SAFETY INSTRUCTIONS
OUTPUT TERMINALS COVER
Models up to 60V output voltage
Hazardous voltages may exist at the output terminals.
Attach the terminals cover, supplied with the unit, to the chassis after connecting the load wires as
described below.
After connection of the load wires ( refer to par. 3-7 ), attach the plastic cover to the rear panel of the
power supply, using two self tapping screws supplied with the unit. Refer to Fig. 1-1 for details.
REAR PANEL
Fig. 1-1: Terminals cover assembly
OUTPUT CONNECTOR COVER
80V and 120V models
Fig. 1-2: Output wires connection
WARNING
PLASTIC COVER
MALE CONNECTOR (PSC1.5/3-M-PE , Phoenix)
LOAD WIRES
FEMALE PLUG (PSC 1.5/3-F)
PLASTIC PLUG COVER
Wires : Copper , AWG16-30
Tightening torque : 4lib-in
