System Overview
EXPLANATION OF LED DISPLAYS
Fig. 11
Symbol
Symbol
Table 1
68
Meaning
Lights when the computer is switched on.
Flashes in power saving mode.
Lights when the battery is charging or ready for
use.
Lights when the wireless LAN is activated.
Lights when Caps Lock is on.
Lights when Num Lock is on.
Lights when Scroll Lock is on.
Lights when the hard disk is being ac-
cessed.
(1) Power
(2) Battery
(3) Wireless LAN
(4) Caps Lock
(5) Num Lock
(6) Scroll Lock
(7) Drive access
