  • Page 1 UNIT REPLACEMENT MANUAL 18605...

  • Page 3: Table Of Contents

    CONTENTS 1. The Unit Life Manual ..................1 2. The Indication of Replacement for CRU/TFU/FRU .......... 1 3. Unit Replacement Manual ................1 3-1. Unit Layout ....................1 3-2. Replacing the Units .................. 2 (1) Replacing the Fusing Web Unit ............2 (2) Replacing the Oil Coating Unit ............
  • Page 7 ✽ The contents of the this list are subject to change without notice. ✽ For details, see the unit life manual about the PM cycle. PM Cycle Page Unit Name Maintenance Message Display CF2001/ CF1501 Imaging Unit 7122 min P-21 (Bk)
  • Page 8 PM Cycle Page Unit Name Maintenance Message Display CF2001/ CF1501 Imaging Unit 4562 min P-11 (31K/28K) Fusing Unit 102K/102K P-22 Oil Coating 34K/27K Unit...
  • Page 9 PM Cycle Page Unit Name Maintenance Message Display CF2001/ CF1501 Fusing Web 17K/17K Unit Waste Toner 40K/40K P-19 Bottle Image 17545 min Transfer Belt P-26 (121K/121K) Unit...
  • Page 10 PM Cycle Page Unit Name Maintenance Message Display CF2001/ CF1501 Image Transfer Nothing to indicate 121K/121K P-26 Roller Unit Paper Dust Nothing to indicate 121K/121K P-26 Cleaner 12. Ozone Filter Nothing to indicate 121K/121K P-26...

  • Page 11: The Indication Of Replacement For Cru/Tfu/Fru

    Unit Replacement Manual 3-1. Unit Layout Image Transfer Belt Unit Replace every 121 K. Replace the waste toner bottle about 4.5 K prints after WASTE TONER BOTTLE NEARLY FULL is detected. Ozone Filter Replace every 121 K. 4004D301AA Imaging Unit C, M, Y: Replace every 4,562 M.

  • Page 12: Replacing The Units

    3-2. Replacing the Units Replacing the Fusing Web Unit Removal method NOTE • Before replacing the fusing web unit, ensure that it is not hot. 1. Turn OFF the main switch, then wait for about 20 min- utes. 2. Open the Upper Right Door.
  • Page 13 4. Grasp the two blue lock levers, and remove the fusing web unit. 4004D306AA NOTE • Do not touch the metal ter- minals beneath the fusing Terminals (metal) web unit (on the fusing unit side). Failure to observe this pre- caution may cause an elec- trostatic discharge, resulting in a breakdown.
  • Page 14 Installation method 1. Remove the fusing web unit from its box, and remove the packing mate- rial. 2. Grasp the two blue lock levers, and set the fusing web unit in place. NOTE • When setting the fusing web unit, align the ▼ mark on the fusing web unit with the ▼...
  • Page 15 4. Close the Upper Right Door. 4004D311AA...

  • Page 16: Replacing The Oil Coating Unit

    Replacing the Oil Coating Unit Removal method NOTE • Before replacing the oil coating unit, ensure that it is not hot. • When placing the oil coating unit on a bench, for example, stand it upright. 1. Turn OFF the main switch, and wait for about 20 min- utes.
  • Page 17 3. Release the two green lock levers. 4004D312AA 4. Grasp the two green han- dles, and remove the oil coating unit. 4004D313AA...
  • Page 18 NOTE • Do not touch the metal ter- Terminal (metal) minals beneath the fusing web unit (on the fusing unit side). Failure to observe this pre- caution may cause an elec- trostatic discharge, resulting in a breakdown. 4004D314AA...
  • Page 19 Installation method 1. Withdraw the oil coating unit from its box, and remove the packing mate- rial. 2. Grasp the two green han- dles, and set the oil coat- ing unit in place. 4004D315AA 3. Lock the two green lock levers. 4004D316AA...
  • Page 20 4. Close the Upper Right Door. 4004D311AA...

  • Page 21: Replacing The Imaging Unit (C, M, Y)

    Replacing the Imaging Unit (C, M, Y) Removal method 1. Turn OFF the main switch. 2. Unplug the power cord. 3. Disconnect the grounding cord. 4. Open the Front Door. 4004D317AA 5. Release the lock lever of the imaging unit. 4004D318AA...
  • Page 22 6. Remove the removal jig of the imaging unit from the main unit. 4004D319AA 7. Set the removal jig of the imaging unit in place. 8. Slowly rotate the jig clock- wise until it is fixed. 4004D320AA 9. Install the bottom cover of the imaging unit.
  • Page 23 10. Grasp the removal jig of the imaging unit, then slowly withdraw the imag- ing unit while supporting the bottom cover with your hand. NOTE • Do not remove the bottom cover after removing the imaging unit. 4004D322AA 11. Remove the removal jig of the imaging unit, and return it to the main unit.
  • Page 24 Installation method NOTE • To prevent damaging the imaging unit by exposure to light, keep the imaging unit in its light-proof vinyl pouch until immediately before installing it. • When holding the Imaging Unit, be sure to hold it by its bottom cover. If the Top Imaging Unit Cover is hold, it may full off or the PC Drum installed on the Imaging Unit may be damage, resulting in decreased image quality.
  • Page 25 4. Remove the shipping cushion. C4004U214AA NOTE • When installing the imaging unit, ensure that the color of the mounting guide of the imaging unit is the same as the color of the label at the mounting position on the main unit.
  • Page 26 7. Using your left hand, sup- port the bottom of the imaging unit, then using your right hand gently push in the part shown in the drawing of the unit. NOTE • When installing the imaging unit, insert it to the position where it clicks into place.
  • Page 27 11. Close the Front Door. 4004D329AA 12. Separate the top and bot- tom halves of the Imaging Unit Cover. 4004D330AA...
  • Page 28 13. Install the top cover on the imaging unit that you removed in step 10 on Page 13. NOTE • The four claws of the top cover must be engaged with the four claw holders. 14. Connect the grounding lead. 15.

  • Page 29: Replacing The Waste Toner Bottle

    Replacing the Waste Toner Bottle NOTE • If the paper exit system option is installed, remove it from the main unit before replac- ing the waste toner bottle. • When removing the paper exit system option, support the horizontal transport unit with your hand to prevent it from dropping.
  • Page 30 NOTE • Raise the waste toner bottle gently before removing it. • If scattered toner has accumulated in the vicinity of the toner collecting port, do not tilt the waste toner bottle when removing it. • Do not leave the waste toner bottle in a tilted condition after removing it. 4.

  • Page 31: Replacing The Imaging Unit Bk

    Installation method 1. Remove the waste toner bottle from its box, and remove the packing mate- rial. 2. Grasp the handle, and set the waste toner bottle in place. 4004D335AA 3. Close the Left Door. 4. Turn ON the main switch. 4004D336AA Replacing the Imaging Unit Bk For the method of replacing the imaging unit, refer to “(3) Replacing the Imaging Unit (C, M,...

  • Page 32: Replacing The Fusing Unit

    Replacing the Fusing Unit Removal method NOTE • Before replacing the fusing unit, ensure that it is not hot. 1. Turn OFF the main switch, then wait for about 20 min- utes. 2. Open the Right Door. 4004D349AA 3. Open the Upper Right Door.
  • Page 33 4. Grasp the blue lever, and remove the fusing unit. 4004D304AA 5. Grasp the two handles with the blue labels, and remove the fusing unit. 4004D338AA...
  • Page 34 Installation method 1. Remove the fusing unit from its box, and remove the packing material. 2. Grasp the two handles with the blue labels, and install the fusing unit. NOTE • When installing the fusing unit, align it with the posi- tioning pin on the main unit.
  • Page 35 5. Close the Right Door. NOTE • Ensure that both the front and rear sides are locked. 4004D350AA...

  • Page 36: Replacing The Paper Dust Remover, Image Transfer Roller Unit, Image Transfer Belt Unit, And Ozone Filter

    Replacing the Paper Dust Remover, Image Transfer Roller Unit, Image Transfer Belt Unit, and Ozone Filter ✽ Store transfer belt unit within the temperature range of 0°C - 35°C. If it is left in high tem- perature, void areas may be generated. Removal method NOTE •...
  • Page 37 4. Release the two blue lock levers. 5. Grasp the two blue lock levers, and remove the image transfer roller unit. 4004D341AA 6. Open the Left Door. 4004D332AA...
  • Page 38 7. Grasp the handle, and remove the waste toner bottle. 4004D333AA NOTE • Raise the waste toner bottle gently before removing it. • If scattered toner has accumulated in the vicinity of the toner collecting port, do not tilt the waste toner bottle when removing it. •...
  • Page 39 9. Remove the ozone filter while grasping the hooks at both ends. 4004D343AA...
  • Page 40 Installation method 1. Install the Ozone Filter. 4004D344AA NOTE • When installing the image transfer belt unit, wear the gloves packed with the unit. (This is to prevent the possibility of a defective image due to finger marks adhering to the transfer film.) •...
  • Page 41 2. Insert the Image Transfer Belt Unit. 4004D346AA 3. Grasp the handle, and install the waste toner bot- tle. 4004D335AA 4. Close the Left Door. 4004D336AA...
  • Page 42 5. Grasp the two blue lock levers, and install the image transfer roller unit. 6. Lock the two blue lock levers. 4004D347AA 7. Install the paper dust remover. NOTE • Push in the hook with the gray label until it clicks into place.
  • Page 43 8. Close the Right Door. NOTE • Both the front and rear sides must be locked. 9. Turn ON the main switch. 4004D350AA...
  • Page 44 Copyright 2001 MINOLTA Co., Ltd. Printed in Japan Use of this manual should be strictly supervised to avoid disclosure of confidential information. MINOLTA Co., Ltd. 7669-4004-11 01011200...
