Pulsar W522 Manual

Digital quartz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAL. W522
DIGITAL QUARTZ
Dot-matrix liquid crystal panel
Time/calendar
8-channel memo function
World time
Regular alarm and single-time alarm
Illuminating light (electroluminescent panel)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W522 and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar W522

Summary of Contents for Pulsar W522

  • Page 1 CAL. W522 DIGITAL QUARTZ Dot-matrix liquid crystal panel Time/calendar 8-channel memo function World time Regular alarm and single-time alarm Illuminating light (electroluminescent panel)
  • Page 2 MODE CHANGE With each press, the mode changes in the following order: REGULAR TIME/ MEMO WORLD TIME ALARM CALENDAR Press in TIME/CALENDAR mode to show SINGLE-TIME ALARM mode.

  • Page 3: Time/Calendar Mode

    TIME/CALENDAR MODE Once the time/calendar of your area is set in the TIME/CALENDAR mode, the times of the 24 cities covered in the WORLD TIME mode will be set automatically. * To display the times of the cities covered in the WORLD TIME mode properly, it is necessary to select the city representing your area and set the correct time in the TIME/CALENDAR mode.

  • Page 4: Time/Calendar Setting

    TIME/CALENDAR SETTING Press for 2 to 3 seconds to show TIME/CALENDAR SETTING display. Press to select the digits to be adjusted. Selection of the digits Seconds Minutes Hour Year Month 12-/24-hour City Date Contrast indication level Set the flashing digits. (Increasing digits) Set the flashing digits.

  • Page 5: Demonstration Function

    CHANGEOVER BETWEEN TWO TIME DISPLAY SYSTEMS With each press in TIME/CALENDAR mode, the time indication in the lower row of the display changes alternately between “HOUR, MINUTES and SECONDS” and “HOUR and MINUTES”. DEMONSTRATION FUNCTION Press in TIME/CALENDAR mode to start the demonstration. * The watch shows the displays in each mode.

  • Page 6: Memo Mode

    MEMO MODE A memo of up to 40 characters can be stored in each of the 8 memo channels. Press to show MEMO mode. Memo channel No. Memo Press to select the desired memo channel.
  • Page 7 SCROLL DISPLAY OF MEMOS If the memo stored in a memo channel has more than 6 characters, the display scrolls to show the rest of the characters. The display scrolls to show 5 characters at a time. The scrolling display can be stopped or moved back as desired.
  • Page 8 HOW TO INPUT THE MEMO Press to select the desired memo channel. Press for 2 to 3 seconds to show MEMO INPUT display. With each press, the flashing character changes in order. With each press, the flashing character changes in reverse order. When the desired character is shown, press to register it.
  • Page 9 * To correct the characters already registered, press button E or F to move the flashing position so that the character you wish to correct flashes. Then, press button C or D to show the desired character, and press button E or F to register it. HOW TO ERASE A MEMO Press to select the desired memo channel.

  • Page 10: World Time Mode

    WORLD TIME MODE The time of 24 cities in different time zones throughout the world can be displayed. Daylight saving time can be set for each city. Press to show WORLD TIME mode. City mark Current time of selected city Press to select the desired city.
  • Page 11 CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME Press for 2 to 3 seconds. With each press, the standard time and daylight saving time of the selected city are alternately shown. Daylight saving time mark...

  • Page 12: Time Differences

    TIME DIFFERENCES GMT = Greenwich Mean Time (As of April 2000) City City City name City name ± (hours) ± (hours) mark mark ± 0 London* S Y D Sydney* + 10 P A R Paris* N O U Noumea + 11 + 12 R O M...
  • Page 13 REGULAR ALARM MODE The regular alarm can be set to ring on a 24-hour basis. Press to show REGULAR ALARM mode. “ON”/“OFF” mark Set alarm time...
  • Page 14 REGULAR ALARM SETTING Press for 2 to 3 seconds to show REGULAR ALARM SETTING display. Press to select the digits to be adjusted (hour/minutes). Set the flashing digits. (Increasing digits) Set the flashing digits. (Decreasing digits) Return to REGULAR ALARM mode. * “ON”...
  • Page 15 ENGAGEMENT/DISENGAGEMENT OF REGULAR ALARM AND HOURLY TIME SIGNAL Hourly time Regular With each press, the engagement and signal mark alarm mark disengagement of the regular alarm and hourly time signal are made as follows: Both engaged Regular alarm engaged Neither engaged Hourly time signal engaged * At the designated time, the regular alarm rings for 20 seconds.
  • Page 16 SINGLE-TIME ALARM MODE The single-time alarm can be set to ring only once at the designated time. As it rings, it is automatically disengaged. The single-time alarm can be set in minute increments starting from the current time. Press in TIME/CALENDAR mode to show SINGLE-TIME ALARM mode. Set alarm time Current time...
  • Page 17 SINGLE-TIME ALARM SETTING Press to set the desired alarm time. (Increasing digits) Press to set the desired alarm time. (Decreasing digits) Return to TIME/CALENDAR mode. * The single-time alarm mark “1-AL” remains displayed to indicate that the single-time alarm has been set. Single-time alarm mark * At the designated time, the single-time alarm rings for 20 seconds.

  • Page 18: Illuminating Light (Electroluminescent Panel)

    ILLUMINATING LIGHT (Electroluminescent panel) Turn on the illuminating light. * The display panel is evenly illuminated for 3 seconds. ViViDiGi is a new type of liquid crystal panel that makes possible various colors and high contrast. Excellent light reflection and transmission make the display bright and clear. Various color options are available.

  • Page 19: Notes On Using The Watch

    NOTES ON USING THE WATCH MODE CHANGE The design of the liquid crystal panel differs depending on the model. When the mode is changed over, the display of the selected mode scrolls from right to left. TIME/CALENDAR MODE [TIME/CALENDAR SETTING] The calendar automatically adjusts for odd and even months including February of leap years from 2000 to 2050.
  • Page 20 of button C or D while the hour and minute digits are flashing. In the 12-hour indication, only “PM” mark is displayed and there is no indication for the AM setting. In the 24- hour indication, “24H” is displayed. The flashing digits except the seconds and 12-/24-hour indication move quickly if button C or D is kept pressed.
  • Page 21 WORLD TIME MODE To display the times of the cities covered in the WORLD TIME mode properly, it is necessary to select the city representing your area and set the correct time in the TIME/ CALENDAR mode. [CHANGEOVER BETWEEN STANDARD TIME AND DAYLIGHT SAVING TIME] When the daylight saving time is set for the city selected in the TIME/CALENDAR mode, the current time is advanced by one hour.
  • Page 22 SINGLE-TIME ALARM MODE When button C or D is pressed to set the single-time alarm, the single-time alarm mark “1-AL” is displayed and the single-time alarm is automatically engaged. If the watch is left untouched in the SINGLE-TIME ALARM mode, it will automatically return to the TIME/CALENDAR mode in 1 to 2 minutes.

  • Page 23: Battery Change

    When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Necessary procedure after battery change After the battery is replaced with a new one or if an abnormal display (broken digits, etc.)
  • Page 24 level, and hour and minute display in the TIME/CALENDAR mode” when the buttons are released. * Before using the watch, set the time/calendar and alarms. WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children.

  • Page 25: To Preserve The Quality Of Your Watch

    WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
  • Page 26 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...

  • Page 27: Periodic Check

    2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact.

  • Page 28: Static Electricity

    Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
