- Page 1 Trademark All trademarks are the property of their respective holders. Any question please visit our website at http://www.commell.com.tw. LV-670 series User’s Manual...
-
Page 2: Packing List
Packing List LV670 : Hardware LV-670 Motherboard ............Cable Kit 40-pin ATA100 IDE Flat Cable.......... 34-pin Floppy Cable ............Dual-USB Port Cable ............DB9 COM Port Cable............Audio Cable.……………………………………………………… I/O Shield………………………………………………………… Printed Matter and Software User’s Manual ..............Driver CD ................ -
Page 3: Table Of Contents
Table of Content CHAPTER 1. INTRODUCTION ............5 ..............5 RODUCT VERVIEW ................. 6 PECIFICATION ............9 OMPONENT LACEMENT ..............10 LOCK IAGRAM CHAPTER 2. HARDWARE SETUP ........... 11 2. 1 ............11 ONNECTOR OCATION 2.1.1 Jumper Reference ..............13 2.1.2 Connector Reference ............ - Page 4 APPENDIX. A I/O PORT PIN ASSIGNMENT........35 IDE Port ................... 35 Floppy Port ................37 Serial Port ................37 USB Port ................. 38 IrDA Port .................. 38 VGA Port ................. 39 LAN Port .................. 39 APPENDIX B. FLASH THE BIOS............41 BIOS A ............41 LASH ..............41...
-
Page 5: Chapter 1. Introduction
Chapter 1. Introduction Product Overview LV-670 series (Include LV-670 and LV-670LVDS) is an all-in-one industrial compact Pentium 4 level motherboard based on Mini-ITX form factor at 170 x 170 mm of dimension. Based on Intel 845GV and ICH4 chipset, LV-670 series offers the compact, embedded, value and high performance solution with Intel Pentium 4 CPU, 533 / 400 MHz of FSB, 1 GBytes DDR200/266/333 SDRAM, Intel 845GV GMCH built-in Intel Extreme Graphics, Intel PRO/100+ LAN, Hi-Speed USB 2.0, IEEE 1394, 5.1 channel... -
Page 6: Specification
Specification General Specification Form Factor Mini-ITX at 170 x 170 mm (L x W) Intel Socket 478 Pentium 4 / Celeron @ 533/400 MHz FSB Support Northwood / Willamette Pentium 4 / Celeron CPU Memory 1GBytes DDR200/266/333 SDRAM on one 184-pin DIMM socket Chipset Intel 82845GV GMCH and 82801DB ICH4... - Page 7 VGA Display Interface Chipset Intel 845GV GMCH built-in Intel Extreme Graphics With 266 MHz VGA core and 256-bit 3D engine Memory Intel dynamic video memory up to 64 Mbytes shared with system Display Type CRT, LCD monitor and analog display Up to 4 textures / pixel on a single pass and 2048x2048 texture size Connector...
- Page 8 Mini-ITX Socket 478 Pentium 4 Motherboard with Intel Extreme VGA, LAN, TV-out, 5.1-CH/SPDIF Audio, Hi-Speed USB 2.0, IEEE1394 Interface LV-670LVDS Same with LV-670 but support 24-bit dual channel LVDS For further product information please visit the website at http://www.commell.com.tw LV-670 series User’s Manual...
-
Page 9: Component Placement
Component Placement ALC650 AC97 Audio Codec Chipset on Back Side With 5.1 Channel Audio Intel 82562ET LAN Phy S/P DIF, Line-in/out, Mic-in Agere FW323 IEEE1394 and CD-in Interface Controller Intel 845GV GMCH Intel 82801DB ICH4 With 533 / 400 MHz Host Bus With Hi-Speed USB 2.0 200 / 266 /333 MHz Memory UltraATA100 IDE... -
Page 10: Block Diagram
Block Diagram Intel Socket 478 Pentium 4 / Celeron CPU Intel 0.13-/0.18-micron Northwood / Willamette Support Intel Hyper-Threading Technology FSB 400 / 533 MHz 100 / 133 MHz x 4 LVDS LVDS One 184-pin Encoder DIMM Sockets up to 1GBytes DDR266 Intel 845G DDR333... -
Page 11: Chapter 2. Hardware Setup
Chapter 2. Hardware Setup This chapter contains the information for installation of hardware. The install procedure includes jumper settings, CPU and memory installation, fan, I/O and panel connections. 2. 1 Connector Location CPUFAN JKBV JAUDIO CDIN1 PCI1 IDE2 DIMM1 IDE1 FLOPPY JIR1 JRTC... - Page 12 CPUFAN JAUDIO CDIN1 CONLCD PCI1 IDE2 DIMM1 IDE1 FLOPPY JIR1 JRTC JFRNT CHASFAN JWOL COM1 USB1 Printer SVDIO1 RJACK1 VGA1 USRJ1 P1 RJACK2 LV-670 series User’s Manual...
-
Page 13: Jumper Reference
2.1.1 Jumper Reference LV-670 Jumper Function JRTC COMS Operate / Clear Setting JKBV Keyboard +5V / +5VSB Voltage Setting IEEE1394 Enable/Disable Setting S/P DIF Input / Output Setting LV-670LVDS Jumper Function JRTC COMS Operate / Clear Setting IEEE1394 Enable/Disable Setting S/P DIF Input / Output Setting Panel Voltage Setting Jumper Setting Quick Reference... -
Page 14: Connector Reference
2.1.2 Connector Reference Internal Onboard Connector Connector Function Remark MicroPGA478 478 CPU Socket Standard DIMM1 184-pin DIMM Socket Standard IDE1 40-pin Primary IDE Port Standard IDE2 44-pin Secondary IDE Port Standard FDC1 34-pin FDD Port Standard JCOM1 10-pin COM1 RS-232 Serial Port Standard USB1 10-pin 3rd / 4th Hi-Speed USB 2.0 Port... -
Page 15: Cpu And Dram Setting
CPU and DRAM Setting The board is based on Intel Socket 478 architecture with Intel 845G chipset, supports Intel Socket 478 Pentium 4 / Celeron CPU at 533/400 MHz FSB. System memory of this board supports up to 1GBytes DDR200/266/333 SDRAM on two 184-pin DIMM sockets. -
Page 16: Watchdog Timer Setting
Watchdog Timer Setting The watchdog timer makes the system auto-reset while it stop to work for a period. The integrated watchdog timer can be setup as system reset mode by program. Timeout Value Range - 1 to 255 - Second or Minute Program Sample Watchdog timer setup as system reset with 5 second of timeout 2E, 87... -
Page 17: Embedded Solid State Disk
Embedded Solid State Disk The LV-670 series supports the IDE-based, bootable and driver free DiskOnModule (DOM) embedded flash disk. The onboard 40-pin IDE1 and 44-pin IDE2 box header supports normal DOM (DiskOnModule) or M- systems DiskOnChip IDE Pro flash disk with or without the additional Vcc power cable. -
Page 18: Power And Fan Connector
Power and Fan Connector CPUFAN 1 2 3 SYSFAN Connector: PW2 Type: 4-pin standard Pentium 4 additional +12V power connector Description Description Ground Ground +12V +12V Connector: PW1 Type: 20-pin ATX power connector PIN assignment 3.3V 3.3V 3.3V -12V PS_ON PW_OK 5V_SB Connector: CPUFAN, SYSFAN... -
Page 19: Vga Interface
VGA Interface 2.7.1 Analog VGA Interface The board is integrated with Intel 845G GMCH chipset built-in Intel Extreme Graphics with 266 MHz VGA core, 256-bit 3D engine and Intel Dynamic Video Memory up to 64MBytes shared with system memory. The CRT / analog VGA interface includes one external DB15 female connector on bracket on board. -
Page 20: Digital Vga Interface (Lv-670Lvds Only)
2.7.2 Digital VGA Interface (LV-670LVDS only) The board’s digital video interface provides LVDS flat panel. The built-in 40-bit dual channel LVDS interface offers the economical solution for LVDS-based LCD display. CONLCD Connector: J4 Connector: J3 Type: 5-pin LVDS Power Header Type: 3-pin Power select Header Description... - Page 21 Connector: CONLCD Type: onboard 40-pin connector for LVDS connector Signal Signal LCDVCC LCDVCC ATX0- BTX0- ATX0+ BTX0+ ATX1- BTX1- ATX1+ BTX1+ ATX2- BTX2- ATX2+ BTX2+ ATXC- BTX3- ATXC+ BTX3+ ATX3- BTXC- ATX3+ BTXC+ PANELCLK PANELCLK PANELDATA PANELDATA LV-670 Series User’s Manual...
-
Page 22: Ethernet Interface
Ethernet Interface The LV-670 series is integrated with Intel PRO/100+ Fast Ethernet interface at the type of 10Base-T/100Base-TX auto-switching Fast Ethernet with full duplex and IEEE 802.3U compliant. The LV-670 series LAN interface is controlled by the Intel 82801DB ICH4 and 82562ET PHY, and connect with the external RJ45 connector on rear I/O panel. -
Page 23: Audio Interface
Audio Interface The LV-670 series offers the AC97 3D audio with 5.1-channel and S/P DIF interface based on Intel ICH4 and Realtek ALC650 codec. JAUDIO CDIN 1 2 3 4 Red: Center / Mic-in Blue: Rear / Line-in Green: Front / Line-out LV-670 Series User’s Manual... - Page 24 Connector: JAUDIO Type: 10-pin (2 x 5) 2.54-pitch header Description Description Line – Right Ground Line – Left Ground Line Out – Left Line Out – Right Ground Jumper: J2 Type: onboard 3-pin header Mode S/P DIF Output S/P DIF Input Default setting Connector: CDIN Type: 4-pin header...
-
Page 25: Switch And Indicator
2.10 Switch and Indicator JFRNT Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header Function Signal Signal Function Vcc (+) (+) Vcc IDE LED Power Active Reset Reset Speaker Power PWRBT Button SPKIN LV-670 Series User’s Manual... - Page 26 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 27: Chapter 3. Bios Setup
Chapter 3. BIOS Setup The single board computer uses the Award BIOS for the system configuration. The Award BIOS in the single board computer is a customized version of the industrial standard BIOS for IBM PC AT-compatible computers. It supports Intel x86 and compatible CPU architecture based processors and computers. - Page 28 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 29: Chapter 4 Audio Channel Configuration
Chapter 4 Audio Channel Configuration In order to enable 5.1 channel, please follow the setup steps below: lunch the Control Panel lunch the Sound Effect Manager 3.select Speaker Configuration and choose 6 channel mode for 5.1 speaker output LV-670 Series User’s Manual... - Page 30 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 31: Chapter 5. Display Settings
Chapter 5. Display Settings Before you using your display device: 1. Check your software Before you can use the display device properly, please install the VGA drivers. 2. Check your hardware Please setup the display device properly before you boot up the system. For configure your Display device, please follow the instructions below: 1. - Page 32 4. There will be a different device list depends on your connecting devices For Monitor: You can configure the Colors, Screen area (resolution) and Refresh Rate. For Notebook: If you connect a LCD panel though LVDS interface, you can configure the Colors and Screen Area (resolution) here.
- Page 33 For Television: If you connect a TV set through S-Video or RCA connector, here can let you configure the Colors, Screen Area (resolution) and Video Standard. If you connect the Monitor and LCD panel at the same time, here can let you configure if you want to have a clone dual display function.
- Page 34 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 35: Appendix. A I/O Port Pin Assignment
Appendix. A I/O Port Pin Assignment IDE Port Connector: IDE1 Type: 40-pin (20 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY IDESEL DACK- Ground CBLID CS0 (MASTER CS) CS1 (SLAVE CS) LED ACT- Ground LV-670 Series User’s Manual... - Page 36 Connector: IDE2 Type: 44-pin (22 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY Ground DACK- Ground ASP1 Ground Ground Ground LV-670 Series User’s Manual...
-
Page 37: Floppy Port
Floppy Port Connector: FDC1 Type: 34-pin (17 x 2) header Description Description Ground DRIVE DENSITY SELECT 0 Ground DRIVE DENSITY SELECT 1 Ground Ground INDEX- Ground MOTOR ENABLE A- Ground DRIVER SELECT B- Ground DRIVER SELECT A- Ground MOTOR ENABLE B- Ground DIRECTION- Ground... -
Page 38: Usb Port
USB Port Connector: JUSB1 Type: 10-pin (5 x 2) header for dual USB Ports Description Description Data0- Data1- Data0+ Data1+ Ground Ground IrDA Port Connector: JIR1 Type: 10-pin (5 x 2) header for SIR/CIR Ports Description Description CIRRX IRRX 5V Standby Ground IRTX LV-670 Series User’s Manual... -
Page 39: Vga Port
VGA Port Connector: VGA Type: 15-pin D-sub female connector on bracket Description Description Description Ground GREEN Ground 5VCDA BLUE Ground HSYNC LVGA5V VSYNC Ground Ground 5VCLK LAN Port Connector: LAN Type: RJ45 connector with LED on bracket Description LV-670 Series User’s Manual... - Page 40 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 41: Appendix B. Flash The Bios
The board is based on Award BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: http://www.award.com http://www.commell.com.tw/Support/Support_SBC.htm File name of the tool is “awdflash.exe”, it’s the utility that can write the data into the BIOS flash ship and update the BIOS. - Page 42 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 43: Appendix C. System Resources
Appendix C. System Resources C.1 I/O Port Address Map Address Range Device 0000-000F PC Compatible Eisa/Isa HAL 0020-0021 PC Compatible Eisa/Isa HAL 0040-0043 PC Compatible Eisa/Isa HAL 0048-0048 PC Compatible Eisa/Isa HAL 0060-0060 i8042prt 0061-0064 PC Compatible Eisa/Isa HAL 0064-0064 i8042prt 0070-0071 PC Compatible Eisa/Isa HAL... -
Page 44: Memory Address Map
Memory Address Map Range Device 0xCBA00-0xCBFFF System board 0xF0000-0xF7FFF System board 0xF8000-0xFBFFF System board 0xFC000-0xFFFFF System board 0xF7F0000-0xF7FFFFF System board 0x0000-0x9FFFF System board 0x100000-0xF7EFFFF System board 0xFEC00000-0xFEC00FFF System board 0xFEE00000-0xFEE00FFF System board 0xFFB00000-0xFFBFFFFF System board 0xFFF00000-0xFFFFFFFF System board 0xE0000-0xEFFFF System board 0xA0000-0xBFFFF PCI bus 0xA0000-0xBFFFF... -
Page 45: System Irq And Dma Resource
System IRQ and DMA Resource C3.1 IRQ IRQ Number Device System timer Standard 101/102-Key or Microsoft Natural Keyboard Programmable Interrupt Controller Communications Port (COM2) Communications Port (COM1) ACPI IRQ Holder for PCI IRQ Steering Advance AC97 Audio Intel(R) 82801DB/DBM SMBus Controller - 24C3 PCI OHCI Compliant IEEE 1394 Host Controller Standard Floppy Disk Controller Parallel Port (LPT1) - Page 46 C3.2 DMA Channel Device (free) (free) Standard Floppy Disk Controller (free) Direct Memory Access Controller (free) (free) (free) LV-670 Series User’s Manual...
- Page 47 Notes (This page left blank intentionally) LV-670 Series User’s Manual...
-
Page 48: Contact Information
Any advice or comment about our products and service, or anything we can help you please don’t hesitate to contact with us. We will do our best to support you for your products, projects and business. COMMELL IPC Division Taiwan Commate Computer, Inc. COMMELL www.commell.com.tw...
