SYSTEM OVERVIEW

LEFT SIDE

(1) USB ports
(2) IEEE 1394 port
(3) PC card slot
(4) PC card release catch
(5) Line In port
(6) Microphone socket
(7) Loudspeakers/headphones port

RIGHT SIDE

(1) Lithium ion battery
(2) Optical drive
(3) Eject button
(4) Emergency release (only if notebook is switched off)
(5) Socket for power adapter

FRONT VIEW

(1) Display release
(2) Loudspeakers
(3) Memory card slot
(4) Wireless network (LAN) on/off
66
Fig. 6
Fig. 7
Fig. 8
