System Overview
SYSTEM OVERVIEW
LEFT AND RIGHT SIDES
(1)
Volume control
(2)
Memory Stick, Secure Digital and MultiMedia card slot
(3)
PC card slot
(4)
PC card release catch
(5)
Infrared sender/ receiver
(1)
Kensington lock - anti-theft device
(2)
Ventilation opening
All air intake and ventilation
openings must be kept free
from obstructions at all
times. If not, the device is
liable to overheat.
66
Fig. 6
Fig. 7
