press for 2 to 3 seconds. Select the digits to be adjusted. Set the flashing digits. Return to TIME/CALENDAR mode. “A” (AM)/ “P” (PM) mark Selection of the digits Seconds Minutes Hour...
  • Page 13 Cal. W671 AUTO ILLUMINATION FUNCTION When AUTO ILLUMINATION FUNCTION is turned on: The display is illuminated with each press of a button to operate the watch. While the stopwatch or timer is counting, the display is illuminated every minute to signal the lapse of time: For the first 19 minutes in the stopwatch function and for the last 19 minutes in the timer function.
  • Page 14 Cal. W671 STOPWATCH MODE The stopwatch measures up to 10 hours in 1/100 second increments. Start / Stop / Restart Current time Time measured Reset / Measure lap time Lap time measurement Lap No. START STOP RESET Lap time...
  • Page 15 Cal. W671 MEMORY RECALL FUNCTION The stored data can be recalled either during or after the measurement. Press to activate the memory recall function. ** With each press, stored data are recalled from the oldest to the newest. Return to STOPWATCH mode.
  • Page 16 Cal. W671 TIMER MODE Two types of timer are available: preset timer and adjustable timer. The adjustable timer can be set up to 9 hours and 59 minutes in minute increments. PRESET TIMER SETTING Set time Select the preset time.
  • Page 17 Cal. W671 Select the digits to be adjusted (hour/minutes). Set the flashing digits. Return to TIMER mode. TIMER OPERATION Start / Stop / Restart Reset * When the set time is up, a warning sound beeps for 5 seconds. To stop it manually, depress any one of the buttons.
  • Page 18 Cal. W671 ALARM MODE ALARM SETTING Current time Press for 2 to 3 seconds. Select the digits to be adjusted (hour/minutes). Set the flashing digits. Return to ALARM mode. * The alarm is automatically engaged. “A” (AM)/ “P” (PM) Set alarm time...
  • Page 19 Cal. W671 Alarm engagement/disengagement Alarm engaged With each press, the alarm is Alarm mark engaged and disengaged alternately. “on” mark Turning on/off of hourly time signal and button operation confirmation sound Hourly time With each press in TIME/ signal mark...

  • Page 20: Illuminating Light

    Cal. W626 Cal. W671 ILLUMINATING LIGHT Turn on the illuminating light. The display panel is illuminated for 3 seconds.

  • Page 21: Notes On Using The Watch

    The flashing digits except the seconds and 12-/24-hour indication (and on/off of auto illumination function for Cal. W671) move quickly if button D is kept pressed. Once the year, month and date have been set, the day of the week is automatically set.
  • Page 22 TIME/CALENDAR mode, and then set the time/calendar again. STOPWATCH MODE Notes for Cal. W671: 1) Lap time measured and lap number remain displayed for 10 seconds, and then, the current time appears in the upper row of the display.
  • Page 23 2) If button D is pressed while the time set for the adjustable timer is displayed, the set time will be canceled. Notes for Cal. W671: 1) After the countdown is repeated 99 times, the number of times the countdown is repeated is displayed in 2 digits such as “00”...
  • Page 24 Cal. W626 Cal. W671 4) If the timer is left counting without being stopped, it will automatically be stopped and reset to show the set time when more than 12 hours passed and the time display reaches 0:00 a.m. or 0:00 p.m.

  • Page 25: Battery Change

    3 times a day, the confirmation sound more than 24 times a day and/or the auto illumination more than 30 times a week (only for Cal. W671). As the battery is inserted at the factory to check the function and performance of the watch, its actual life once in your possession may be less than the specified period.
  • Page 26 Cal. W626 Cal. W671 appears, follow the procedure below to reset the IC. Cal. W626 Cal. W671 Press and hold buttons A, B, C and D at the same time for 2 to 3 seconds. The display shown at right appears.

  • Page 27: To Preserve The Quality Of Your Watch

    WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
  • Page 28 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...

  • Page 29: Periodic Check

    Cal. W626 Cal. W671 SHOCKS & VIBRATION PERIODIC CHECK Light activities will not It is recommended that the affect your watch, but be watch be checked once careful not to drop your 2 - 3 every 2 to 3 years. Have...

  • Page 30: Static Electricity

    Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
