- Page 1 SUBMERSIBLE PUMP SUBMERSIBLE PUMP GSE RANGE OPERATION & MAINTENANCE INSTRUCTIONS 0507...
-
Page 2: Guarantee
Service@clarkeinternational.com Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machines data plate... -
Page 3: Table Of Contents
Features • Continuously rated, fitted with overload protection. • Corrosion resistant stainless steel casing. • Cast iron impeller and base for long and reliable service. Contents Guarantee ..................2 Specifications .................. 3 Safety Precautions ................4 Electrical Connections ..............5 Operation .................. -
Page 4: Safety Precautions
An approved Residual Current Device (RCD) MUST be used when pumping from ponds or swimming pools. ● Your submersible pump may ONLY be used for pumping water from a swimming pool when there is no person or animal in the pool. ●... -
Page 5: Electrical Connections
Electrical Connections 230 Volt models: Connect the mains lead to a standard 230 Volt (50Hz) electrical supply through an approved BS1363, 13amp plug or a suitably fused isolator switch. 110 Volt models: Connect the mains lead to a suitable 110 Volt (50Hz) electrical supply through an approved plug or a suitably fused isolator switch. -
Page 6: Operation
This pump should require little or no maintenance other than regular cleaning. If the pump starts to show signs of wear or damage, contact you nearest CLARKE dealer for advice. Do Not use the pump if there is any damage to the mains supply or float switch cable. -
Page 7: Maintenance/Troubleshooting
Check the pump installation regularly to ensure the base inlet is clear of leaves or other foreign objects, mud silt etc. if the pump starts to show signs of wear or damage, contact your nearest Clarke dealer for advice. DO NOT ATTEMPT TO CARRY OUT REPAIRS TO THE PUMP YOURSELF UNLESS YOU ARE FULLY COMPETENT. - Page 8 Parts Diagram (GSE 1 & GSE 1A)
-
Page 9: Parts Gse1 & Gse1A
Parts List (GSE 1 & GSE 1A) INDEX PART NUMBER DESCRIPTION GM7099 Inox Screw GM7144 Inox Nut GM7206 Flange GM8138 Elastic Washer GM7212 Bearing GM8357 10M Cable Comp With Plug GM7205 Inox Housing GM5662 Motor Complete GM6029 Seeger GM7215 ‘O’ Ring 4437 GM8344 Bearing GM7202... - Page 10 Parts Diagram (GSE 150 &150A) -11-...
-
Page 11: Parts Gse 150 & Gse150A
Parts List (GSE 150 &150A) INDEX PART NUMBER DESCRIPTION GM8355 10M Cable With Plug GM8221 Inox Handle GM8185 Inox Nut GM8235 Condenser 16 MY GM7093 Superior Flange GM7105 ‘O’ Ring 107.7 x 1.78 GM7111 Bearing 6203 GM8113 Motor GM8269 Inox Screw GM7097 Inox Washer GM5507... - Page 12 Parts Diagram (GSE 2 & 2A) -13-...
-
Page 13: Parts Gse2 & Gse2A
Cable-Lock For Float (GSE 2A) GM1017 Connection 2” x 50 GM1095 Nipple From 2” to 2” IMPORTANT: The use of parts other than CLARKE replacement parts may result in safety hazards, de- creased tool performance and may invalidate your warranty. -14-...
