CONNECTING & OPERATING THE 4X1 DVI KVM SWITCHER
How to Connect the 4x1 DVI KVM Switcher to your devices:
1. Connect your computers' DVI, USB, and Audio sources to the 4x1 DVI KVM
Switcher inputs using the supplied cables.
2. Connect your USB and audio devices to the USB and audio outputs using the
supplied cables.
3. Connect your DVI-compliant display to the DVI output of the 4x1 DVI KVM
Switcher using a user-supplied DVI cable.
4. Connect the included 5V DC power supply to the Switcher by connecting its
5V DC power supply tip into the receptacle in the rear of the unit, then plug it
into the wall.
5. Turn on the DVI display or projector fi rst, then the DVI video sources/
computers.
Note: Computers must be turned on one at a time and the switcher must
be selected to the computer that is booting up. This is so that monitor
information (EDID) can be transmitted from the display to each computer.
After one computer completes the startup process, you can boot up the
second computer and repeat the process with the remaining computers.
How to Operate the 4x1 DVI KVM Switcher:
1. Use the RMT-4IR remote control to remotely switch between DVI video
sources.
2. Alternatively, use the front panel selector buttons.
