Model EE-Ti
WARNING
For Your saFetY - This product must be installed by a licensed HVAC technician certified in heat
pump repair and maintenance by the jurisdiction in which the product will be installed where such
state or local requirements exists. The technician must possess and comply with all certifications and
regulations regarding the purchasing, handling, transportation and reclamation of R410A refrigerant.
In the event no such state or local requirement exists, the installer or maintainer must be a
professional with sufficient experience in pool equipment installation and maintenance so that all of
the instructions in this manual can be followed exactly. Before installing this product, read and follow
all warning notices and instructions that accompany this product. Failure to follow warning notices
and instructions may result in property damage, personal injury, or death. Improper installation and/
or operation can create an electrical hazard which can cause serious injury, property damage, or
death. Improper installation and/or operation will void the warranty.
installation and
operation Manual
|
english
Français
|
español
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Zodiac Jandy EE-Ti
Summary of Contents for Zodiac Jandy EE-Ti
-
Page 1: Operation Manual
installation and operation Manual english Français español Jandy Heat Pumps ® Model EE-Ti WARNING For Your saFetY - This product must be installed by a licensed HVAC technician certified in heat pump repair and maintenance by the jurisdiction in which the product will be installed where such state or local requirements exists. -
Page 3: Table Of Contents
Install the Remote Pool-Off-Spa Selector ..........17 Ordering Information ......... 28 4.5.1.2 Configure the Control Panel ....17 Zodiac EE-Ti Heat Pumps Parts List ....28 4.5.2 Two-Wire Connection to an AquaLink ® Zodiac EE-Ti Heat Pumps Exploded View ..29 or TSTAT ............ - Page 4 Figure 14. EE-Ti Heat Pump Connection to Power Center ............18 Figure 15. Main Control Panel ........20 Figure 16. Winterizing the EE-Ti Heat Pump ....23 Figure 17. Heat Pump Operation Overview ....25 Figure 18. Zodiac EE-Ti Heat Pumps Exploded View (EE2000 Shown) ......29...
-
Page 5: Section 1. General Information
“Fresh water swimming pools and spas” include temperatura del agua antes de proceder a fijar systems that utilize saltwater chlorine generator la temperatura. units, such as the Zodiac AquaPure Electronic ® Chlorine Generator. Please ensure that the salt WarninG content of the pool/spa does not exceed The following “Safety Rules for Hot Tubs,”... -
Page 6: Swimming Pool Energy Saving Tips
Page 4 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual Pregnant women take note! Soaking in water The American Red Cross recommends a maximum above 102°F (38.5°C) can cause fetal damage water temperature of 78°F (25°C). Use an accurate during the first three (3) months of pregnancy pool thermometer. A difference of 4°F (2°C), (which could result in the birth of a brain-damaged between 78°F and 82°F (26°C and 28°C), will or deformed child). If pregnant women are going significantly increase energy consumption. to use a spa or hot tub, they should make sure Carefully monitor the water temperature of your the water temperature is below 100°F (38°C) pool in the summertime. You can reduce heat maximum. pump usage due to warmer air temperatures. The water temperature should always be checked During the winter or when on vacation for longer with an accurate thermometer before entering a than a week, turn off the heat pump. spa or hot tub. Temperature controls may vary by Find the proper setting on the heat pump as much as 1F° (1°C). -
Page 7: Technical Assistance
Note: If a flow switch is installed (R0509700), do not exceed 92.5 gpm (350 lpm). Exceeding the maximum flow large scale water loss or flooding. Zodiac cannot rate can damage the flow switch. be responsible for such water loss or flooding or Maximum Working Water resulting damage. - Page 8 Page 6 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual...
-
Page 9: Clearances
Access in front of the heat pump of 24” (60 cm) ocasionar la pérdida de grandes cantidades provides adequate room for serviceability. If the heat pump is to be installed in a garage de agua o inundación. Zodiac Pool Systems, or under a vertical overhang, the unit must have a Inc. no se responsabilizará de dichas pérdidas minimum of 5 feet (1.5 meters) clearance from the top de agua o inundaciones, ni de los daños que of the heat pump. -
Page 10: Equipment Pad
¼ inch per foot maximum and level from note: Bolts and bolt anchors are not included with the side to side. heat pump. Zodiac recommends that a 1/4” x 1¾” long galvanized or plated concrete screw and washer is used to mount the clamp to the 2.2.4... -
Page 11: Section 3. Water Connections
ENGLISH Page 9 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual EVAPORATOR Attach anchor COIL GUARD brackets to base EVAPORATOR 1/4" x 1-3/4" COIL GALVANIZED OR of heat pump PLATED where indicated CONCRETE SCREW by the arrows. -
Page 12: Automatic Flow Control Valve
Page 10 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual section 4. electrical Connections The heat pump must be protected from back- siphoning of water. If there is any chance of back- siphoning, provide a check valve between the pool and the filter pump inlet. General information When an automatic chemical feeder is installed Wiring connections must be made exactly as in the plumbing, it must be installed downstream of the shown in the wiring diagram found on the inside of heat pump. A check valve must be installed between the heat pump access compartment (see Figure 8 for the heat pump and the chemical feeder to prevent back- single phase electrical wiring and Figure 9 for 3-phase siphoning of chemically saturated water into the heat electrical wiring). The heat pump must include a pump where it will damage the components. definite means of grounding and bonding. There is a bonding lug on the right side of the heat pump, where a automatic Flow Control Valve bond wire must be attached. -
Page 13: Figure 4. Standard Plumbing Layout
ENGLISH Page 11 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual VENT FOR INDOOR INSTALLATION ONLY CHEMICAL LOOP POOL HEATER OR OPTIONAL CHLORINE GENERATION SYSTEM (JANDY AQUAPURE SHOWN) ® CHEMICAL FEEDER FILTER POOL PUMP FROM POOL OR SPA... -
Page 14: Figure 6. Two (2) Heat Pump Plumbing Layout
Page 12 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual Optional Isolation Valves 2” PVC From Filter 3” PVC Manual Bypass Valve To Pool Figure 6. two (2) Heat pump plumbing layout Optional Isolation Valves 2”... -
Page 15: Figure 8. Ee-Ti Single-Phase Electrical Supply Wiring Diagram
ENGLISH Page 13 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual PUMP TIME CLOCK 24 VAC TRANSFORMER COMPRESSOR HEATER MAINTAIN TEMP RELAY MODEL 3000 ONLY RELAY MAIN CONTACTOR GROUND WATER TEMP AIR TEMP COMPRESSOR CAPACITOR R BK... -
Page 16: Figure 9. Ee-Ti 3-Phase Electrical Supply Wiring Diagram
Page 14 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual PUMP TIME CLOCK 24 VAC TRANSFORMER COMPRESSOR HEATER MAINTAIN TEMP RELAY MODEL 3000 ONLY BK BK RELAY O BK MAIN CONTACTOR GROUND Y-OUT WATER TEMP... -
Page 17: Figure 10. Example Of "Maintain Temp" Wiring To The Time Clock
ENGLISH Page 15 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual INTERMATIC MODEL T104 MECHANICAL TIMER (NOT PROVIDED WITH HEAT PUMP) 208 - 277 VAC PUMP CLOCK MOTOR EQUIPMENT GROUND FIELD INSTALLED COMPONENTS HEAT PUMP COMPONENTS... -
Page 18: Main Power
Page 16 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual Main power Bonding Electrical wiring to the heat pump must be in Caution accordance with the latest edition of the National Electric Code (NEC), ANSI/National Fire Protection ® This heater must be connected to a bonding Association (NFPA) 70 in the United States, and in grid with a solid copper wire not smaller in Canada, the Canadian Electrical Code (CEC) C22.1,... -
Page 19: Optional Remote Controls
ENGLISH Page 17 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual Relay is needed. See Figure 10. note The display will revert back to oFF after one minute since the last key press. optional remote Controls Press the up or down button to display Electrical wiring must be in accordance with all reMote. Press the Menu button. The... -
Page 20: 4.5.2.3 Configure The Control Panel
Menu to disaBle" will disappear 4.5.2. from the heat pump display. All functionality has now Use 22 gauge 4-conductor wire (Zodiac Part No. been returned to the control on the heat pump. In this 4278) to run between the heat pump and the RS mode the RS unit is no longer controlling the heat control, and match the wire color order. pump. To return the functionality to the RS unit, cycle The wires coming from the EE-Ti heat pump can (turn off and then turn on) the power to the heat pump, be “doubled up” on the red terminal bar with the or press the Menu button for 5 seconds to enter the four (4) wires coming from the indoor controller. User Setup Mode and then enable the Zodiac Remote. note If you need to install more than two (2) wires in each terminal, order a Zodiac Multiplex PCB Kit,... -
Page 21: Connection To A Secondary User Interface
ENGLISH Page 19 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual ee-ti Heat pump power aqualink rs software ® Caution interface software rev. revision Keep all objects off the top of the heat pump. 3.0 or later... -
Page 22: Pool Mode - (Optional Maintain Heat)
Page 20 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual pressing the up or down button . Repeatedly press temperature falls to 1 degree below the temperature the up or down button until you reach the desired setting after a 5 minute delay, the control will start temperature set point. After 5 seconds of inactivity, the the heat pump and the associated right LED will light new set point is stored in memory. RED. When the water temperature falls to 1 degree 5.2.5 spa Mode - (optional Maintain Heat) below the temperature setting... -
Page 23: Spa Mode - (Optional Maintain Chill)
ENGLISH Page 21 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual A Maintain Temp Relay is required (provided) and 5.4.2 temperature scale setup the feature must be enabled. Make sure the control is in the oFF mode. When the temperature of the water rises above the desired temperature setting, the control will then turn on To enter the User Setup mode, press and hold the the unit and the associated right green LED will light. Menu button for 5 seconds. To operate in pool mode with the Maintain Chill To select temperature scale, use the up or down feature, press pool , then press Menu , then press... -
Page 24: Set Point Lockout
(1.5 m) above or 10 feet (3 m) below the pool control will display set point loCKed . To unlock surface a flow switch must be used. Please the Set Point Lockout, press and hold the up and down order Zodiac p/n R0509700. buttons for 5 seconds. The unit will display set point unloCKed . On some installations, the piping from the heat pump to the pool is very short. The back pressure could be too low to trigger the pressure switch. If this... -
Page 25: Section 6. General Maintenance
ENGLISH Page 23 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual heat pump compressor will start. Winterizing Once the heat pump is running, turn off the filter Caution pump. The heat pump should turn off immediately. Failure to winterize could cause damage to the If the heat pump continues to operate when the heat pump and will void the warranty. filter pump is off, turn the thumb wheel on the water pressure switch in a clockwise direction attention until “NO FLOW” is displayed on the control and... -
Page 26: Spring Start-Up
Page 24 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual Cover only the top of the heat pump to prevent Zodiac recommends that you inspect your heat debris from falling into the unit. Do not wrap the pump on a regular basis and especially after abnormal sides of the heat pump with any plastic or other weather conditions. The following basic guidelines are material that will retain heat or moisture inside the suggested for your inspection: unit. Keep the top and surrounding areas of the heat pump clear of all debris. spring start-up Keep all plants and shrubs trimmed and away from If your heat pump has been winterized, perform the heat pump. the following steps when starting the system in the Spring: The heat pump will produce condensation (water) while in operation. The heat pump base is designed to Uncover the heat pump and inspect the top and allow the condensation to exit through the bottom drain sides for any debris or structural problems. port when the unit is running. The condensation will Connect the water inlet and outlet unions located increase as the outdoor air humidity level increases. -
Page 27: Section 7. Professional Maintenance And Service
ENGLISH Page 25 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual pump time clock to an OFF position. Turn the Heat pump Components and heat pump back ON. The heat pump must not operation come on. Evaporator - As air passes through the evaporator, the Inspect the electrical controls, specifically the refrigerant in the evaporator absorbs heat from the following: ambient air. The warmer the ambient air and the a. High and Low Limits larger the surface area of the evaporator the more b. Pressure Switch or Flow Switch heat it can collect. Fan - The heat pump fan produces high volume airflow. c. Temperature Control Adequate airflow is required to move warm air Inspect the evaporator coil for blockage and clean through the large evaporator. as necessary. Compressor - The compressor compresses the Check for spider webs or debris in the condensate refrigerant gas to a higher pressure, increasing the drain; clean if necessary. -
Page 28: Section 8. Troubleshooting
Page 26 ENGLISH Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual section 8. troubleshooting troubleshooting Guide The following table provides symptoms and solutions for general troubleshouting problems for the heat pump. table 4. Heat pump troubleshouting Guide sYMptoM CorreCtiVe aCtion Heat pump will not start, no control board display. Breaker or fuse may be tripped. Reset breaker or check fuse. If heat pump still does not run, call for service. -
Page 29: Diagnostics
ENGLISH Page 27 Zodiac ® Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual diagnostics In the event a pressure switch opens or another fault condition occurs, the LCD screen will display the fault until the problem has been resolved. Please refer to the following table for the list of diagnostic conditions. table 5. Heat pump diagnostics diaGnostiC Condition desCription FAULT- Low or restricted water flow through the heat pump. NO FLOW The external bypass valve is in the wrong position, or the water flow switch has malfunctioned. -
Page 30: Section 9. Replacement Parts
Jandy ® Heat Pumps Model EE-Ti Installation and Operation Manual section 9. replacement parts ordering information To order or purchase parts for the EE-Ti models of heat pumps, contact your nearest Zodiac dealer or distributor. See the Zodiac web site at www.Zodiac.com for the nearest service center. If they cannot supply you with what you need, contact Zodiac customer support department, telephone (800) 822-7933. Zodiac ee-ti Heat pumps parts list order order description Model no. part no. description Model no. part no. Top Enclosure, Jacket... -
Page 31: Zodiac Ee-Ti Heat Pumps Exploded View
Heat Pumps Model EE-Ti Installation and Operation Manual Zodiac ee-ti Heat pumps exploded View These pressure switches are installed in the refrigerant line near the compressor DETAIL “A” DETAIL “B” Figure 18. Zodiac ee-ti Heat pumps exploded View (ee2000 shown) - Page 32 2620 Commerce Way, Vista, CA 92081 1.800.822.7933 | www.ZodiacPoolSystems.com ZODIAC ® is a registered trademark of Zodiac International, S.A.S.U., used under license. All trademarks referenced herein are the property of their respective owners. ©2012 Zodiac Pool Systems, Inc. H0335800 Rev H 1206...
