Other Functions of the "Fn" Key

Pressing the "Fn" key will lock the function, indicated by the illuminated "Fn" LED.
Number Pad keys (page 11) but it will also enable other standard keyboard features of the RACKMUX-V15.
Key Function when Fn key is
not locked ("Fn" LED is OFF)
NUMLCK
SCR LCK
See additional functions of the "Fn" key described on page 13.

Numeric Keypad Option

Models with the Numeric Keypad option (-N) (i.e. RACKMUX-V15-N) have a standard Windows keyboard with 17-key numeric
keypad. Also included is a special "Fn" key to:
toggle between USB and PS/2 keyboard/mouse mode (pg. 13).
enable a SUN and MAC Power Key
enable SUN extra key emulation
F1 F2
F3 F4
ESC
@
~ ! #
2
1 3
4
`
W E
Q
TAB
A S D
CAPS LOCK
SHIFT Z X
Fn CTRL
ALT
"Fn" Key to enable additional key functions

Figure 14- U.S. (English) Keyboard with numeric keypad
