Summary of Contents for Pulsar W510
- Page 1 CAL. W510 DIGITAL QUARTZ Time/calendar Single-time alarm Regular alarm Illuminating light (electroluminescent panel)
- Page 2 MODE CHANGE With each press, the mode changes in the following order: TIME/ SINGLE-TIME REGULAR CALENDAR ALARM ALARM...
-
Page 3: Time/Calendar Mode
TIME/CALENDAR MODE TIME/CALENDAR SETTING Hour Press to show TIME/ CALENDAR mode. Press for 2 to 3 seconds. Select the digits to be adjusted. Set the flashing digits. Return to TIME/CALENDAR Minutes mode. - Page 4 Selection of the digits Minutes Hour Date Month * If the flashing “ – – ” is shown in the middle row of the display, the digits indicate the time, and otherwise, they indicate the calendar. SHOWING THE CALENDAR DISPLAY Press and hold in TIME/ Month CALENDAR mode.
- Page 5 SINGLE-TIME ALARM MODE The single-time alarm can be set to ring only once at the designated time. As it rings, it is automatically disengaged. The single-time alarm can be set in minute increments starting from the current time. SINGLE-TIME ALARM SETTING Hour Press to show SINGLE-TIME ALARM mode.
- Page 6 * At the designated time, the single-time alarm rings for 20 seconds. To stop it manually, press any of the buttons. To cancel the single-time alarm you have set, press buttons C and D at the same time in the SINGLE-TIME ALARM mode, or press button C or D to set the alarm time to the current time.
- Page 7 REGULAR ALARM MODE The regular alarm can be set to ring on a 24-hour basis. Press to show REGULAR ALARM mode. REGULAR ALARM SETTING Regular alarm Hour mark Press for 2 to 3 seconds. Set the desired alarm time. Return to REGULAR ALARM mode.
- Page 8 ENGAGEMENT/DISENGAGEMENT OF REGULAR ALARM AND HOURLY TIME SIGNAL Regular alarm mark With each press in REGULAR ALARM mode, the engagement/disengagement of the regular alarm and hourly time signal are made as follows: Both engaged Regular alarm engaged Neither engaged Hourly time signal engaged Hourly time signal mark * At the designated time, the regular alarm rings for 20 seconds.
-
Page 9: Illuminating Light (Electroluminescent Panel)
ILLUMINATING LIGHT (Electroluminescent panel) Turn on the illuminating light. * The display panel is evenly illuminated for 3 seconds. ViViDiGi is a new type of liquid crystal panel that makes possible various colors and high contrast. Excellent light reflection and transmission make the display bright and clear. Various color options are available. -
Page 10: Notes On Using The Watch
NOTES ON USING THE WATCH MODE CHANGE The displayed numerals have unique forms. The positions where they are shown on the display, therefore, shift between both sides of the display, depending on the numeral shown. If the watch is left untouched in the SINGLE-TIME ALARM and REGULAR ALARM mode, it will automatically return to the TIME/CALENDAR mode in 2 to 3 minutes. - Page 11 is displayed. For the AM setting, there is no indication. As button “A” is pressed to return to the TIME display, the second digits are automatically reset to “00” and start counting immediately. (See “ Setting the seconds” explained above) If the watch is left untouched with the digits flashing, it will automatically return to the TIME/CALENDAR mode in 1 to 2 minutes.
- Page 12 If the watch is left untouched in the SINGLE-TIME ALARM mode, it will automatically return to the TIME/CALENDAR mode in 2 to 3 minutes. The single-time alarm rings differently from the regular alarm. REGULAR ALARM MODE If the watch is left untouched in the REGULAR ALARM mode, it will automatically return to the TIME/CALENDAR mode in 2 to 3 minutes.
-
Page 13: Battery Change
ILLUMINATING LIGHT (Electroluminescent panel) The electroluminescent panel loses its luminance as the battery voltage gets lowered. Also, its luminance level decreases gradually with use. After 120 hours of use, the level decreases by about half. When the illuminating light becomes dim, replace the battery with a new one. If the light remains dim after the battery is replaced, have the electroluminescent panel replaced with a new one by the retailer from whom the watch was purchased. - Page 14 When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children.
-
Page 15: To Preserve The Quality Of Your Watch
WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely. - Page 16 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...
-
Page 17: Periodic Check
2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact. -
Page 18: Static Electricity
Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
