Summary of Contents for Pulsar w863
- Page 1 CAL. W863 DIGITAL QUARTZ l Full-panel dot-matrix liquid crystal panel Time/calendar Stopwatch with memory recall function Countdown timer 3-channel regular alarm World time Illuminating light (LED panel) Auto illumination...
-
Page 2: Mode Change
MODE CHANGE ILLUMINATING LIGHT (LED pANEL) l Selection of a desired mode can be made by pressing and holding button A for more than two seconds. Press to turn on the LED light. The display panel is evenly illuminated for 2 seconds. AUTO ILLUMINATION l If set in advance, the display is illuminated for approximately 2 seconds with each press of any of the buttons (except pressing... -
Page 3: Time/Calendar Setting
TIME/CALENDAR SETTING TIME/CALENDAR MODE (TIME) Press and hold for 2 seconds to show TIME/CALENDAR l Once the time/calendar of your area is set in the TIME/CALENDAR SETTING display. mode, the times of the 33 cities in the WORLD TIME mode will be set automatically. -
Page 4: Key Sound Setting
STOpWATCH MODE (CHRONO) CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME l The stopwatch measures up to 9 hours, 59 minutes and 59.99 seconds in 1/100 second increments. If the daylight saving time is effective in the selected city, press to show the daylight saving time. -
Page 5: Stopwatch Operation
CHANGEOVER BETWEEN LAP TIME AND SPLIT TIME STOPWATCH OPERATION Lap number Split time Press and hold for more than 2 seconds to change over Lap time and Press to start the stopwatch. Split time. LAP/SPLIT 1 Press to take a lap time. LAP/SPLIT 2 Lap time STOPWATCH... -
Page 6: Memory Recall Mode
MEMORY RECALL MODE HOW TO DELETE THE CHANNEL l The first 100 lap and split times are automatically stored in memory. Press and hold for 2 seconds to l The stored data can be recalled either during or after the measurement. delete the selected channel data. Press until the watch enters MEMORY RECALL mode. Press and hold for 2 seconds Show the desired channel again to delete all the stored data. number. (Moves forward) Show the desired channel number. (Moves backward) -
Page 7: Timer Mode
TIMER MODE TIMER SETTING l The timer can be set from 1 minute up to 59 minutes 59 seconds in Press for 2 seconds to show TIMER SETTING display. one-second increments. The minute digits start flashing. Press to show TIMER mode. Set the flashing digits. -
Page 8: Timer Operation
ALARM MODE TIMER OpERATION l The alarm can be set to ring daily at three different times per day. Start / Stop / Restart Set time Press until the watch enters ALARM mode. Alarm channel Timer mark Reset While the timer is counting, TIMER mark is flashing. When the set time is up, a warning sound beeps for 10 seconds. -
Page 9: Alarm Time Setting
ALARM TIME SETTING ALARM ENGAGEMENT/DISENGAGEMENT l The alarms can be engaged and disengaged independently of one Press to select the desired alarm channel (from AL-1 to AL-3). another. Press to select the desired alarm channel (from AL-1 to AL-3). Press for 2 seconds to show ALARM SETTING display. With each pressing, the selected alarm is engaged and disengaged Press to select the digits to be adjusted (hour/minute). -
Page 10: World Time Mode
WORLD TIME MODE CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME If the daylight saving time is effective in the selected city, press to l The time of 33 cities in different time zones throughout the world can be displayed. show the daylight saving time. - Page 11 GMT± (hours) City mark City name GMT ± (hours) City mark City name Country name Country name B E R Berlin* Germany Japan T Y O Tokyo A T H Athens* Greece Australia + 9.5 A D L Adelaide* C A I Cairo Egypt Sydney*...
-
Page 12: Notes On Using The Watch
NOTES ON USING THE WATCH Notice on change of Moscow time zone Moscow had previously been in a time zone that was 3 hours ahead of GMT/UTC. TIME/CALENDAR MODE However, since 2011, Moscow has shifted to a time zone that is 4 hours ahead of [TIME/CALENDAR SETTING] GMT/UTC. - Page 13 STOpWATCH MODE MEMORY RECALL mode l If no measurement is made, “ - - - - ” mark will be displayed when button A is l After 9 hours, 59 minutes and 59.99 seconds have been measured, the stopwatch pressed to show the memory recall display. stops.
-
Page 14: Battery Change
When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. l We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Battery life indicator When the battery voltage becomes low, the battery mark starts flashing on the dis-... -
Page 15: To Preserve The Quality Of Your Watch
3 bar, such as acci- cause battery leakage or damage to the battery. We recommend that you wear a PULSAR Diver’s dental contact with splashes of water or rain, but it watch for scuba diving. - Page 16 TEMPERATURES SHOCKS & VIBRATION * Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the crown is pushed in completely. Light activities will not Operational temperature Do not operate the crown when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
-
Page 17: Periodic Check
Have your watch a ff e c t e d b y s t a t i c checked by an AUTHOR- electricity which may IZED PULSAR DEALER or SER- disturb the display. Keep the VICE CENTER to ensure that the...
