I
NSTALLATION
1. Remove all packing materials. Remove the protective fi lm
(blue fi lm) from the outer case cabinet (if covered). Do not
remove the plastic fi lm from the inside of the oven window
as this protects it from dirt.
2. Place oven on a secure, level surface, strong enough to take
the oven weight, plus the heaviest item likely to be cooked in
the oven.
3. Ensure there is a minimum free space above the oven of
25 cm.
4. Do not place the oven where heat, moisture or high humidity
are generated, (for example, near or above a conventional
oven) or near combustible materials (for example, curtains).
Do not block or obstruct air vent openings, as obstructions
may ignite due to the emission of hot air.
5. Make sure the power supply cord is undamaged (See
Installation next page) and that it does not run under the oven
or over any hot or sharp surfaces.
6. The socket must be readily accessible so that it can be easily
unplugged in an emergency.
7. Do not use the oven outdoors.
8. Two ovens can be installed together by placing one on top of
another. Follow these instructions.
A. Place oven A in the desired location. Position Oven B on
top of Oven A as shown in the fi gure.
B. Remove Screws (a) and Mounting plate A and B from the
right side of the back of Oven A and B.
C. Replace Screws (a) removed at step B and tighten them.
D. Remove Screws (b), (c), (d), and (e) and then
install Mounting Plate A and B which were
removed at step B to the each lower edge of Oven B as
shown in the fi gure.
E. Replace Screws (b), (c), (d), and (e) which were removed
at step D and tighten them.
Oven B (Back)
Screw (e)
Screw (e)
Screw (d)
Oven A (Back)
Screw (d)
WARNING:
In situations where two ovens are installed together by placing
one on top of another,
1) Use the two mounting plates for fi xing the two ovens.
2) Make sure that the power supply cord is not caught between
the two ovens.
3) Do not install more than one oven on top of another.
4) Do not lose the removed screws.
R-1900M [EN].indd Sec1:3 R-1900M [EN].indd Sec1:3
Screw (a)
Mounting
plate B
Screw (b)
Screw (b)
Screw (c)
Screw (c)
Screw (a)
Mounting
plate A
3
WARNING:
It is hazardous for anyone other than a Service Technician,
approved by SHARP to carry out any service or repair operation
which involves the removal of a cover which gives protection
against exposure to microwave energy.
IMPORTANT! ELECTRICAL CONNECTION
• Do not allow water to come into contact with the power supply
cord or plug.
• Insert the plug properly into the socket as the plug may
otherwise overheat and catch fi re.
• Do not connect other appliances to the same socket using an
adaptor plug as it may cause the wiring to overheat and catch
fi re.
• If the plug or socket is loose or the power supply cord is
damaged, do not operate the oven, it must be replaced by the
special power cord. Contact your dealer or a Service Technician
appointed by SHARP.
A defective plug, power supply cord or socket may overheat
and catch fi re during operation or cause an electrical shock.
• When removing the plug from the socket always grip the plug,
never the mains lead as this may damage the power supply
cord and the connections inside the plug.
• The product is fi tted with a non-rewireable (moulded) plug.
Should it not be suitable for the socket outlet in your kitchen,
remove the plug and fi t an appropriate type, observing the wiring
code given in "To replace the mains plug" on page 39.
The fuse from a cut-off plug should be removed and the plug
disposed of in safe manner. Under no circumstances should the
cut-off plug be inserted into a socket outlet as serious electrical
shock may occur. The plug must not be used without the fuse
cover fi tted.
When replacing the plug please ensure that you use a BSI or
ASTA approved plug to BS1363, this should be fi tted with a brown
coloured 13 amp fuse approved by BSI or ASTA to BS1362. If
you have any doubt about electrical connection seek the help
of a qualifi ed electrician.
WARNING:
THIS APPLIANCE MUST BE EARTHED.
To wire an appropriate plug, follow the wiring code given in
"To replace the mains plug" on page 39.
Radio or TV Interference
Should there be any interference caused by the microwave
oven to your radio or TV, check that the microwave oven is
on a different electrical circuit, relocate the radio or TV as far
away from the oven as feasible or check position and signal of
receiving antenna.
