Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Eup-Standby And Off Mode Power Consumption Statement
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.
Page 6: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 7: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 8: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 9: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 11: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer.  • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Page 12: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 13: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 14: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 15: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 16 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 17 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 18: Lcd Screen Care
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 19: Table Of Contents
Preface Contents Notice .................I Function/Hot Key Indicators .........1-9 EuP-Standby and Off Mode Power Consumption State- System Map: Front & Top Views ........1-10 ment: .................II System Map: Left View ..........1-11 FCC Statement ..............IV System Map: Right & Rear Views ......1-12 FCC RF Radiation Exposure Statement: ......
Page 20 Preface Power Management Updating/Reinstalling Individual Drivers ......4-4 User Account Control ............4-5 Overview ................3-1 Windows Security Message ...........4-5 The Power Sources ............3-2 New Hardware Found ............4-5 AC/DC Adapter .............3-2 Driver Installation Procedure .........4-6 Battery ................3-2 Chipset ................4-6 Turning On the Computer ..........3-3 Video (VGA) ..............4-6 Power Plans ..............3-4 LAN ................4-6...
Page 21 Preface The Setup Utility ............5-2 Security Menu ..............5-10 Failing the POST ............5-3 Set Supervisor Password (Security Menu) ....5-10 Fatal Errors ..............5-3 Set User Password (Security Menu) ......5-11 Non-Fatal Errors ............5-3 Password on boot (Security Menu) ......5-11 Setup Screens ..............5-4 TPM Configuration (Security Menu) ......5-12 Main Menu ..............5-5 TPM State (Security Menu >...
Page 22 Preface 3rd Party WLAN Driver Installation ......7-12 Bluetooth & WLAN Combo Module Configuration ...7-66 Intel® WLAN Driver Installation .......7-12 Intel Bluetooth Combo Driver Installation ....7-69 Connecting to a Wireless Network in Windows 7 ..7-13 Standard Bluetooth Configuration in Windows 7 ..7-70 Intel®...
Page 23 Preface Notebook Ports and Jacks ..........A-2 Communication ............. C-4 Communication (Model A Only) ........C-4 Video Driver Controls Power Management ............C-4 Video Driver Installation ..........B-1 Power ................C-4 Dynamic Video Memory Technology ...... B-1 Security ................. C-4 Intel®...
Page 24 Preface XXII...
Page 25: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 26: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 27: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 28: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 29: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system.
Page 30: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open  Built-In PC Camera Wireless Device (Optional) Operation Aboard Aircraft Power Button Keyboard The use of any portable elec- Built-In Microphone tronic transmission devices Touchpad & aboard aircraft is usually pro- Buttons hibited.
Page 31: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Orange DC Power is Plugged In Blue Power Button The Powered USB Port is Blinking Orange Green The Computer is On...
Page 32: Keyboard
Quick Start Guide Keyboard  The keyboard has a numerical keypad for easy numeric data input, and features func- Other Keyboards tion keys to allow you to change operational features instantly. See Table 1 - 2, on page 1 - 9 for full function key combination details.
Page 33: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...
Page 34: System Map: Front & Top Views
Quick Start Guide System Map: Front & Top Views Figure 1 - 4 Front & Top Views (with Optional Docking Station) LED Indicators WLAN Switch Docking Station (Optional) Alignment Markers  WLAN Switch Use the WLAN Switch (for Wireless LAN only) to tog- gle power to the WLAN module.
Page 35: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 5 Left View DC-In Jack External Monitor Port RJ-45 LAN Jack e-SATA Port/   USB 2.0 Combo Port External Monitor Port & RJ-45 LAN Multi-In-1 Card Reader HDMI-Out Port Jack 2 * USB 3.0 Ports The card reader allows you to use the most...
Page 36: System Map: Right & Rear Views
Quick Start Guide System Map: Right & Rear Views Figure 1 - 6 Right & Rear Views Microphone-In Jack Headphone-Out Jack 1 * Powered USB 2.0 Port Fan Intake/Vent Security Lock Slot Battery  Powered USB 2.0 Port The powered USB 2.0 port can supply power when the system is off but still powered by the AC/DC adapter plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may not work with certain devices - see page...
Page 37: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 7 Bottom View  Battery Docking Port The CPU is not a user ser- Fan Intake/Vent viceable part. Drainage Outlet Speakers Overheating Component Bay To prevent your computer Cover from overheating make sure nothing blocks the...
Page 38: Docking Port
Quick Start Guide Docking Port Follow the instructions below before connecting the computer to the docking station, if included in your pur- chase configuration. Failure to open the cover of the docking port before connecting the computer to the docking station may result in irreparable damage to the connector on the docking station.
Page 39: What To Do If You Spill Liquid On The Computer
Quick Start Guide What to do if you Spill Liquid on the Computer  The keyboard incorporates a drainage system that minimizes the chances of liquid Warranty Warning spillages on the keyboard penetrating the inside components of the computer. Liquid spilled on the computer is drained towards the right side of the computer.
Page 40 Quick Start Guide 3. Move the computer to a dry place and wipe any liquid off the keyboard and bottom of the computer using a clean, soft, dry cloth. 4. Remove the battery. 5. Leave the computer resting on its right side (while placed on a clean, soft, dry cloth) to dry out for about three hours.
Page 41 Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 42: Video Features
Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 7 (see over). For more detailed video information see “Video Driver Con- trols” on page B - 1.
Page 43 Quick Start Guide To access the Intel(R) Graphics and Media Control Panel: Click Advanced settings (Figure 1 - 12 on page 1 - 18) in the Display Settings control panel in Windows. Click Graphics Properties (button) (Figure 1 - 13) in the Intel Graphics & Media Control Panel tab. Right-click the desktop and select Graphics Properties from the menu.
Page 44: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 13) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 45: Features & Components
Features & Components Chapter 2: Features & Components  Overview External Optical (CD/DVD) Device Read this chapter to learn more about the following main features and components Drives of the computer: To install applications and drivers etc. you will • Hard Disk Drive need to attach an exter- •...
Page 46: Hard Disk Drive
Features & Components Hard Disk Drive  The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 47: Multi-In-1 Card Reader
Features & Components Multi-In-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 48: Expresscard Slot
Features & Components ExpressCard Slot  The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you install the Card Reader driver (see “CardReader”...
Page 49: Touchpad And Buttons/Mouse
Features & Components Touchpad and Buttons/Mouse  The Touchpad is an alternative to the mouse; however, you can also add a mouse to Touchpad Scrolling your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse. This computer model se- ries may feature different Touchpad versions.
Page 50: Gestures And Device Settings
Features & Components Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the Touchpad to perform specific actions to manipulate doc- uments, objects and applications. You can get a clearer view of the gestures in- You can configure the settings from the Device Settings tab in Mouse Properties:...
Page 51 Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 6 tinuous motion).
Page 52 Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Page 53: Audio Features
Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 54: Optimizing Audio Recording
Features & Components Optimizing Audio Recording Follow these instructions to optimize your audio recording. Double-click the taskbar icon to bring up the Realtek HD Audio Manager. Click the Microphone tab. Click the Noise Suppression button to prevent any background noise or feedback.
Page 55: Adding A Printer
Features & Components Adding a Printer  The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
Page 56 Features & Components 2 - 12...
Page 57: Power Management
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the LCD and hard disk drive) or the whole system.
Page 58: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.
Page 59: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 60: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 62: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 63: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 64: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 65: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color...
Page 66: Energy Star Power Saving
Power Management Energy Star Power Saving  This system supports Energy Star power management features that place comput- Taskbar Icon ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. If you want to enable Energy Star power saving then follow these in- If the taskbar icon does structions: not appear then click the...
Page 67: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- cally low, immediately grams you are running, and peripheral devices attached.
Page 68: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 69: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 70: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 71: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 72 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 73 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 74 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 75: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the lat- est versions of most available operating systems haven’t built in drivers and utilities.
Page 76: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 77 Drivers & Utilities Drivers for Windows 7 with Service Pack 1 Chipset Page 4 - 6 PC Camera Module Page 7 - 2 Video (VGA) Page 4 - 6 Wireless LAN Module Page 7 - 10 Page 4 - 6 Fingerprint Reader Module Page 7 - 30 CardReader...
Page 78: Updating/Reinstalling Individual Drivers
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.
Page 79: User Account Control
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue or ing the installation procedure (other than when out- Allow, and follow the installation procedure as direct- lined in the driver install procedure), click Cancel to close the window, and follow the installation proce-...
Page 80: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual 1. Click 3.Install LAN Driver > Yes. disc and click Install Drivers (button). 2. Click Install Drivers and Software > Next. 3. Click the button to accept the license and click Chipset Next.
Page 81: Hot Key
Drivers & Utilities Hot Key MEI Driver 1. Click 6.Install Hotkey AP > Yes. 1. Click 8.Install MEI Driver > Yes. 2. Click Next > Next. 2. Click (click the button to “Install Intel Con- ® 3. Click Finish > Finish to restart the computer. trol Center”) Next >...
Page 82: Windows Experience Index
Drivers & Utilities Windows Experience Index  After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- Windows Update ence Index (make sure the AC/DC adapter is plugged After installing all the drivers make sure you enable Win- in): dows Update in order to get all the latest security up- dates etc.
Page 83: Optional Drivers
Drivers & Utilities Optional Drivers PC Camera Module See the pages indicated for the driver installation pro- “PC Camera Module” on page 7 - cedures for any modules included in your purchase op- tion. Wireless LAN Module “Wireless LAN Module” on page 7 - Fingerprint Module “Fingerprint Reader Module”...
Page 84 Drivers & Utilities 4 - 10...
Page 85: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities  BIOS Screens Overview Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- ting up your system’s system (e.g.
Page 86: The Setup Utility
BIOS Utilities The Setup Utility  Each time you turn on the computer the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...
Page 87: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 88: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
Page 89: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 90: Sata Port # (Main Menu)
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
Page 91: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting and enable/ disable Intel Virtualization Technology and Intel AMT SPI protection. Advanced Menu 5 - 7...
Page 92: Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)
BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)  You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is SATA Mode started up or restarted.
Page 93: Legacy Usb Support (Advanced Menu)
BIOS Utilities Legacy USB Support (Advanced Menu) Choose “Enabled” if you intend to use USB devices in systems which do not nor- mally support USB functionality (e.g. DOS). The default setting is “Enabled” and does not need to be changed if you intend to use your USB devices in Windows. Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup.
Page 94: Security Menu
BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
Page 95: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Aptio Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to Password Warning set a Password on Boot (see below).
Page 96: Tpm Configuration (Security Menu)
BIOS Utilities TPM Configuration (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select TPM Configuration and press En- ter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu (see “Trusted Platform Mod- ule”...
Page 97: Tpm State (Security Menu > Tpm Support Enabled)
BIOS Utilities TPM State (Security Menu > TPM Support Enabled) Select TPM State, press Enter and select Enable to change the TPM state to en- abled. You will then need to press F4 to save the changes and restart the computer. Figure 5 - 6 TPM State (Enabled) As the computer restarts press F2 to enter the BIOS again and go to the TPM Con-...
Page 98: Pending Tpm Operation (Security Menu > Tpm Support & Tpm State Enabled)
BIOS Utilities Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer.
Page 99: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 8 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
Page 100: Boot Sequence (Boot Menu)
BIOS Utilities Boot Sequence (Boot Menu) Use the arrow keys to move up and down the menu and use the keys to move the device’s boot priority up and down the list (the selected device will be highlight- ed in white). 5 - 16 Boot Menu...
Page 101: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 9 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 102 BIOS Utilities 5 - 18...
Page 103: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 104: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- dures, make sure that...
Page 105: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Slide the latch...
Page 106: Removing/Replacing The Component Bay Cover
Upgrading The Computer Removing/Replacing the Component Bay Cover  Turn off the computer, and turn it over and remove the battery. Warranty Warning Slide the latch in the direction of the arrow. Slide the latch in the direction of the arrow, and hold it in place. Please check with your Carefully slide the cover in the direction of the arrow to align with the markers...
Page 107: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive  The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 108 Upgrading The Computer Turn off the computer, and turn it over and remove the bottom cover (see “Removing/Replacing the Component Bay Cover” on page 6 - Raise the plastic tab Slide the hard disk assembly in the direction of arrow until you can see the (gold colored) HDD connector Figure 6 - 3...
Page 109 Upgrading The Computer Remove the screw(s) & and the adhesive cover Figure 6 - 5 Hard Disk Cover Removal Upgrading the Hard Disk Drive 6 - 7...
Page 110 Upgrading The Computer Reinserting the HDD To reinsert the HDD assembly hold it carefully at the four corners between your thumb and forefinger. Figure 6 - 6 Hard Disk Insertion  Hard Disk Handling Insert the HDD directly down into the bay vertically Do not press down on the center off the hard disk as Press and slide the HDD assembly at the area illustrated...
Page 111 Upgrading The Computer Press down on the rubber case to ensure the assembly is properly seated before replacing the cover and screws. Figure 6 - 8 Seat the Assembly Replace the component bay cover (see “Removing/Replacing the Component Bay Cover” on page 6 - Upgrading the Hard Disk Drive 6 - 9...
Page 112: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 2 details of supported module types). Turn off the computer, and turn it over and remove the bottom cover (“Removing/ Replacing the Component Bay Cover”...
Page 113 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 10 RAM Module Release Latches  Contact Warning Be careful not to touch The RAM module will pop-up, and you can remove it.
Page 114 Upgrading The Computer Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it will go.
Page 115: Modules & Options
Modules & Options Chapter 7: Modules & Options  Overview Wireless Device Operation Aboard Aircraft This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Page 116: Pc Camera Module
Modules & Options PC Camera Module  Before installing the PC Camera driver, make sure that the optional PC Camera is Latest PC Camera on. Use the Fn + F10 key combination (see “Function/Hot Key Indicators” on Driver Information page 1 - 9) to toggle power to the PC Camera module.
Page 117: Pc Camera Driver Installation
Modules & Options PC Camera Driver Installation  1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3.
Page 118 Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 119 Modules & Options Figure 7 - 1 Audio Setup for PC Camera Right-click PC Camera Module 7 - 5...
Page 120 Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see Set Capture File below).
Page 121 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 122 Modules & Options Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 123 Modules & Options Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Page 124: Wireless Lan Module
Modules & Options Wireless LAN Module  If you have included an Intel® or 3rd Party Wireless LAN (or WLAN & Bluetooth Wireless Device combo) module in your purchase option, make sure that the WLAN module is on be- Operation Aboard fore installing the driver.
Page 125: Wireless Lan Switch
Modules & Options Wireless LAN Switch The Wireless LAN switch allows you to quickly and easily toggle power to the WLAN module when necessary. Figure 7 - 3 Front View WLAN Switch You can also use the Fn + F11 key combination (see page 9) or the Windows Mobility Center (see page 28) button to toggle power to the WLAN module,...
Page 126: 3Rd Party Wlan Driver Installation
Modules & Options 3rd Party WLAN Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2.
Page 127: Connecting To A Wireless Network In Windows 7
Modules & Options Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Click the taskbar notification area wireless icon , and then double-click an Network and access point to connect to or click to Open Network and Sharing Center if you do Sharing Center not see a network you want to connect to in the taskbar menu (a list of options will You can also use the Net-...
Page 128 Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 129 Modules & Options Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Page 130 Modules & Options Intel My WiFi Configuration ®  Intel® My WiFi Technology uses your WLAN (for Intel WLAN modules only) module to allow you to connect up to eight other WiFi enabled devices (e.g. digital Intel® My WiFi Help cameras, other computers, cell phones, handheld devices etc.) to your computer To get help on Intel®...
Page 131: Intel® My Wifi Configuration
Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the taskbar icon Click Enable (on the first run of the program there will be no connected...
Page 132 Modules & Options Click Start and click Control Panel. Click Network and Sharing Center (Network and Internet). Click Change adapter settings. Figure 7 - 8 Network and Sharing Center Click Change adapter settings 7 - 18 Wireless LAN Switch...
Page 133 Modules & Options Right-click Wireless Network Connection and select Properties. Figure 7 - 9 Network Connections Right-click Wireless Network Connection and select Proper- ties. Wireless LAN Switch 7 - 19...
Page 134 Modules & Options Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Connection under Home networking connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”.
Page 135 Modules & Options 10. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the taskbar icon 11. Click Profiles Figure 7 - 11 Intel®...
Page 136 Modules & Options 12. Click Profiles, click Intel Wireless PAN and click Edit or New (Note that all preset settings may not be editable - see sidebar). Figure 7 - 12 Profiles  Profile Settings 13. You can change the Profile Name and Network Name to your personal Profiles that are preset preferences in General (tab).
Page 137 Modules & Options 14. Click Security (tab). 15. Change the Security Type to WEP and the Encryption Type to 64bit. 16. Enter a password (8 characters long) in the Password box. Figure 7 - 14 Intel® My WiFi Profile Settings - Security Wireless LAN Switch 7 - 23...
Page 138 Modules & Options 17. Click Sharing (tab). 18. It is recommended that the Filter Network Traffic and DHCP and DNS Server are Disabled. Figure 7 - 15 Intel® My WiFi Profile Settings - Sharing 7 - 24 Wireless LAN Switch...
Page 139 Modules & Options 19. Click Advanced (tab). 20. It is recommended that the Default Channel is set to Channel 1, 6 or 11. 21. Click OK to save the settings. Figure 7 - 16 Intel® My WiFi Profile Settings - Advanced Wireless LAN Switch 7 - 25...
Page 140 Modules & Options 22. Double-click Wireless Network Connection in Network Connections. 23. Click Details to display the Network Connection Details. Figure 7 - 17 Wireless Network Connection Details 7 - 26 Wireless LAN Switch...
Page 141 Modules & Options 24. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon 25. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Page 142: Windows Mobility Center
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 143: Security Modules (Fingerprint & Tpm)
Modules & Options Security Modules (Fingerprint & TPM)  The encrypted channel between the Trusted Platform Module security chip (see Password Warning “Trusted Platform Module” on page 7 - 75) and the fingerprint reader with Au- thenTec TrueSuite software (see “Fingerprint Reader Module”...
Page 144: Fingerprint Reader Module
Modules & Options Fingerprint Reader Module The fingerprint reader module provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. Fingerprint Reader Driver Installation 1.
Page 145: User Enrollment
Modules & Options User Enrollment  Click Start > All Programs > Protector Suite > Control Center, or double click the notification area icon (click Initialize). Fingerprint On the first run of the program you will be asked to click the Accept button to Enrollment accept the license.
Page 146 Modules & Options Click the button above any of the fingers to begin the enrollment process for that  finger. Swipe the finger until the progress bar reaches 100% to enroll that finger. Fingerprint Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Save and Continue.
Page 147 Modules & Options 11. Click the taskbar notification area icon (and then swipe a finger) to allow you to Edit Fingerprints, register Applications, edit Settings and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite item in the Programs/All Programs menu 12.
Page 148: Fingerprint Control Center Features
Modules & Options Fingerprint Control Center Features  Application Launcher Help The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the reg- For more information on these and other features istered fingers and ten click OK to close the application window.
Page 149: 3.75G/Hspa Module
Modules & Options 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module (see “Communication” on page C - 4 for specification details) in your purchase op- tion, you will have the appropriate application provided for your particular module. Follow the instructions on page 7 - 37 to install the USIM card (supplied by your...
Page 150 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON  (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...
Page 151 Modules & Options 3.75G/HSPA Module USIM Card Installation  Follow the instructions below to install the USIM card (which will be provided by Power Safety your service provider). Warning Turn the computer off, and turn it over. Before you undertake any Slide the latch in the direction of the arrow.
Page 152: Wireless Manager
Modules & Options Wireless Manager  With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Wireless Manager application. The Wireless Wireless Device Manager application allows you to directly access your HSPA internet service from Operation Aboard Aircraft the computer.
Page 153: Wireless Manager Application
Modules & Options Wireless Manager Application  The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a PIN Number Profile”...
Page 154 Modules & Options The system will connect to your network.  Connected will appear above the timer icon (the timer will indicate your connected time for the current session) Wireless Manager You can then access the internet, download e-mail etc. as per any internet Help connection.
Page 155 Modules & Options Click the Wireless Manager notification area icon to view the connection status, or wireless icon to view the Mobile Broadband Connection status Figure 7 - 26 Notification Area Icons (Connected)  Notification Area The indicator will display the signal strength and radio access Icon technology.
Page 156: Profiles
Modules & Options Profiles Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click the Settings > Advanced. Click the Profiles (tab). Figure 7 - 27 Advanced Settings - Profiles 7 - 42 3.75G/HSPA Module...
Page 157 Modules & Options Multiple profiles may be available from the USIM card and the first time the application starts it may require you to select a profile (Set Profile) to use for your connection. Figure 7 - 28 Multiple Profiles Found Automatic Profile Selection If Automatic selection is chosen, then the application will search the operator pro-...
Page 158 Modules & Options Selecting a Profile Click Manual selection (button). Click the Filter to view the drop-down list. Select the Profile you wish to use and click Apply to confirm the selection. Figure 7 - 29 Profile - Manual Selection (Filter) 7 - 44 3.75G/HSPA Module...
Page 159 Modules & Options Creating a Profile  Click Manual selection (button). Click the New. Deleting a Profile Enter a name you prefer for the profile. Enter the Access Point Name (APN). To delete a profile click Enter the User Name and Password if required (some service providers may not to select Manual selec- require this information and the fields may then be left blank).
Page 160: Settings
Modules & Options Settings The Settings tab allows you at adjust the application features. Click to put a tick in Launch Wireless Manager at Windows startup to launch the application at Win- dows Startup. Figure 7 - 31 Settings The Advanced settings allows more detailed configuration. To access the Ad- vanced settings: Access the Wireless Manager program from the Start menu (Start >...
Page 161 Modules & Options  Most USIM cards are protected by a Personal Identity Number (PIN). You may turn on or off the Request PIN at startup (click Apply to save any changes). You can PIN Notes also Change PIN (you will need to enter the new PIN in the two fields provided and click Apply to save any changes).
Page 162 Modules & Options Networks  The mobile network list lists available networks at your location, and allows you to select a network which to connect. You must disconnect before being able to select Warning a network. Note that some applica- tions automatically Connection...
Page 163: Text Messaging Service (Sms)
Modules & Options Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Wireless Manager, if your service supports SMS. SMS Utility Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 164 Modules & Options Messages Click the Messages tab to access the tabs displaying text messages. The tabs at the top of the menu display the Inbox, Drafts, Outbox, Sent and Trash menus. Inbox Drafts Outbox Sent Trash Figure 7 - 35 SMS Utility Messages Text messages are automatically saved to your computer and may be sorted in as-...
Page 165: Sending A Text Message
Modules & Options Sending a Text Message Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click SMS and the SMS Utility will then start. Click the New Message tab.
Page 166 Modules & Options Click Send to send the message or Save to save the message in the Drafts folder. Clicking the Clear icon clears both the Message and To fields. If radio is on then the message will be sent, however if the radio is off the message will be stored in the Outbox.
Page 167 Modules & Options Messages • Opening a text message: Double-click the message and the message will open in a new window (to close it click the close icon in the top right of the message). Figure 7 - 38 Click to close the message Close Message •...
Page 168: Phonebook
Modules & Options Phonebook The Phonebook allows you to view and edit all your frequently used contacts, and is divided into Contacts and Groups . To access the Phonebook: Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 169 Modules & Options Contacts  • New Contact: Click the New contact button to create a contact. Add the name and at least one phone number (Mobile, Work, Home and Other Import/Export fields are available) for the contact. Click the icon to expand the number Contacts details.
Page 170 Modules & Options Groups You can organize existing contacts into groups from the Groups tab. • New Group: Click the New group button to create a group. Click icon to expand the group details, and click a check box to add at least one phone number from the contacts for the group.
Page 171: Sms Settings
Modules & Options SMS Settings The SMS Utility Settings tab allows you at adjust the SMS features. Figure 7 - 42 SMS Utility Settings  SMS Settings Message Length: You can set the number of blocks that can be sent (up to a length of 10 blocks).
Page 172 Modules & Options Send Click Delivery Report to automatically request a reply from a recipient. If you click to Send messages in Outbox automatically upon connection then messages writ- ten when the radio is off, will then be sent automatically the next time radio is turned on.
Page 173 Modules & Options Number You can choose to Use default service center number or you can uncheck the box and add your number manually if your service provider supplies a different number (click Apply to save the change or Default to return to the default number). Memory Phonebook memory status displays the number of contacts displayed on the USIM card.
Page 174: Bluetooth & Wlan Combo Module
Modules & Options Bluetooth & WLAN Combo Module  If your purchase option includes the Combination Wireless LAN & V3.0 Blue- Wireless Device tooth module (either Intel® or 3rd Party) then install the driver as instructed from Operation Aboard the appropriate page (see below). Aircraft Use the Fn + F12 key combination to toggle power to the Bluetooth module.
Page 175: 3Rd Party Bluetooth Combo Driver Installation
Modules & Options 3rd Party Bluetooth Combo Driver Installation  Note this driver is required only for the combo Bluetooth and WLAN module only. High Speed Bluetooth 1. Before installing the driver make sure the Bluetooth module is powered Data Transfer on (use Fn + F12 key combination), then insert the Device Drivers &...
Page 176: 3Rd Party Bluetooth & Wlan Combo Settings
Modules & Options 3rd Party Bluetooth & WLAN Combo Settings  This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Make sure the Bluetooth module is powered on. Resuming From Sleep Double-click the My Bluetooth application on the desktop (or access it from the Mode Programs/All Programs menu).
Page 177 Modules & Options Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 46 General Settings Bluetooth &...
Page 178 Modules & Options Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 47 File Transfer Settings 7 - 64 Bluetooth & WLAN Combo Module...
Page 179: Bluetooth Networking Setup
Modules & Options Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 45 on page 7 - 62).
Page 180: Bluetooth & Wlan Combo Module Configuration
Modules & Options Bluetooth & WLAN Combo Module Configuration  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Module & Make the device discoverable (to do this check your device documentation). Resuming From Sleep Mode To Turn the Bluetooth Module On...
Page 181 Modules & Options You will then be presented with a menu of options to select from. Figure 7 - 50 Bluetooth Device Options Click the appropriate button to connect to the device. Bluetooth & WLAN Combo Module 7 - 67...
Page 182 Modules & Options You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Page 183: Intel Bluetooth Combo Driver Installation
Modules & Options Intel Bluetooth Combo Driver Installation  Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Page 184: Standard Bluetooth Configuration In Windows 7
Modules & Options Standard Bluetooth Configuration in Windows 7  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 185 Modules & Options To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 186 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 54 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 187 Modules & Options To Change Settings for the Bluetooth Device  Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 188: Intel Rapid Storage Technology
Modules & Options Intel Rapid Storage Technology Install the Intel Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - IRST Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Page 189: Trusted Platform Module
Modules & Options Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.
Page 190: Enabling & Activating Tpm
Modules & Options Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu Select TPM Configuration and press Enter. Select TPM Support and press Enter, select Enable and press Enter. Select TPM State, press Enter and select Enabled to change the TPM state to enabled.
Page 191 Modules & Options Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership) and press Enter. You will then need to press F4 to save the changes and restart the computer.
Page 192: Trusted Platform Module (Tpm) Driver Installation
Modules & Options Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver (if you do not do see the note below). 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Page 193: Initializing Tpm
Modules & Options Initializing TPM Run the application from the Infineon Security Platform Solution > Manage Security Platform item in the Start > All Programs menu. Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
Page 194 Modules & Options Choose the Security Platform Features you want to use by clicking the appropriate tickbox. Enter a Basic User Password (and re-type to confirm it) and click Next. Figure 7 - 61 Settings  Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use...
Page 195: Infineon Security Platform Settings Tool
Modules & Options Infineon Security Platform Settings Tool  The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
Page 196 Modules & Options User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
Page 197 Modules & Options Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion.
Page 198 Modules & Options Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 65 Infineon Security Platform Settings Tool (Migration) 7 - 84 Trusted Platform Module...
Page 199 Modules & Options Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 66 Infineon Security Platform Settings Tool (Password Reset) Trusted Platform Module 7 - 85...
Page 200 Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
Page 201 Modules & Options Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 68 BitLocker Drive Encryption Trusted Platform Module 7 - 87...
Page 202 Modules & Options Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 69 Infineon Security Platform Settings Tool (Advanced) 7 - 88 Trusted Platform Module...
Page 203: Intel® Vpro™ Technology
Modules & Options Intel® vPro™ Technology Intel® vPro™ Technology is supported by Model B computers only. This set of technology features, built into the computer’s motherboard, allows Information Technology departments remote access to the computer. This allows the IT depart- ment to monitor, maintain and manage computers regardless of the state of the op- erating system or the computer’s power state.
Page 204 Modules & Options Figure 7 - 70 Intel(R) Management Engine (Password Creation) Once you have entered the password you will then be taken to the platform config- uration screen. 7 - 90 Intel® vPro™ Technology...
Page 205 Modules & Options Figure 7 - 71 Intel(R) Management Engine (Platform Configuration) The platform configuration screen allows you to setup Intel ME as per your require- ments (consult your IT administrator for the actual settings required). Intel® vPro™ Technology 7 - 91...
Page 206 Modules & Options 7 - 92...
Page 207: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 208: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 209: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 210: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 211: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 212 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 213: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 214 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 215 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 216 Troubleshooting Problem Possible Cause - Solution The system freezes or the screen goes The system’s power saving features have timed-out. Use the AC/DC adapter, dark. press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
Page 217 Troubleshooting Problem Possible Cause - Solution A file cannot be copied to/from a The transfer of data between the computer and a Bluetooth enabled device is connected Bluetooth device. supported in one direction only (simultaneous data transfer is not supported). If you are copying a file from your computer to a Bluetooth enabled device, you will not be able to copy a file from the device to your computer until the file transfer process from the computer has been completed.
Page 218 Troubleshooting Problem Possible Cause - Solution I previously turned off the WLAN module The computer entered a power saving state with the WLAN Switch in the ON using the Fn + F11 key combination (or position, and upon resuming from the power saving state the WLAN module Windows Mobility Center button), but turned ON.
Page 219: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 220 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 221 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 222 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 16 Bluetooth Connection Problems...
Page 223: Intel® Centrino Advanced Wlan & Bluetooth V3.0+Hs Combo Modules
Troubleshooting Intel® Centrino Advanced WLAN & Bluetooth V3.0+HS Combo Modules Note that, at the time of going to press, Intel® Centrino® Wireless-N 1030 and Advanced-N 6230 WLAN & Bluetooth V3.0+HS combo modules use the standard Bluetooth configuration in Windows 7 (see “Standard Bluetooth Configuration in Windows 7”...
Page 224 Troubleshooting 8 - 18...
Page 225: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.  USB Port/Card Reader Power Note that power to the USB ports and card reader may be enabled/disabled in the BIOS (see “USB Ports/Card Reader...
Page 226: Notebook Ports And Jacks
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 227 Interface (Ports & Jacks) Item Description Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions.
Page 228 Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the USB 3.0 Port power rating of your USB device is 500mA or above, make sure you use the power supply which...
Page 229: Video Driver Controls
Video Driver Controls Appendix B: Video Driver Controls  The basic settings for configuring the LCD are outlined in “Video Features” on Video Card Options page 1 - Note that card types, specifications and driv- Video Driver Installation ers are subject to contin- updates Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 -...
Page 230: Intel® Graphics & Media Control Panel
Video Driver Controls Intel Graphics & Media Control Panel ®  Advanced video configuration options are provided by the Intel Graphics and ® Application Mode Media Control Panel. To access the control panel: Note that all figures pic- Click Advanced settings in the Screen Resolution control panel in Windows. tured, and instructions Click the Intel(R)...
Page 231 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...
Page 232: Display Devices & Options
Video Driver Controls Display Devices & Options  Besides the built-in LCD you can also use an external monitor/flat panel display/TV connected to the external monitor port or to the HDMI-Out port (High-Definition Function Key Combination Multimedia Interface) as your display device. The table below outlines the display options.
Page 233: Attaching Other Displays
Video Driver Controls Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the left of the computer. At least one other dis- To Clone Displays: play must be attached in Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 234 Video Driver Controls To Enable Extended Desktop:  Attach your display to the external monitor port or HDMI-Out port, and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 235 Video Driver Controls Display Profiles You can save display settings to be loaded at any time. Go to the Intel(R) G&M control panel and click Display. Configure the General Settings, Multiple Displays, Color Enhancement, Custom Resolution & Monitor/TV Settings to your preferences. Click Apply, and OK to confirm the settings change.
Page 236: Configuring An External Display In Windows 7
Video Driver Controls Configuring an External Display in Windows 7  You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your display to the external monitor port or HDMI-Out port, and turn it on. You can use the Fn + Go to the Screen resolution control panel (see “Video Features”...
Page 237 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure B - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 238 Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 239: Hdmi Audio Configuration
Video Driver Controls HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Configure the audio output as per the instructions below. Connect a device with HDMI support to the HDMI-Out port. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound), and click Playback (tab).
Page 240 Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure B - 10 HDMI Device Properties B - 12 HDMI Audio Configuration...
Page 241 Video Driver Controls HHDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Page 242 Video Driver Controls B - 14...
Page 243: Specifications
Specifications Appendix C: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 244: Processors For All Models
Specifications Processors For All Models Processor For Model A Only Core Logic Note all processor packages are rPGA Note all processor packages are rPGA Model A: Intel® HM65 Express Chipset Intel® Core i7-2640M (2.8GHz) These processors are available for Model 4M L3 Cache, 32nm (32 Nanometer), A computers only: Model B:...
Page 245: Video
Specifications Video Keyboard, Pointing Device & Buttons Interface Intel® Integrated GPU (Intel® HD Isolated A4 Size Keyboard with Anti- One Powered USB 2.0 Port Graphics 3000): Spray Support Two USB 3.0 Ports Dynamic Frequency Built-in Touchpad with Multi-Gesture and One eSATA Port (USB/eSATA Combo) Scrolling Functionality Intel®...
Page 246: Communication
Specifications Communication Communication (Model A Only) Power Built-In 10/100/1000Mb Base-TX Ethernet Intel® Centrino® Wireless-N 1000 1*2 Full Range AC/DC Adapter (802.11 b/g/n) Half Mini-Card PCIe WLAN AC input 100 - 240V, 50 - 60Hz, Module (Factory Option) DC Output 19V, 3.42A or 18.5V, 3.5A (65 Intel®...
Page 247: Design Features
Specifications Design Features Power to all USB / Card Reader ports/ slots can be switched on/off in the BIOS WLAN Switch Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Dimensions &...
Page 248 Specifications C - 6...

MAXDATA M-BOOK 600 User Manual

Quick Start Guide

Features & Components

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules & Options

Troubleshooting

Interface (Ports & Jacks)

Video Driver Controls

Specifications

Quick Links

Need help?

Questions and answers

Related Manuals for MAXDATA M-BOOK 600

Summary of Contents for MAXDATA M-BOOK 600
