OWNER'S MANUAL & SERVICE GUIDE
ELECTRIC POWERED
FLEET GOLF CARS & PERSONAL VEHICLES
REVISED: 03/30/05

Advertisement

Table of Contents
loading

Summary of Contents for Ezgo EZGO

  • Page 1 28645-G01 OWNER’S MANUAL & SERVICE GUIDE ELECTRIC POWERED FLEET GOLF CARS & PERSONAL VEHICLES REVISED: 03/30/05...
  • Page 2: Safety

    SAFETY For any questions on material contained in this manual, contact an authorized representative for clarification. Read and understand all labels located on the vehicle. Always replace any damaged or missing labels. On steep hills it is possible for vehicles to coast at greater than normal speeds encountered on a flat surface. To pre- vent loss of vehicle control and possible serious injury, speeds should be limited to no more than the maximum speed on level ground.
  • Page 3 TO CONTACT US NORTH AMERICA: TECHNICAL ASSISTANCE & WARRANTY PHONE: 1-800-774-3946, FAX: 1-800-448-8124 SERVICE PARTS PHONE: 1-888-GET-EZGO (1-888-438-3946), FAX: 1-800-752-6175 INTERNATIONAL: PHONE: 010-1-706-798-4311, FAX: 010-1-706-771-4609 E-Z-GO DIVISION OF TEXTRON, INC., 1451 MARVIN GRIFFIN ROAD, AUGUSTA, GEORGIA USA 30906-3852 Owner’s Manual and Service Guide...
  • Page 4: General Information

    GENERAL INFORMATION This vehicle has been designed and manufactured in the United States of America (USA) as a ‘World Vehicle’. The Standards and Specifications listed in the following text originate in the USA unless otherwise indicated. The use of non Original Equipment Manufacturer (OEM) approved parts may void the warranty.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY ......................... Inside covers GENERAL INFORMATION ......................ii SAFETY INFORMATION ......................v BEFORE INITIAL USE ......................1 Fig. 1 Initial Service Chart ........................1 PORTABLE CHARGER INSTALLATION ......................1 Fig. 2 Proper Charger Installation ......................2 Fig. 3 Charger Receptacle Location ......................2 CONTROLS AND INDICATORS ....................
  • Page 6 TABLE OF CONTENTS Late Production ............................13 Fig. 15 Serial Number Plate Location - Late Production ..............13 PERIODIC SERVICE SCHEDULE ........................14 Fig. 16 Periodic Service Schedule ...................... 14 TIRE INSPECTION ............................15 BRAKES ................................15 Periodic Brake Test for Mechanical Brakes....................15 Fig.
  • Page 7 TABLE OF CONTENTS DOMESTIC WARRANTY ........................... 42 INTERNATIONAL WARRANTY (2001) ......................43 INTERNATIONAL WARRANTY (2002) ......................44 INTERNATIONAL WARRANTY (2003) ......................45 DECLARATION OF CONFORMITY (EUROPE ONLY)............47 FLEET GOLF CAR (2000)..........................48 FREEDOM™ GOLF CAR (2000) ........................49 FREEDOM™ HP GOLF CAR (2000) ......................... 50 SHUTTLE 2+2 (2000)............................
  • Page 8 TABLE OF CONTENTS Notes: Owner’s Manual and Service Guide Page vi...
  • Page 9: Safety Information

    SAFETY INFORMATION This manual has been designed to assist in maintaining the vehicle in accordance with procedures developed by the manufacturer. Adherence to these procedures and troubleshooting tips will ensure the best possible service from the product. To reduce the chance of personal injury or property damage, the following must be carefully observed: Certain replacement parts can be used independently and/or in combination with other accessories to modify an E-Z- GO-manufactured vehicle to permit the vehicle to operate at or in excess of 20mph.
  • Page 10: General Operation

    SAFETY INFORMATION Standards of the United States of America (USA) and are not equipped for operation on public streets. Some commu- nities may permit these vehicles to be operated on their streets on a limited basis and in accordance with local ordi- nances.
  • Page 11 SAFETY INFORMATION battery terminals or associated wiring. Remove the batteries or cover exposed terminals with an insulating material. • Check the polarity of each battery terminal and be sure to rewire the batteries correctly. • Use specified replacement parts. Never use replacement parts of lesser quality. •...
  • Page 12 SAFETY INFORMATION Notes: Owner’s Manual and Service Guide Page x...
  • Page 13 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings GENERAL manual without the manufacturer’s prior written authori- zation. Where authorized modifications have been made, The following text is provided as recommended by part II the user shall ensure that capacity, operation, warning, of ASME/ANSI B56.8-1988.
  • Page 14 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Control of Noxious Gases and Fumes turer; 4.8.1 When equipment powered by internal com- (b) emphasis on safety of passengers, material loads, bustion engines is used in enclosed areas, the atmo- carrier operator, and other employees;...
  • Page 15 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings 5.4.9 Carriers shall not be parked or left unattended smooth, sweeping motion. such that they block or obstruct fire aisles, access to Loading stairways, or fire equipment.
  • Page 16 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Maintenance Procedures prevent the use of the carrier until the leak has been eliminated. 6.2.1 Maintenance and inspection of all carriers (o) The carrier manufacturer’s capacity, operation, and shall be performed in conformance with the manufac- maintenance instruction plates, tags, or decals shall be...
  • Page 17 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings GENERAL 5.2.1. Steep Grade The following text is provided as recommended by part II In areas where steep grades exist, golf car operations of ANSI / NGCMA Z130.1 - 1993.
  • Page 18: Preventive Maintenance

    SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings MAINTENANCE liters per car per charge. Because of the highly volatile nature of hydrogen gas and its propensity to rise and accumulate at the ceiling in pockets, a minimum of 5 air 6.1.
  • Page 19 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings governors and all other safety devices shall be inspected 7. FUELS HANDLING AND STORAGE/ and maintained in a safe and proper operating condition BATTERY CHARGING and shall not be modified as supplied by the manufac- turer.
  • Page 20 SAFETY INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Notes: Owner’s Manual and Service Guide Page xviii...
  • Page 21: Before Initial Use

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Thank you for purchasing this vehicle. Before driving the Vehicle batteries must be fully charged before initial use. vehicle, we ask you to spend some time reading this Check for correct tire inflation.
  • Page 22: Fig. 2 Proper Charger Installation

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings The charging (DC) cord is equipped with a polarized con- nector which fits into a matching receptacle on the vehi- Provide Protection From Elements cle.
  • Page 23: Direction Selector

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings DIRECTION SELECTOR Park Service To prevent loss of con- Brake Brake trol, do not move PDS vehicle direction selector while the vehicle is in motion.
  • Page 24: Fig. 7 Run-Tow/Maintenance Switch

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Before attempting to tow vehicle, move With the switch in ‘RUN’ position: the Run-Tow/Maintenance switch to the •...
  • Page 25: Precision Drive System

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings ™ Stay in designated areas and avoid extremely PRECISION DRIVE SYSTEM rough terrain. Precision Drive System™ (PDS) vehicles are operated in Maintain a safe speed when driving down hill.
  • Page 26: Regenerative Braking

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Regenerative Braking a) the vehicle has been stopped for more than 1.5 seconds To prevent the possibili- b) the accelerator pedal has been released for more ty of loss of control that than one second...
  • Page 27: Diagnostic Mode Feature

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Diagnostic Mode Feature Do not hold vehicle on hill by using accelerator and motor. Leaving motor Diagnostic mode eases troubleshooting.
  • Page 28: Sun Top And Windshield

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings SUN TOP AND WINDSHIELD with lukewarm or cold water and mild detergent is required to preserve the painted surfaces. The sun top does not Occasional cleaning and waxing with non-abrasive prod- provide protection from...
  • Page 29: Repair

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings REPAIR Center of LIFTING THE VEHICLE Front Axle Tool List Qty. Required Floor jack ..............1 Jack stands ..............
  • Page 30: Wheel Installation

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Use caution when inflating tires. Due to the low volume of assure even seating of the wheel against the hub. the small tires, overinflation can occur in seconds.
  • Page 31: Fig. 12 Headlight, Turn Signal & Marker Light Bulb Replacement

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Do not ride on vehicle being towed. Do not attempt to tow the vehicle with ropes, chains or any device other than a factory approved tow bar.
  • Page 32: Service And Maintenance

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Always remove windshield before transporting. servicing. Maximum speed with sun top installed is 50 mph The electrolyte in a battery is an acid solution (80 kph).
  • Page 33: Late Production

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings To prolong vehicle life, some mainte- quently on vehicles used under severe driving conditions such nance items must be serviced more fre- as extreme temperatures, extreme dust/debris conditions, fre- quently on vehicles used under severe driving conditions such quent use with maximum load.
  • Page 34: Periodic Service Schedule

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings PERIODIC SERVICE SCHEDULE ✓ Check ♦ Clean, Adjust, etc. ▲ Replace To perform service that is listed in this schedule but not described in this manual, contact a local Service Representa- tive or see the Repair and Service Manual for this vehicle.
  • Page 35: Tire Inspection

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings ✓ Check for bent/binding linkage rod ✓ Check for damage or wear to latch arm or catch bracket PARK BRAKE ♦...
  • Page 36: Fig. 17 Typical Brake Performance Test

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings able stopping distance or pulls to one side, the vehicle has failed the test and should be tested again. If the vehicle fails the second test, it should immediately be removed from service.
  • Page 37: Checking The Lubricant Level

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Checking the Lubricant Level Clean the area around the check/fill plug and remove plug. The correct lubricant level is just below the bottom of the threaded hole.
  • Page 38: Fig. 22 Torque Specifications And Bolt Grades

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings ALL TORQUE FIGURES ARE IN FT. LBS. (Nm) Unless otherwise noted in text, tighten all hardware in accordance with this chart. This chart specifies 'lubricated' torque figures.
  • Page 39: Batteries And Charging

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings BATTERIES AND CHARGING must be used with extreme care. Insulate metal container to prevent can from contacting battery SAFETY terminals which could result in an explosion.
  • Page 40: Monthly

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Before charging the batteries, inspect the plug of the bat- vent tube and battery cap. The water will evaporate but tery charger and vehicle receptacle housing for dirt or the sulfuric acid will remain where it can damage vehicle debris.
  • Page 41: Fig. 26 Automatic Watering Gun

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings The correct cleaning technique is to spray the top and sides of the batteries with a solution of sodium bicarbon- Watering gun similar to the type included in the ate (baking soda) and water.
  • Page 42: Fig. 28 Battery Connections

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings If the batteries have been cleaned and any acid in the In high temperatures the chemical reaction is faster, battery rack area neutralized as recommended, no corro- while low temperatures cause the chemical reaction to sion to the battery racks or surrounding area should be...
  • Page 43: Ac Voltage

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings age could be the cause and the power company should be consulted. TROUBLESHOOTING In general, troubleshooting will be done for two distinct reasons.
  • Page 44: Fig. 30 Hydrometer

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Using A Hydrometer Bulb 1. Draw electrolyte into the hydrometer several times to Cylinder permit the thermometer to adjust to the electrolyte Float temperature and note the reading.
  • Page 45: Fig. 31 Hydrometer Temperature Correction

    OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Electrolyte Temperature ° F ° C 71.1 +.032 Main Contact +.030 65.6 +.028 Auxiliary Contact +.026 60.0 +.024 EXAMPLE #1:...
  • Page 46 OPERATION AND SERVICE INFORMATION Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings Notes: Owner’s Manual and Service Guide Page 26...
  • Page 47: General Specifications

    GENERAL SPECIFICATIONS GENERAL SPECIFICATIONS Owner’s Manual and Service Guide Page 27...
  • Page 48: Txt Electric - Fleet

    GENERAL SPECIFICATIONS TXT ELECTRIC - FLEET STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 300 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Series Wound, Non Vented 2.5 hp (1.9 kw) @ 2700 rpm (1 Hour) Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft...
  • Page 49: Txt Pds Electric - Fleet

    GENERAL SPECIFICATIONS TXT PDS ELECTRIC - FLEET STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Shunt Wound with Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft BRAKES...
  • Page 50: Txt Electric - Freedom

    GENERAL SPECIFICATIONS TXT ELECTRIC - FREEDOM™ STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Series Wound, Non Vented 2.5 hp (1.9 kw) @ 2700 rpm (1 Hour) Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft...
  • Page 51: Txt Electric - Freedom™ Se

    GENERAL SPECIFICATIONS TXT ELECTRIC - FREEDOM™ SE STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Series Wound, Non Vented 2.5 hp (1.9 kw) @ 2700 rpm (1 Hour) Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft...
  • Page 52: Txt Electric - Freedom™ Le

    GENERAL SPECIFICATIONS TXT ELECTRIC - FREEDOM™ LE STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Series Wound, Non Vented 2.5 hp (1.9 kw) @ 2700 rpm (1 Hour) Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft...
  • Page 53: Txt Pds Electric - Freedom

    GENERAL SPECIFICATIONS TXT PDS ELECTRIC - FREEDOM™ STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Shunt Wound with Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft BRAKES...
  • Page 54: Txt Pds Electric - Freedom™ Se

    GENERAL SPECIFICATIONS TXT PDS ELECTRIC - FREEDOM™ SE STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Shunt Wound with Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft BRAKES...
  • Page 55: Txt Pds Electric - Freedom™ Le

    GENERAL SPECIFICATIONS TXT PDS ELECTRIC - FREEDOM™ LE STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 350 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Shunt Wound with Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft BRAKES...
  • Page 56: Txt Electric - Shuttle 2+2

    GENERAL SPECIFICATIONS TXT ELECTRIC - SHUTTLE 2+2 STANDARD EQUIPMENT: BATTERIES Six 6 Volt Deep Cycle (105 Minute Minimum, 220 Amp-Hour @ 20 Hour Discharge Rate SPEED CONTROLLER Solid State, 300 Amp Capacity with Non-Contact Inductive Throttle Sensor MOTOR 36 VDC, Series Wound, Non Vented 2.5 hp (1.9 kw) @ 2700 rpm (1 Hour) Brazed Armature and Solid Copper Windings TRANSAXLE 12.44:1 Helical Geared with Input Pinion Shaft Directly Connected to Motor Shaft...
  • Page 57 GENERAL SPECIFICATIONS 67 in. (170 cm) 49 in. (124 cm) Front 4.25 in. 33.5 in. (85 cm) (10.8 cm) Ground Rear Clearance 38 in. (97 cm) 65.5 in. (166 cm) 92.5 in. (235 cm) 105 in. (267 cm) NOTE: Shaded Area Indicates SHUTTLE 2+2 46.5 in.
  • Page 58 GENERAL SPECIFICATIONS RECOMMENDED MAX SIDE TILT RECOMMENDED MAX RAMP 25% GRADE or 14 25% GRADE or 14 TURNING CLEARANCE DIAMETER 19 ft. (5.8 m) Ref Dim 1-2 Fig. 37 Vehicle Dimensions, Incline Specifications and Turning Clearance Diameter Owner’s Manual and Service Guide Page 38...
  • Page 59 GENERAL SPECIFICATIONS FRONT SIDE PowerWise Only 1 in. (2.5 cm) 9 1/8 in. (23 cm) 6 3/4 in. 4 7/8 in. 10 ft. DC 7 ft. AC (17 cm) (12 cm) Cord Cord (3 m) (2 m) 10 7/8 in. 8 3/16 in.
  • Page 60 GENERAL SPECIFICATIONS Notes: Owner’s Manual and Service Guide Page 40...
  • Page 61: Limited Warranties

    WARRANTY LIMITED WARRANTIES Owner’s Manual and Service Guide Page 41...
  • Page 62: Domestic Warranty

    WARRANTY DOMESTIC WARRANTY (U.S. AND CANADA) To obtain a copy of the limited warranty applicable to the vehicle, call or write a local distributor, authorized Branch or the Warranty Department with vehicle serial number and manufacturer date code. Owner’s Manual and Service Guide Page 42...
  • Page 63: International Warranty (2001)

    WARRANTY 2001 INTERNATIONAL WARRANTY (ALL COUNTRIES OUTSIDE THE U.S. AND CANADA) E-Z-GO DIVISION OF TEXTRON INC. ("E-Z-GO") warrants to the Original Retail Purchaser or the Original Retail Lessee that any 2001 E-Z-GO Vehicle and/or Battery Charger shall be free from any defects in ma- terial or workmanship for one year from the date of installation at the customers location with respect to parts and labor.
  • Page 64: International Warranty (2002)

    WARRANTY 2002 INTERNATIONAL WARRANTY (ALL COUNTRIES OUTSIDE THE U.S. AND CANADA) TEXTRON GOLF, TURF & SPECIALTY PRODUCTS “TGTSP”) warrants to the Original Retail Pur- chaser or the Original Retail Lessee that any 2002 TGTSP vehicle and/or Battery Charger shall be free from any defects in material or workmanship for one year from the date of installation at the customer’s location with respect to parts and labor.
  • Page 65: International Warranty (2003)

    WARRANTY 2003 INTERNATIONAL WARRANTY (ALL COUNTRIES OUTSIDE THE U.S. AND CANADA) TEXTRON GOLF, TURF & SPECIALTY PRODUCTS ("TGTSP") warrants to the Original Retail Purchaser or the Original Retail Lessee that any 2003 TGTSP vehicle and/or Battery Charger shall be free from any defects in material or workmanship for one year from the date of installation at the customer's location with respect to parts and labor.
  • Page 66 WARRANTY Notes: Owner’s Manual and Service Guide Page 46...
  • Page 67: Declaration Of Conformity (Europe Only)

    DECLARATION OF CONFORMITY DECLARATION OF CONFORMITY (EUROPE ONLY) Owner’s Manual and Service Guide Page 47...
  • Page 68: Fleet Golf Car (2000)

    DECLARATION OF CONFORMITY Owner’s Manual and Service Guide Page 48...
  • Page 69: Freedom™ Golf Car (2000)

    DECLARATION OF CONFORMITY Owner’s Manual and Service Guide Page 49...
  • Page 70: Freedom™ Hp Golf Car (2000)

    DECLARATION OF CONFORMITY Owner’s Manual and Service Guide Page 50...
  • Page 71 DECLARATION OF CONFORMITY Owner’s Manual and Service Guide Page 51...
  • Page 72: Fleet And Freedom™ Golf Car (2002)

    DECLARATION OF CONFORMITY Anil V. Kulkarni 1451 Marvin Griffin Road Augusta, GA 30906 Vice President of Engineering 706/798-4311 Textron Golf, Turf & Specialty Products 706/771-4602 Fax DECLARATION OF CONFORMITY MODEL NAME MODEL NAME NUMBER NUMBER TXT G 76101 Freedom TXT G 76102 TXT E 76080...
  • Page 73: Shuttle 2+2 (2000)

    DECLARATION OF CONFORMITY Anil V. Kulkarni 1451 Marvin Griffin Road Augusta, GA 30906 Vice President of Engineering 706/798-4311 Textron Golf, Turf & Specialty Products 706/771-4602 Fax DECLARATION OF CONFORMITY MODEL NAME MODEL MODEL NAME MODEL NUMBER NUMBER Industrial 875E 34301 Shuttle 2+2 Freedom TXT G 76106 Industrial 875PE...
  • Page 74 DECLARATION OF CONFORMITY Notes: Owner’s Manual and Service Guide Page 54...
  • Page 75: Labels And Pictograms

    LABELS AND PICTOGRAMS LABELS AND PICTOGRAMS Owner’s Manual and Service Guide Appendix A - 1...
  • Page 76 LABELS AND PICTOGRAMS 74443G01 74443G01 See Following Pages For Explanation Of These Pictograms: (1,2) 71145-G01 74316G01 See Following 71145G01 74316G01 Pages For Explanation Of These Pictograms 71123-G02 74320G01 (43,44,45) 71123G02 74320G01 74322G01 71129-G02 74322G01 71129G02 WARNING FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SEVERE PERSONAL INJURY.
  • Page 77 LABELS AND PICTOGRAMS See Following Pages For See Following Pages For Explanation Of Pictogram (49) Explanation Of Pictogram (30) WARNING WARNING Keep entire body Windshields do not provide protection inside car. from golf balls or other flying objects. 27653G01 EGWHL14 WARNING ■...
  • Page 78 LABELS AND PICTOGRAMS WARNING WARNING READ MANUAL FOR MAXIMUM LOAD BED CAPACITY. MAXIMUM RAMP/HILL READ MANUAL SECURE LOAD AS FAR FORWARD xxx lbs . AS POSSIBLE. xxx kg MAXIMUM LOAD BED WARNING CAPACITY USE CAUTION IN INCLEMENT WEATHER DO NOT RIDE IN LOAD BED WARNING DO NOT OPERATE...
  • Page 79 LABELS AND PICTOGRAMS DO NOT CLEAN UP GASOLINE SPILLS WITH WATER EXPOSE TO FLAME BEFORE STARTING ENGINE UNLEADED DO NOT GASOLINE DISPOSE OF BATTERIES DO NOT IN LANDFILL SPILL FUEL ON A HOT ENGINE DO NOT DRIVE ON GROUND HIGHWAY FUEL PUMP WINDSHIELDS LOW OIL PRESSURE...
  • Page 80 LABELS AND PICTOGRAMS KEEP CLEAR OPERATE HAND OR FROM FINGERS CAN DRIVERS SIDE BE TRAPPED ONLY POSITION KEEP ARMS AND LEGS POSITION WITHIN VEHICLE HEADLIGHTS TO OPERATE VEHICLE IN FORWARD: ✱ TURN KEY TO ON UNLOCKED ✱ MOVE DIRECTION SELECTOR TO FORWARD ✱...
  • Page 81 Read and understand the following warnings Read and understand the following text and before attempting to operate the vehicle: warnings before attempting to service vehicle: In any product, components will eventually fail to perform prevent personal properly as the result of normal use, age, wear or abuse. injury or death, observe It is virtually impossible to anticipate all possible compo- the following:...
  • Page 82 1451 Marvin Griffin Road, Augusta, Georgia USA 30906-3852 TO CONTACT US North America: Technical Assistance & Warranty Phone: 1-800-774-3946, FAX: 1-800-448-8124 Service Parts Phone: 1-888-GET-EZGO (1-888-438-3946), FAX: 1-800-752-6175 International: Phone: 010-1-706-798-4311, FAX: 010-1-706-771-4609 Copyrighted Material This manual may not be reproduced in whole or in part without the express permission of E-Z-GO Division of Textron, Inc.
