CAL. W850
DIGITAL QUARTZ
Full-panel dot-matrix liquid crystal panel
Time/calendar
5-channel regular alarm
10-hour stopwatch with memory recall function
Countdown timer
with preset and adjustable timer functions
World time
Button operation confirmation light
Illuminating light (electroluminescent panel)
Changeover between normal and enlarged displays

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W850 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar W850

Summary of Contents for Pulsar W850

  • Page 1 CAL. W850 DIGITAL QUARTZ Full-panel dot-matrix liquid crystal panel Time/calendar 5-channel regular alarm 10-hour stopwatch with memory recall function Countdown timer with preset and adjustable timer functions World time Button operation confirmation light Illuminating light (electroluminescent panel) Changeover between normal and enlarged displays...

  • Page 2: Mode Change

    MODE CHANGE Selection of a desired mode can be made by pressing the corresponding button in the MENU display. STOPWATCH ALARM mode mode TIMER mode TIME/ WORLD TIME CALENDAR mode mode [MENU display] * When the desired mode is selected, the opening graphic display is shown before the selected mode appears.
  • Page 3 CHANGEOVER BETWEEN NORMAL AND ENLARGED DISPLAYS In all modes, the display can be selected between the normal display that shows all the data with characters of a normal size and the enlarged display that shows the main data with characters of an enlarged size. With each press, the normal and enlarged displays alternately appear.

  • Page 4: Time/Calendar Mode

    TIME/CALENDAR MODE Once the time/calendar of your area is set in the TIME/CALENDAR mode, the times of the 38 cities covered in the WORLD TIME mode will be set automatically. Changeover between the standard time and daylight saving time can be made. Press in MENU display to show TIME/CALENDAR mode.

  • Page 5: Time/Calendar Setting

    TIME/CALENDAR SETTING Press for 2 to 3 seconds to show TIME/CALENDAR SETTING display. Press to select the digits to be adjusted. Selection of the digits Standard time/ C i t y Seconds Minutes Hour daylight saving time 12-/24-hour indication Year Month Date Set the flashing digits.
  • Page 6 SHOWING THE SELECTED CITY Press to show the city selected for TIME/CALENDAR mode. * The name of the selected city is displayed in place of the day, scrolls from right to left, and then the day is displayed again. TURNING ON/OFF OF HOURLY TIME SIGNAL AND BUTTON OPERATION CONFIRMATION SOUND With each press, the hourly time signal and sound for button operation...

  • Page 7: Demonstration Function

    DEMONSTRATION FUNCTION Provided with a demonstration function, the watch shows the displays in each mode. Press for 3 seconds in TIME/CALENDAR mode to start the demonstration. * The name of the selected city appears in place of the day, and then the demonstration display will start, showing the display of each mode repeatedly.

  • Page 8: Alarm Mode

    ALARM MODE The alarm can be set to ring daily at five different times a day. The alarms can be engaged and disengaged independently of one another. Press in MENU display to show ALARM mode. Current time Set alarm time “ON”...

  • Page 9: Alarm Time Setting

    ALARM TIME SETTING Press to select the desired alarm channel (Ch.-1 – Ch.-5). Press for 2 to 3 seconds to show ALARM SETTING display. Press to select the digits to be adjusted (hour/minutes). Set the flashing digits. (Increasing digits) Set the flashing digits. (Decreasing digits) Return to ALARM mode.
  • Page 10 ALARM ENGAGEMENT/DISENGAGEMENT The alarms can be engaged and disengaged independently of one another. Press to select the desired alarm channel (Ch.-1 – Ch.-5). With each press, the selected alarm is engaged and disengaged alternately. * At the designated time, the alarm rings for 20 seconds.

  • Page 11: Stopwatch Mode

    STOPWATCH MODE The stopwatch measures up to 10 hours in 1/100 second increments. Press in MENU display to show STOPWATCH mode. Start / Stop / Restart Current time Time measured Measure lap & split time / Reset Lap time and split time measurement •...
  • Page 12 MEMORY RECALL FUNCTION The first 199 lap and split times are automatically stored in memory. The stored data can be recalled either during or after the measurement. Press to activate the memory recall function .* With each press, stored data are recalled from the oldest to the newest.

  • Page 13: Timer Mode

    TIMER MODE Two types of timer are available: 10-channel preset timer and adjustable timer. The adjustable timer can be set up to 9 hours and 59 minutes in minute increments. Press in MENU display to show TIMER mode. Current time Set time...
  • Page 14 PRESET TIMER SETTING Press to select the desired preset time. Selection of the preset time/adjustable timer 1 min. ⇔ 2 min. ⇔ 3 min. ⇔ 4 min. ⇔ 5 min. ⇔ 10 min. Adjustable timer ⇔ 1 hour ⇔ 45 min. ⇔ 30 min. ⇔ 15 min. ADJUSTABLE TIMER SETTING Press to select the adjustable timer.

  • Page 15: Timer Operation

    Set the flashing digits. (Increasing digits) Set the flashing digits. (Decreasing digits) Return to TIMER mode. TIMER OPERATION Start / Stop / Restart No. of times Time measured the countdown is repeated Reset * When the set time is up, a warning sound beeps for 5 seconds. To stop it manually, press any of the buttons.

  • Page 16: World Time Mode

    WORLD TIME MODE The time of 38 cities in different time zones throughout the world can be displayed together with their respective country code for overseas telephone call. Press in MENU display to show WORLD TIME mode. Country code Current time of selected city City mark Press to select the desired city.
  • Page 17 * In the normal display, the daylight saving time (summer time) mark, country code, time and city name are shown. CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME If the daylight saving time is effective in the selected city, press to show the daylight saving time.
  • Page 18 City name Country name Country code City mark ± (hours) Berlin* Germany B E R Athens* Greece A T H C A I Cairo* Egypt Jerusalem* Israel J R S M O W Moscow* Russia J E D Jeddah Saudi Arabia R U H Riyadh Saudi Arabia...
  • Page 19 City name Country name Country code City mark ± (hours) A D L Adelaide* Australia + 9.5 Sydney* Australia S Y D + 10 N O U Noumea New Caledonia + 11 W L G Wellington* New Zealand + 12 Honolulu U.S.A.

  • Page 20: Illuminating Light (Electroluminescent Panel)

    ILLUMINATING LIGHT (Electroluminescent panel) Turn on the illuminating light. * The display panel is evenly illuminated for 3 seconds. TURNING ON/OFF OF BUTTON OPERATION CONFIRMATION LIGHT “EL” With each continuous press for 2 to 3 mark seconds, the button operation confirmation light is alternately turned on and off.

  • Page 21: Notes On Using The Watch

    NOTES ON USING THE WATCH TIME/CALENDAR MODE [TIME/CALENDAR SETTING] The calendar automatically adjusts for odd and even months including February of leap years from 1998 to 2047. Once the year, month and date have been set, the day of the week is automatically set. Setting the seconds: •...
  • Page 22 “15”. The contrast becomes higher as the digits indicating the contrast level increase and becomes lower as they decrease. The contrast level has been initially set at “10” at the factory. When the contrast level is set to “0”, the digits on the display will be unable to read. With each press of buttons C and E, the contrast level increases and decreases by one, respectively.
  • Page 23 Measurement of the lap time and split time can be repeated by pressing button E. The lap number counts up to “199”. After “199”, the number is displayed in two digits such as “00” for 200, “01” for 201, and so on. The lap time and split time measured remain displayed for 10 seconds together with the flashing lap number.
  • Page 24 TIMER MODE The timer counts down the set time repeatedly up to 10 times unless stopped. [ADJUSTABLE TIMER SETTING] The flashing digits move quickly if button C or E is kept pressed. If the watch is left untouched with the digits flashing, it will automatically return to the TIMER mode in 2 to 3 minutes.

  • Page 25: Battery Change

    When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Battery life indicator When all the digits start flashing, have the battery replaced with a new one as soon as possible.
  • Page 26 Press and hold buttons A, B, C and E at the same time for 2 to 3 seconds. The display will become blank, and the MENU display will appear when the buttons are released. Then, press button A. “TIME 1-JAN A12:00'00" THU” will be displayed. * Before using the watch, set the time/calendar and alarm.

  • Page 27: To Preserve The Quality Of Your Watch

    WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
  • Page 28 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...

  • Page 29: Periodic Check

    2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact.

  • Page 30: Static Electricity

    Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
