Reference Part
1 Paper guide
Paper support (ASF)
2
3 Extractible cover
of the exposure bed
4 Front panel
5 Front hatch
6 Paper tray
7 Exposure bed
8 Scanning unit
9 Power connector
10 High speed USB
interface
11 Support for cartridges
12 Front panel USB
interface
4 CHAPTER 1
Description
Guides the paper fed into the printer.
Supports the paper loaded.
Cover of the scanner. Can be removed to scan bulky documents
(such as books).
Used to switch the printer ON and OFF and to control print, copy
and scanning operations.
To access the compartment containing the print cartridges.
Collects the paper printed that is ejected from the printer.
Place the document or the photo with the side to be copied or to
be scanned facing down. See "Positioning of the document on
the exposure bed".
To place the original on the exposure bed.
Connect the power cable of the external universal power supply
unit, furnished with the product, to the printer.
Then connect the other end of the external power supply unit
with the mains cable to a grounded electrical outlet.
note: Connect first of all the cable to the printer and then to the
outlet.
Connect the USB cable (not included) to the printer for
connection to the computer. Connect the other end of the cable
to the USB port on the computer.
Supports two ink cartridges. The color cartridge is installed to the
right while the black cartridge (or the photographic cartridge, sold
separately) is installed to the left.
To replace the ink cartridges, see "Replacement of the ink
cartridges".
Connect the USB cable of the digital camera, a USB memory
(Mass Storage).
