- Page 1 CAL. W540 DIGITAL QUARTZ Dot-matrix liquid crystal panel Time/calendar 5-channel memo function World time...
- Page 2 MODE CHANGE With each press, the mode changes in the following order: TIME/ MEMO WORLD TIME CALENDAR...
-
Page 3: Time/Calendar Mode
TIME/CALENDAR MODE Once the time/calendar of your area is set in the TIME/CALENDAR mode, the times of the 33 cities covered in the WORLD TIME mode will be set automatically. * To display the times of the cities covered in the WORLD TIME mode properly, it is necessary to select the city representing your area and set the correct time in the TIME/CALENDAR mode. -
Page 4: Time/Calendar Setting
TIME/CALENDAR SETTING Press for 1 to 2 seconds to show TIME/CALENDAR SETTING display. Press to select the digits to be adjusted. Selection of the digits Seconds Minutes Hour Year 12-/24-hour Date Month City indication Set the flashing digits. (Increasing digits) Set the flashing digits. - Page 5 SHOWING CALENDAR DISPLAYS With each press in TIME/CALENDAR mode, the display changes in the following order: [ Day display ] [ Time display ] [ Month & date display ] Month Date MEMO DEMONSTRATION The memo registered in the memo channel No. 1 can be shown in TIME/ CALENDAR mode.
-
Page 6: Memo Mode
MEMO MODE A memo of up to 40 characters can be stored in each of the 5 memo channels. Press to show MEMO mode. Mode name Memo channel No. Memo Press to select the desired memo channel. CH–1 CH–4 CH–5 CH–2 CH–3 * The memo scrolls once, and then, its first three characters remain displayed. - Page 7 With each press, restart and stop of the scroll are made alternately. HOW TO INPUT THE MEMO Press to select the desired memo channel. Press for 1 to 2 seconds to show MEMO INPUT display. With each press, the flashing character changes in order. With each press, the flashing character changes in reverse order.
- Page 8 * To correct the characters already registered, follow the procedure below. 1) Press button A for 1 to 2 seconds to return to the MEMO mode. 2) Press button A for 1 to 2 seconds to show the MEMO INPUT display. 3) Press button A to move the flashing position so that the character you wish to correct flashes.
-
Page 9: World Time Mode
WORLD TIME MODE The time of 33 cities in different time zones throughout the world can be displayed. Daylight saving time can be set for each city. Press to show WORLD TIME mode. “A” (AM)/“P” (PM) in the 12-hour indication Mode mark City mark Current time of... - Page 10 CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME Press for 1 to 2 seconds. With each press, the standard time and daylight saving time of the selected city are alternately shown. Daylight saving time mark...
-
Page 11: Time Differences
TIME DIFFERENCES GMT = Greenwich Mean Time (As of April 2000) City City City name City name ± (hours) ± (hours) mark mark ± 0 London* S I N Singapore P A R Paris* T Y O Tokyo M I L Milan* S E L Seoul... - Page 12 ViViDiGi is a new type of liquid crystal panel that makes possible various colors and high contrast. Excellent light reflection and transmission make the display bright and clear. Various color options are available. Either the whole panel or the displayed data only can be illuminated. * Features vary in different models.
-
Page 13: Notes On Using The Watch
NOTES ON USING THE WATCH MODE CHANGE When the mode is changed over, the mode name or mark to indicate the selected mode scrolls from the top to the bottom, and then, the display for the mode scrolls from right to left. - Page 14 B or C is kept pressed. If the watch is left untouched with the digits flashing, it will automatically return to the TIME/CALENDAR mode in 1 to 2 minutes. Note on unusual display: While setting the time/calendar, all the segments of the display will light up if both buttons B and C are pressed at the same time.
- Page 15 MEMO mode in 1 to 2 minutes. The flashing character changes quickly if button B or C is kept pressed. Characters for the memo input and the order of appearance: A B C D E F G H I J K L M N O P Q R S T U V W X Y Z 1 2 3 4 5 6 7 8 9 0 ! ? @ # + / = % ~ ' "...
-
Page 16: Battery Change
When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Necessary procedure after battery change After the battery is replaced with a new one or if an abnormal display (broken digits, etc.) - Page 17 WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children. If a child swallows it, consult a doctor immediately. Never short-circuit, tamper with or heat the battery, and never expose it to fire.
-
Page 18: To Preserve The Quality Of Your Watch
WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely. - Page 19 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...
-
Page 20: Periodic Check
2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact. -
Page 21: Static Electricity
Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
