Pulsar W621 Manual

Digital quartz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAL. W621
DIGITAL QUARTZ
Time/calendar
Stopwatch with 8 lap memory
Countdown timer with preset and adjustable
timer functions
Daily alarm
Stroke function
Electroluminescent panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W621 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar W621

Summary of Contents for Pulsar W621

  • Page 1 CAL. W621 DIGITAL QUARTZ Time/calendar Stopwatch with 8 lap memory Countdown timer with preset and adjustable timer functions Daily alarm Stroke function Electroluminescent panel...
  • Page 2 MODE CHANGE Mode mark (No mode mark in TIME/CALENDAR mode) Change modes TIME/CALENDAR STOPWATCH STROKE ALARM TIMER...

  • Page 3: Time/Calendar Mode

    TIME/CALENDAR MODE TIME/CALENDAR SETTING Press for 2 to 3 seconds. Select the digits to be adjusted. Set the flashing digits. Return to TIME/CALENDAR mode. Selection of the digits Seconds Minutes Hour Date Year Month 12-/24-hour indication...

  • Page 4: Stopwatch Mode

    STOPWATCH MODE The stopwatch measures up to 10 hours in 1/100 second increments. Start / Stop / Restart Current time Time measured Reset / Measure lap time Lap time measurement • • • • START STOP RESET...
  • Page 5 MEMORY RECALL FUNCTION The stored data can be recalled either during or after the measurement. Press to activate the memory recall function.** With each press, stored data are recalled from the oldest to the newest. Return to STOPWATCH mode. **In memory recall after measurement, the oldest data in memory is displayed.

  • Page 6: Stroke Mode

    STROKE MODE The number of strokes per minute is automatically calculated by measuring the time required to make three strokes. Press to start measurement. Press to stop measurement when the third stroke is made. * The number of strokes per minute will be displayed.

  • Page 7: Timer Mode

    TIMER MODE Two types of timer are available: preset timer and adjustable timer. PRESET TIMER SETTING Select the preset time. Selection of the preset time 3 min. 5 min. 10 min. 15 min. 20 min. 45 min. 40 min. 35 min. 30 min.

  • Page 8: Timer Operation

    Select the digits to be adjusted (hour/minutes). Set the flashing digits. Return to TIMER mode. TIMER OPERATION Start / Stop / Restart No. of times Time measured the countdown is repeated Reset * When the set time is up, a warning sound beeps for 5 seconds. To stop it manually, press any one of the buttons.

  • Page 9: Alarm Mode

    ALARM MODE ALARM SETTING Press for 2 to 3 seconds. Select the digits to be adjusted (hour/minutes). Set the flashing digits. Return to ALARM mode. * The alarm is automatically engaged. Alarm engagement/disengagement Engage/disengage the alarm Alarm “on” mark engaged Alarm mark [...

  • Page 10: Illuminating Light (Electroluminescent Panel)

    Turning on/off of hourly time signal and button operation confirmation sound With each press in TIME/CALENDAR mode, hourly time signal and confirmation sound are turned on and off alternately. Hourly time signal mark [ ILLUMINATING LIGHT (Electroluminescent panel) * The display panel is illuminated for 3 seconds.
  • Page 11 ViViDiGi is a new type of liquid crystal panel that makes possible various colors and high contrast. Excellent light reflection and transmission make the display bright and clear. Various color options are available. Either the whole panel or the displayed data only can be illuminated. * Features vary in different models.

  • Page 12: Notes On Using The Watch

    NOTES ON USING THE WATCH MODE CHANGE If the stopwatch is not reset to “00” and button A is pressed to change the mode from the STOPWATCH, the TIMER mode appears, skipping the STROKE mode. When the confirmation sound is turned on, a beep sounds with each press of button A to change over the mode.
  • Page 13 buttons C and D are pressed at the same time. This is not a malfunction. Press any one of the buttons to return to the TIME/CALENDAR mode, and then set the time/calendar again. STOPWATCH MODE Lap time measured and lap number remain displayed for 10 seconds, and then, the current time appears in the upper row of the display.
  • Page 14 STROKE MODE The time required to make each stroke is measured up to 9 seconds and 99 in 1/100 second increments. The measurable number of strokes per minute is between 18 and 240. The stroke and stopwatch functions cannot be used simultaneously. If the measurement is stopped within 0.75 seconds after it is started, “- - -”...
  • Page 15 If button D is pressed while the time set for the adjustable timer is displayed, the set time will be canceled and the preset time of 3 minutes will be shown. Restart and stop of the timer can be repeated by pressing button C. After the countdown is repeated 99 times, the number of times the countdown is repeated is displayed in 2 digits such as “00”...
  • Page 16 When the hourly time signal mark is displayed, the hourly time signal rings every hour on the hour and the confirmation sound beeps with each press of the buttons. ILLUMINATING LIGHT (electroluminescent panel) The electroluminescent panel loses its luminance as the battery voltage gets lowered. Also, its luminance level decreases gradually with use.

  • Page 17: Battery Change

    When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Battery life indicator When all the digits start flashing, have the battery replaced with a new one as soon as possible.
  • Page 18 Press and hold buttons A, B, C and D at the same time for 2 to 3 seconds. The display shown below appears. * Before using the watch, set the time/calendar and alarm. WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children.

  • Page 19: To Preserve The Quality Of Your Watch

    WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
  • Page 20 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...

  • Page 21: Periodic Check

    2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact.

  • Page 22: Static Electricity

    Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
