Set; Clear; Calibration; Lighting - Nexus NX2 Wind Data Installation And Operation Manual

WIND DATA
5.2.4

SET

A press on SET unlocks a digit to access edit PAGE.
When unlocked, the digits are "active" (flashes) and can be edited
by pressing MINUS, PLUS and PAGE as required.
When finished editing, lock the digit by another press on SET.
5.2.5

Clear

A press on C, clear digits.
5.2.6

Calibration

To access calibration PAGE, press and hold SET more than 2
seconds.
To return to main function PAGE, press SET when the text return
[RET] is shown.
5.2.7

Lighting

The instrument uses red back lighting for the display and the 5
push-buttons. The lighting can be set at 4 different levels.
To quick access the light control, press and hold PAGE for more
than 2 seconds. The flashing text [Lit OFF] will be displayed and
the display will be lit momentarily.
To select between the 4 light levels, press PLUS: [LOW], [MID],
[MAX] and [OFF]. To lock the selected level, press SET.
The selected light level will be copied to all NX2 instruments
connected to the system. When the lighting is on, it is not possible
to reduce or turn off the lighting on an individual instrument.
4-15
2 sec
2 sec
